Page 1 Compass 2 0 2 0 O W N E R ’ S M A N U A L...
Page 2 This manual illustrates and describes the operation VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name of features and equipment that are either standard or optional on this vehicle. This manual may also include FCA US LLC shall be deemed to be deleted and the a description of features and equipment that are no name FCA Canada Inc.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ....................................12 GETTING TO KNOW YOUR VEHICLE ............................14 GETTING TO KNOW YOUR INSTRUMENT PANEL ......................111 SAFETY ......................................... 144 STARTING AND OPERATING ..............................236 IN CASE OF EMERGENCY ................................333 SERVICING AND MAINTENANCE .............................398 TECHNICAL SPECIFICATIONS ..............................453 MULTIMEDIA ....................................463 CUSTOMER ASSISTANCE ................................537 INDEX ........................................542 20_MP_OM_EN_USC...
Page 4 INTRODUCTION  REMOTE STARTING SYSTEM — IF EQUIPPED ..25 How To Use Remote Start — If Equipped ....25   INTRODUCTION ...............12 Remote Start Abort Message On The Instrument   HOW TO USE THIS MANUAL........12 Cluster Display — If Equipped ........26 Essential Information ............12 To Enter Remote Start Mode........26 ...
Page 5  DOORS .................33  MIRRORS ................58 Manual Door Locks............33 Inside Day/Night Mirror — If Equipped ....58   Power Door Locks ............34 Electrochromic Mirror — If Equipped ......58   Keyless Enter-N-Go — Passive Entry......34 Outside Mirrors .............59   Automatic Unlock Doors On Exit .......40 Power Adjustment Mirrors ..........60 ...
Page 6  INTERIOR LIGHTS ............68  POWER SUNROOF WITH POWER SHADE — IF Interior Courtesy Lights ..........68 EQUIPPED ................92   WINDSHIELD WIPERS AND WASHERS......70 Opening Sunroof............93  Windshield Wiper Operation ........70 Opening Sunroof — Vent ..........93   Rain Sensing Wipers — If Equipped ......71 Closing Sunroof .............93 ...
Page 7 GETTING TO KNOW YOUR INSTRUMENT  ONBOARD DIAGNOSTIC SYSTEM — OBD II ...141 Onboard Diagnostic System (OBD II) PANEL  Cybersecurity ...............141  INSTRUMENT CLUSTER..........111  EMISSIONS INSPECTION AND MAINTENANCE Instrument Cluster Descriptions .......112 PROGRAMS ...............142   INSTRUMENT CLUSTER DISPLAY ......114 SAFETY Instrument Cluster Display Location And ...
Page 8 Transmission ...............255 Periodic Safety Checks You Should Make  FOUR-WHEEL DRIVE OPERATION — IF  Outside The Vehicle ............235 EQUIPPED .................262 Jeep Active Drive ............262  STARTING AND OPERATING  SELEC-TERRAIN — IF EQUIPPED .......265 Mode Selection Guide ..........265 ...
Page 9  ADAPTIVE CRUISE CONTROL (ACC) — IF  LANESENSE — IF EQUIPPED ........304 EQUIPPED .................274 LaneSense Operation...........304  To Activate/Deactivate ..........276 Turning LaneSense On Or Off ........305   Activating Adaptive Cruise Control (ACC) ....277 LaneSense Warning Message........306   To Set A Desired ACC Speed........278 Changing LaneSense Status ........312 ...
Page 10 IN CASE OF EMERGENCY  REFUELING IN EMERGENCY – IF EQUIPPED ..388  IF YOUR ENGINE OVERHEATS ........389  HAZARD WARNING FLASHERS ........333  GEAR SELECTOR OVERRIDE ........390  ASSIST AND SOS MIRROR — IF EQUIPPED .....333  FREEING A STUCK VEHICLE ........391 General Information............338 ...
Page 11  DEALER SERVICE ............405  DEPARTMENT OF TRANSPORTATION UNIFORM Engine Oil ..............405 TIRE QUALITY GRADES ..........444  Engine Oil Filter............407 Treadwear..............444   Engine Air Cleaner Filter ........... 407 Traction Grades............444   Air Conditioner Maintenance........407 Temperature Grades ...........444  ...
Page 12 TECHNICAL SPECIFICATIONS MULTIMEDIA  IDENTIFICATION DATA ..........453  UCONNECT SYSTEMS............463 Vehicle Identification Number ........453  DRAG & DROP MENU BAR...........463   WHEEL AND TIRE TORQUE SPECIFICATIONS..455  CYBERSECURITY ............464 Torque Specifications..........455  UCONNECT SETTINGS ..........465   FUEL REQUIREMENTS ..........456 Customer Programmable Features —...
Page 13 CUSTOMER ASSISTANCE  RADIO OPERATION AND MOBILE PHONES ..513 Regulatory And Safety Information ......513   SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR  UCONNECT VOICE RECOGNITION QUICK TIPS ..515 VEHICLE ................537 Introducing Uconnect ..........515  Prepare For The Appointment........537 Get Started ..............516 ...
Page 14: Introduction
ROLLOVER WARNING When it comes to service, remember that an authorized dealer knows your Jeep® vehicle best, has factory-trained technicians Utility vehicles have a significantly higher rollover rate than and genuine MOPAR® parts, and cares about your satisfaction.
Page 15: Warnings And Cautions
INTRODUCTION higher center of gravity, if this vehicle is out of control it may Failure to use the driver and passenger seat belts provided is roll over while some other vehicles may not. a major cause of severe or fatal injury. In fact, the US govern- ment notes that the universal use of existing seat belts could Do not attempt sharp turns, abrupt maneuvers, or other unsafe cut the highway death toll by 10,000 or more each year and...
Page 16: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE VEHICLE USER GUIDE — IF EQUIPPED Access your Owner’s Information right through your Ucon- nect 4C or 4C NAV touchscreen system (if equipped). To access the Vehicle User Guide on your Uconnect Touch- screen: Press the Uconnect Apps button. From there, press the Vehicle User Guide icon on your touchscreen.
Page 17 GETTING TO KNOW YOUR VEHICLE NOTE: Features/Benefits Vehicle User Guide features are not available while the • Pre-installed on your Uconnect touchscreen radio vehicle is moving. If you try to access while the vehicle is in • Enhanced search and browsing capability motion, the system will display: Feature not available while the vehicle is in motion.
Page 18: Keys
16 GETTING TO KNOW YOUR VEHICLE KEYS Key Fobs Your vehicle uses either a key start ignition system or keyless ignition system. The ignition system consists of a key fob with a Remote Keyless Entry (RKE) and an ignition switch. The keyless ignition system consists of a key fob and Keyless Enter-N-Go button.
Page 19 GETTING TO KNOW YOUR VEHICLE The keyless ignition key fob also includes an emergency key, To remove the emergency key from the keyless ignition key which stores in the rear of the key fob. fob, slide the mechanical latch at the top of the key fob side- ways with your thumb and then pull the key out with your other hand.
Page 20 18 GETTING TO KNOW YOUR VEHICLE Key Fob: To Lock The Doors And Liftgate Push and release the lock button on the key fob to lock all 1. Remove the emergency key by sliding the mechanical doors and liftgate. latch on the back of the key fob sideways with your thumb and pull the emergency key out with your other The turn signal lights will flash and the horn will chirp to hand.
Page 21 GETTING TO KNOW YOUR VEHICLE 2. Separate the key fob halves using the tip of the emergency key, a #2 flat blade screwdriver, or a coin and gently pry the two halves of the key fob apart. Make sure not to damage the seal during removal.
Page 22 20 GETTING TO KNOW YOUR VEHICLE 4. To assemble the key fob case, snap the two halves together. Programming Additional Key Fobs Programming the key fob may be performed by an autho- rized dealer. NOTE: Once a key fob is programmed to a vehicle, it cannot be repurposed and reprogrammed to another vehicle.
Page 23 GETTING TO KNOW YOUR VEHICLE Duplication of key fobs may be performed at an authorized Le présent appareil est conforme aux CNR d`Innovation, dealer. This procedure consists of programming a blank key Science and Economic Development applicables aux appar- fob to the vehicle electronics. A blank key fob is one that has eils radio exempts de licence.
Page 24: Ignition Switch
22 GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH Keyless Enter-N-Go — Ignition This feature allows the driver to operate the ignition with the push of a button as long as the key fob is in the passenger compartment. The START/STOP push button ignition has three operating modes.
Page 25 GETTING TO KNOW YOUR VEHICLE ON/RUN WARNING! (Continued) • Driving mode. • Do not leave children or animals inside parked vehicles • All the electrical devices are available. in hot weather. Interior heat build-up may cause serious injury or death. START •...
Page 26: Vehicle On Message
24 GETTING TO KNOW YOUR VEHICLE Vehicle On Message WARNING! (Continued) When opening the driver's door and the ignition is in ON/ • Never leave children alone in a vehicle, or with access RUN (engine not running) mode, a chime will sound to to an unlocked vehicle.
Page 27: Remote Starting System - If Equipped
GETTING TO KNOW YOUR VEHICLE All of the following conditions must be met before the engine REMOTE STARTING SYSTEM — IF EQUIPPED will remote start: This system uses the key fob to start the engine • Gear selector in PARK conveniently from outside the vehicle while still maintaining security.
Page 28: Remote Start Abort Message On The Instrument Cluster Display - If Equipped
26 GETTING TO KNOW YOUR VEHICLE The message will stay active until the ignition is placed in the WARNING! ON/RUN position. • Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Monoxide To Enter Remote Start Mode (CO) which is odorless and colorless.
Page 29: To Exit Remote Start Mode Without Driving The Vehicle
GETTING TO KNOW YOUR VEHICLE To Exit Remote Start Mode Without Driving The Remote Start Comfort Systems — If Equipped Vehicle When remote start is activated, the heated steering wheel and driver heated seat features will automatically turn on in Push and release the remote start button one time or allow cold weather.
Page 30: Sentry Key
28 GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las siguientes dos General Information condiciones: The following regulatory statement applies to all Radio 1. es posible que este equipo o dispositivo no cause interfer- Frequency (RF) devices equipped in this vehicle: encia perjudicial y This device complies with Part 15 of the FCC Rules and with 2.
Page 31: Replacement Keys
GETTING TO KNOW YOUR VEHICLE After placing the ignition switch to the ON/RUN position, Replacement Keys the vehicle security light will turn on for three seconds for a NOTE: bulb check. If the light remains on after the bulb check, it Only key fobs that are programmed to the vehicle electronics indicates that there is a problem with the electronics.
Page 32: Key Programming
30 GETTING TO KNOW YOUR VEHICLE Le présent appareil est conforme aux CNR d`Innovation, Key Programming Science and Economic Development applicables aux appar- Programming key fobs may be performed at an authorized eils radio exempts de licence. L'exploitation est autorisée aux dealer.
Page 33: Vehicle Security Alarm - If Equipped
GETTING TO KNOW YOUR VEHICLE 2. Perform one of the following methods to lock the vehicle: VEHICLE SECURITY ALARM — IF EQUIPPED The vehicle security alarm monitors the vehicle doors, hood, • Push the lock button on the interior power door lock liftgate, and the Keyless Enter-N-Go —...
Page 34: Rearming Of The System
32 GETTING TO KNOW YOUR VEHICLE NOTE: If the vehicle security alarm is armed and the battery becomes disconnected, the vehicle security alarm will • The driver's door key cylinder and the liftgate button on remain armed when the battery is reconnected; the exterior the key fob cannot arm or disarm the vehicle security lights will flash, and the horn will sound.
Page 35: Doors
GETTING TO KNOW YOUR VEHICLE DOORS WARNING! • For personal security and safety in the event of a colli- Manual Door Locks sion, lock the vehicle doors before you drive as well as To lock each door, rotate the door lock knob on each door when you park and exit the vehicle.
Page 36: Power Door Locks
34 GETTING TO KNOW YOUR VEHICLE Power Door Locks Keyless Enter-N-Go — Passive Entry A power door lock switch is located on each of the front door The Passive Entry system is an enhancement to the vehicle’s trim panels. Use this switch to lock or unlock the doors, lift- Remote Keyless Entry system and a feature of Keyless gate and fuel door.
Page 37 GETTING TO KNOW YOUR VEHICLE To Unlock From The Driver's Side To Unlock From The Passenger Side With a valid Passive Entry key fob within 5 ft (1.5 m) of the With a valid Passive Entry key fob within 5 ft (1.5 m) of the driver's door handle, grab the front driver door handle to passenger door handle, grab the front passenger door handle unlock the driver's door automatically.
Page 38 36 GETTING TO KNOW YOUR VEHICLE FOBIK-Safe only executes in vehicles with Passive Entry. NOTE: There are three situations that trigger a FOBIK-Safe search in The vehicle will only unlock the doors when a valid Passive any Passive Entry vehicle: Entry key fob is detected inside the vehicle.
Page 39 GETTING TO KNOW YOUR VEHICLE To Lock The Liftgate To Lock The Vehicle’s Doors And Liftgate With a valid Passive Entry key fob within 5 ft (1.5 m) of the With one of the vehicle’s Passive Entry key fobs within 5 ft liftgate, push the passive entry lock button located to the (1.5 m) of the driver or passenger front door handles, push right of the liftgate handle release.
Page 40 38 GETTING TO KNOW YOUR VEHICLE NOTE: • After pushing the door handle button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle without the vehicle reacting and unlocking.
Page 41 GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las siguientes dos General Information condiciones: The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: 1. es posible que este equipo o dispositivo no cause interfer- encia perjudicial y This device complies with Part 15 of the FCC Rules and with Innovation, Science and Economic Development Canada...
Page 42: Automatic Unlock Doors On Exit
40 GETTING TO KNOW YOUR VEHICLE Automatic Unlock Doors On Exit Child-Protection Door Lock System — Rear Doors The doors will unlock automatically on vehicles with power To provide a safer environment for small children riding in door locks if: the rear seats, the rear doors are equipped with a Child-Protection Door Lock system.
Page 43: Seats
GETTING TO KNOW YOUR VEHICLE NOTE: SEATS • When the Child-Protection Door Lock system is engaged, Seats are a part of the Occupant Restraint System of the the door can be opened only by using the outside door vehicle. handle even though the inside door lock is in the unlocked position.
Page 44: Manual Adjustment (Front Seats) - If Equipped
42 GETTING TO KNOW YOUR VEHICLE While sitting in the seat, lift up on the bar and move the seat Manual Adjustment (Front Seats) — If Equipped forward or rearward. Release the bar once you have reached Manual Front Seat Forward/Rearward Adjustment the desired position.
Page 45 GETTING TO KNOW YOUR VEHICLE Manual Seat Height Adjustment — If Equipped Manual Front Seat Recline Adjustment The driver’s seat height can be raised or lowered by using a To adjust the seatback, lift the lever located on the outboard lever, located on the outboard side of the seat.
Page 46: Manual Adjustment (Rear Seats)
44 GETTING TO KNOW YOUR VEHICLE WARNING! WARNING! Do not ride with the seatback reclined so that the Adjusting a seat while the vehicle is moving is shoulder belt is no longer resting against your chest. In a dangerous. The sudden movement of the seat could collision you could slide under the seat belt, which could cause you to lose control.
Page 47 GETTING TO KNOW YOUR VEHICLE NOTE: To Lower The Rear Seat Prior to folding the rear seat, it may be necessary to position 1. Pull the seatback release lever located on either side of the the front seat to its mid-track position. Also, be sure that the upper outer edge of the seat.
Page 48: Power Adjustment (Front Seats) - If Equipped
46 GETTING TO KNOW YOUR VEHICLE To Raise The Rear Seat Power Adjustment (Front Seats) — If Equipped NOTE: Some models may be equipped with a power driver's seat If interference from the cargo area prevents the seatback and/or power passenger seat. The power seat switch and from fully locking, you will have difficulty returning the seat power seat recliner switch are located on the outboard side to its proper position.
Page 49 GETTING TO KNOW YOUR VEHICLE Forward Or Rearward Adjustment The seat can be adjusted both forward and rearward. Push the seat switch forward or rearward, the seat will move in the direction of the switch. Release the switch when the desired position has been reached.
Page 50: Driver Memory Seat - If Equipped
48 GETTING TO KNOW YOUR VEHICLE Power Lumbar — If Equipped Driver Memory Seat — If Equipped This feature allows the driver to store up to two different Vehicles equipped with power driver or passenger seats may memory profiles, for easy recall through a memory switch. be equipped with power lumbar.
Page 51 GETTING TO KNOW YOUR VEHICLE 3. Push and release the set (S) button on the memory switch, Programming The Memory Feature then push memory button (2) within five seconds. The To create a new memory profile, perform the following: instrument cluster display will display which memory position is being set.
Page 52 50 GETTING TO KNOW YOUR VEHICLE To program your key fob, perform the following: Memory Position Recall 1. Place the vehicle’s ignition in the OFF position. NOTE: The vehicle must be in PARK (P) to recall memory positions. 2. Select the desired memory profile (1) or (2). If a recall is attempted when the vehicle is not in PARK, a message will display in the instrument cluster display.
Page 53: Front Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE Each stored memory setting will have an associated Easy Easy Entry/Exit Seat — If Equipped Entry and Easy Exit position. This feature provides automatic driver seat positioning to enhance driver mobility when entering and exiting the NOTE: vehicle.
Page 54: Front Ventilated Seats - If Equipped
52 GETTING TO KNOW YOUR VEHICLE If your vehicle is equipped with automatic temperature WARNING! controls with an integrated center stack, or manual tempera- • Persons who are unable to feel pain to the skin because ture controls, you’ll find the heated seat switches on the of advanced age, chronic illness, diabetes, spinal cord switch bank below the radio screen.
Page 55: Head Restraints
GETTING TO KNOW YOUR VEHICLE The front ventilated seats control buttons are located within HEAD RESTRAINTS the Uconnect system. You can gain access to the control Head restraints are designed to reduce the risk of injury by buttons through the climate screen or the controls screen. restricting head movement in the event of a rear impact.
Page 56: Front Head Restraint Adjustment
54 GETTING TO KNOW YOUR VEHICLE To adjust the head restraint forward, pull the top of the head Front Head Restraint Adjustment restraint toward the front of the vehicle as desired and Your vehicle is equipped with front four way driver and release.
Page 57: Rear Head Restraints
GETTING TO KNOW YOUR VEHICLE Rear Head Restraints The rear head restraints have two positions: up or down. When the center seat is being occupied, the head restraint should be in the raised position. When there is no occupant in the center seat, the head restraint can be lowered for maximum visibility for the driver.
Page 58: Steering Wheel
56 GETTING TO KNOW YOUR VEHICLE To unlock the steering column, push the control handle STEERING WHEEL downward (toward the floor). To tilt the steering column, Tilt/Telescoping Steering Column move the steering wheel upward or downward as desired. To lengthen or shorten the steering column, pull the steering This feature allows you to tilt the steering column upward or wheel outward or push it inward as desired.
Page 59 GETTING TO KNOW YOUR VEHICLE The heated steering wheel control button is located on the WARNING! center instrument panel below the touchscreen, as well as • Persons who are unable to feel pain to the skin because within the climate or controls screen of the touchscreen. of advanced age, chronic illness, diabetes, spinal cord •...
Page 60: Mirrors
58 GETTING TO KNOW YOUR VEHICLE MIRRORS Inside Day/Night Mirror — If Equipped This is a single ball joint mirror that fixes to the windshield button with a counter clockwise rotation. No tools are needed for mounting. The mirror head can be adjusted left and right, or tilted up and down for various drivers.
Page 61: Outside Mirrors
GETTING TO KNOW YOUR VEHICLE This mirror automatically adjusts for headlight glare from CAUTION! vehicles behind you. To avoid damage to the mirror during cleaning, never NOTE: spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the •...
Page 62: Power Adjustment Mirrors
60 GETTING TO KNOW YOUR VEHICLE Power Adjustment Mirrors The power mirror switch is located on the driver’s door panel. To adjust an exterior power mirror, select the right or left side using the mirror selector switch, then push the mirror adjustment switch in the desired direction indicated by the direction arrows.
Page 63: Folding Mirrors
GETTING TO KNOW YOUR VEHICLE Power Folding Mirror — If Equipped Folding Mirrors The switch for the power folding mirrors is located in the The exterior mirrors are hinged to allow the mirror to pivot power mirror switch. forward or rearward to help avoid damage. The mirror has three detent positions: full forward, normal and full rear- Push the switch once and the mirrors will fold in, pushing ward.
Page 64: Heated Mirrors - If Equipped
62 GETTING TO KNOW YOUR VEHICLE Puddle Lamps — If Equipped Illuminated Vanity Mirrors Located under the exterior mirrors is a small lamp that illu- An illuminated vanity mirror is located on each sun visor. To minates the ground when the doors are unlocked with the use the mirror, rotate the sun visor down and swing the key fob or when the doors to the vehicle are open.
Page 65: Exterior Lights
GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS Sun Visor “Slide-On-Rod” Feature — If Equipped The sun visor “Slide-On-Rod” feature allows for additional Multifunction Lever flexibility in positioning the sun visor to block out the sun. The multifunction lever controls the operation of the turn 1.
Page 66: Headlight Switch
64 GETTING TO KNOW YOUR VEHICLE Headlight Switch Daytime Running Lights (DRL) — If Equipped The headlight switch is located on the left side of the instru- The Daytime Running Lights will turn on when the engine is ment panel. This switch controls the operation of the head- started and remain on unless the headlamps are turned on or lights, parking lights, automatic headlights (if equipped), the ignition is placed in the OFF position.
Page 67: Flash-To-Pass
GETTING TO KNOW YOUR VEHICLE NOTE: headlight time delay feature is also on. This means the head- lights will stay on for up to 90 seconds after you place the • The Automatic High Beam Headlamp Control can be ignition into the OFF position. To turn the automatic system turned on or off using the Uconnect System.
Page 68: Lights-On Reminder
66 GETTING TO KNOW YOUR VEHICLE If you turn the headlights off before the ignition, they will Fog Lights — If Equipped turn off in the normal manner. The front fog light switch is built into the headlight switch. NOTE: •...
Page 69: Turn Signals
GETTING TO KNOW YOUR VEHICLE An indicator light in the instrument cluster illuminates when • When the Daytime Running Lights are on and a turn signal the fog lights are turned on. is activated, the Daytime Running Lamp will turn off on the side of the vehicle in which the turn signal is flashing.
Page 70: Interior Lights
68 GETTING TO KNOW YOUR VEHICLE To protect the battery, the interior lights will turn off auto- INTERIOR LIGHTS matically 15 minutes after the ignition is placed in the OFF Interior Courtesy Lights position. This will occur if the interior lights were switched on manually or are on because a door is open.
Page 71 GETTING TO KNOW YOUR VEHICLE Rotating the instrument panel dimmer up or down will Ambient Light Control — If Equipped adjust the brightness of the instrument panel lights ONLY Rotate the ambient dimmer control upward or downward to when the parking lights or headlights are turned on, AND increase or decrease the brightness of the ambient light ONLY if the built in cluster light sensor determines that the located in the overhead console, door handle lights, lights...
Page 72: Windshield Wipers And Washers
70 GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Windshield Wiper Operation The windshield wiper/washer controls are located on the Rotate the end of the lever to one of the first two detent posi- windshield wiper/washer lever on the right side of the tions for intermittent settings.
Page 73: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE CAUTION! WARNING! Always remove any buildup of snow that prevents the Sudden loss of visibility through the windshield could windshield wiper blades from returning to the “park” lead to a collision. You might not see other vehicles or position.
Page 74: Rear Window Wiper/Washer
72 GETTING TO KNOW YOUR VEHICLE The sensitivity of the system can be adjusted with the multi- • Change In Ignition Position — If the vehicle is in Rain function lever. Wiper delay position one is the least sensitive, Sensing mode and the ignition is cycled from OFF to ON, and wiper delay position two is the most sensitive.
Page 75: Windshield Wiper De-Icer - If Equipped
GETTING TO KNOW YOUR VEHICLE The rear wiper/washer controls are located on the wind- NOTE: shield wiper/washer lever on the right side of the steering As a protective measure, the pump will stop if the switch is column. The rear wiper has different operation modes: held for more than 20 to 30 seconds.
Page 76: Climate Controls
74 GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Manual Climate Control Overview The Climate Control System allows you to regulate the temperature, air flow, and direction of air circulating throughout the vehicle. The controls are located on the touchscreen (if equipped) and on the instrument panel below the radio.
Page 77 GETTING TO KNOW YOUR VEHICLE Climate Controls Description Icon Description MAX A/C Setting Set the Temperature Control Knob to the MAX A/C Setting, to change the current setting to the coldest output of air. Moving the Temperature Control Knob away from the MAX A/C setting causes the MAX A/C operation to exit.
Page 78 76 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Defrost Button Push and release the Rear Defrost Control button to turn on the rear window defroster and the heated outside mirrors (if equipped). The Rear Defrost indicator illuminates when the rear window defroster is on.
Page 79 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed Bi-Level Mode through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
Page 80: Automatic Climate Control Overview
78 GETTING TO KNOW YOUR VEHICLE Automatic Climate Control Overview Uconnect 4 With 7-inch Display Automatic Climate Controls...
Page 81 GETTING TO KNOW YOUR VEHICLE Uconnect 4/4C NAV With 8.4-inch Display Automatic Climate Controls...
Page 82 80 GETTING TO KNOW YOUR VEHICLE Climate Controls Description Icon Description MAX A/C Button Press and release the MAX A/C button on the touchscreen to change the current setting to the coldest output of air. The MAX A/C indicator illuminates when MAX A/C is on. Pressing the button again will cause the MAX A/C operation to exit.
Page 83 GETTING TO KNOW YOUR VEHICLE Icon Description AUTO Button Press and release this button on the touchscreen, or push the button on the faceplate, to change the current setting. The AUTO indicator illuminates when AUTO is on. This feature automatically controls the interior cabin temperature by adjusting airflow distribution and amount.
Page 84 82 GETTING TO KNOW YOUR VEHICLE Icon Description Driver and Passenger Temperature Up and Down Buttons Provides the driver and passenger with independent temperature control. Push the red button on the faceplate or touchscreen or press and slide the temperature bar towards the red arrow button on the touchscreen for warmer temperature settings.
Page 85 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate Blower Blower Control Knob Blower Control is used to regulate the amount of air forced through the climate system. There are seven blower speeds available. Adjusting the blower will cause automatic mode to switch to manual operation.
Page 86 84 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate Mode Mode Control Button Mode Control regulates the airflow distribution. The airflow distribution outlets are: instrument panel outlets, floor outlets, defrost outlets, and demist outlets. Faceplate: Push the Mode Button to change the airflow distribution mode. Touchscreen: Press one of the “MODE”...
Page 87 GETTING TO KNOW YOUR VEHICLE Icon Description Floor Mode Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.
Page 88: Climate Control Functions
86 GETTING TO KNOW YOUR VEHICLE MAX A/C Climate Control Functions MAX A/C sets the control for maximum cooling perfor- A/C (Air Conditioning) mance. The Air Conditioning (A/C) button allows the operator to Press and release to toggle between MAX A/C and the prior manually activate or deactivate the air conditioning system.
Page 89: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE To provide you with maximum comfort in the Automatic Automatic Temperature Control (ATC) mode during cold start-ups, the blower fan remains on low Automatic Operation until the engine warms up. The blower increases in speed and transition into Auto mode.
Page 90 88 GETTING TO KNOW YOUR VEHICLE Winter Operation CAUTION! To ensure the best possible heater and defroster perfor- Failure to follow these cautions can cause damage to the mance, make sure the engine cooling system is functioning heating elements: properly and the proper amount, type, and concentration of •...
Page 91: Windows
GETTING TO KNOW YOUR VEHICLE WINDOWS Operating Tips Chart WEATHER CONTROL SETTINGS Power Window Controls The window controls on the driver's door control all the door Set the mode control to windows. on, and blower on high. Hot Weather And Vehicle Roll down the windows for Interior Is Very Hot a minute to flush out the hot...
Page 92: Auto-Down Feature
90 GETTING TO KNOW YOUR VEHICLE NOTE: To open the window part way, push the window switch down For vehicles equipped with the Uconnect, the power briefly and release it when you want the window to stop. window switches will remain active for up to 10 minutes To stop the window from going all the way down during the after the ignition is placed in the OFF position.
Page 93: Reset Auto-Up
GETTING TO KNOW YOUR VEHICLE button with turn on). To enable the window controls, push WARNING! and release the window lockout button again (the indicator There is no anti-pinch protection when the window is light on the button will turn back off). almost closed.
Page 94: Power Sunroof With Power Shade - If Equipped
92 GETTING TO KNOW YOUR VEHICLE and rear windows together to minimize the buffeting. If the WARNING! buffeting occurs with the sunroof open, adjust the sunroof • Never leave children unattended in a vehicle, or with opening to minimize the buffeting or open any window. access to an unlocked vehicle.
Page 95: Opening Sunroof
GETTING TO KNOW YOUR VEHICLE Opening Sunroof Opening Sunroof — Vent The sunroof has two programmed open positions, comfort Push and release the "Vent" button within one-half second stop position and full open position. The comfort stop posi- and the sunroof will move from the closed position to the tion has been optimized to minimize wind buffeting when vent position.
Page 96: Opening Power Shade
94 GETTING TO KNOW YOUR VEHICLE Manual Mode Manual Mode Pull and hold the switch down and the sunroof will close Push and hold the sunshade switch, the sunshade will open from any position. Any release of the switch will stop the to the half open position and stop automatically.
Page 97: Pinch Protect Feature
GETTING TO KNOW YOUR VEHICLE Manual Mode vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open Pull and hold the sunshade switch down. If the sunroof is in positions. This is a normal occurrence and can be minimized. closed position, the sunshade will fully close from any posi- If the buffeting occurs with the rear windows open, then tion.
Page 98: Hood
96 GETTING TO KNOW YOUR VEHICLE 2. Move to the outside of the vehicle. The safety latch release HOOD lever is located behind the front edge of the hood at the Opening The Hood center. Reach in at the center of the hood with a palm facing the ground.
Page 99: Closing The Hood
GETTING TO KNOW YOUR VEHICLE Closing The Hood LIFTGATE Opening WARNING! Be sure the hood is fully latched before driving your To Unlock/Enter The Liftgate vehicle. If the hood is not fully latched, it could open The liftgate may be released by the overhead console switch, when the vehicle is in motion and block your vision.
Page 100: Closing
98 GETTING TO KNOW YOUR VEHICLE NOTE: Use the interior door lock/unlock button on the door panel or the key fob to lock and unlock the liftgate. The manual door locks on the doors and the exterior door lock cylinder will not lock and unlock the liftgate.
Page 101: Power Liftgate - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: Power Liftgate — If Equipped • Before closing the liftgate, make sure to be in possession of The power liftgate may be opened or closed by the the key because the liftgate may be locked. key fob, outside handle, overhead console switch, and the liftgate switch on the upper left trim.
Page 102 100 GETTING TO KNOW YOUR VEHICLE NOTE: • Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- • The liftgate will not power open or close if the gear selector ture, it may be necessary to assist the props when opening is in gear or the vehicle speed is above 0 mph (0 km/h).
Page 103: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE Cargo Area Features WARNING! • Driving with the liftgate open can allow poisonous Cargo Load Floor exhaust gases into your vehicle. You and your passen- The cargo load floor system has a load capacity of 400 lbs gers could be injured by these fumes.
Page 104 102 GETTING TO KNOW YOUR VEHICLE To change the level of the load floor, pull upward on the load Raising The Load Floor floor handle, pull the floor outward, and place the back of the To raise the load floor for access of the Tire Service Kit, or floor into the desired position.
Page 105 GETTING TO KNOW YOUR VEHICLE To fully raise the load floor, pull upward on the floor handle, Cargo Tie-Down Hooks And Loops pull the floor outward, then position the floor upright with The tie-downs located on the cargo area floor should be used the bottom fitting on top of the floor positioning brackets.
Page 106 104 GETTING TO KNOW YOUR VEHICLE Rear Storage Bins WARNING! (Continued) The rear storage bins are located in the rear of the vehicle on • Do not carry loads that exceed the load limits described the sides of the load floor. on the label attached to the left door or left door center pillar.
Page 107: Internal Equipment
GETTING TO KNOW YOUR VEHICLE INTERNAL EQUIPMENT Storage Glove Compartment The glove compartment is located on the passenger side of the instrument panel. Glove Compartment To open the glove compartment, pull the release handle. WARNING! Do not operate this vehicle with a glove compartment in the open position.
Page 108: Cupholders
106 GETTING TO KNOW YOUR VEHICLE Console Storage Compartment WARNING! To open, pull up on the latch and lift the cover. Do not operate this vehicle with a console compartment lid in the open position. Driving with the console The center console armrest can also be adjusted forward and compartment lid open may result in injury in a collision.
Page 109: Power Outlets
GETTING TO KNOW YOUR VEHICLE There are two cupholders (if equipped) for the rear seat The front power outlet is located on the center stack of the passengers, located in the center armrest. instrument panel. Power Outlets Your vehicle is equipped with 12 Volt (13 Amp) power outlets that can be used to power cellular phones, small elec- tronics and other low powered electrical accessories.
Page 110 108 GETTING TO KNOW YOUR VEHICLE In addition to the front power outlet, there may also be a WARNING! power outlet located in the rear cargo area, if equipped. To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet.
Page 111: Power Inverter - If Equipped
GETTING TO KNOW YOUR VEHICLE current. This outlet can power cellular phones, electronics and CAUTION! (Continued) other low power devices requiring power up to 150 Watts. • After the use of high power draw accessories, or long Certain high-end game consoles will exceed this power limit, periods of the vehicle not being started (with accesso- as will most power tools.
Page 112: Roof Luggage Rack - If Equipped
110 GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED CAUTION! • To avoid damage to the roof rack and vehicle, do not The load carried on the roof, when equipped with a luggage exceed the maximum roof rack load capacity. Always rack, must not exceed 150 lbs (68 kg), and it should be distribute heavy loads as evenly as possible and secure uniformly distributed over the cargo area.
Page 113: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Base Instrument Cluster...
Page 114: Instrument Cluster Descriptions
112 GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Instrument Cluster 2. Instrument Cluster Display Instrument Cluster Descriptions 1. Tachometer •The instrument cluster display features a driver-interac- tive display. Refer to “Instrument Cluster Display” in •Indicates the engine speed in revolutions per minute this chapter for further information.
Page 115 GETTING TO KNOW YOUR INSTRUMENT PANEL 3. Speedometer WARNING! A hot engine cooling system is dangerous. You or others •Indicates vehicle speed. could be badly burned by steam or boiling coolant. You 4. Fuel Gauge may want to call an authorized dealer for service if your vehicle overheats.
Page 116: Instrument Cluster Display
114 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY Instrument Cluster Display Location And Controls Your vehicle may be equipped with an instrument cluster The instrument cluster display features a driver interactive display, which offers useful information to the driver. With display that is located in the instrument cluster.
Page 117 GETTING TO KNOW YOUR INSTRUMENT PANEL The instrument cluster display menu items consist of the following as equipped: • Speedometer • Vehicle Info • Driver Assist • Fuel Economy • Trip • Stop/Start (If Equipped) • Audio • Messages Premium Instrument Cluster Display Location And Controls •...
Page 118: Oil Change Reset
116 GETTING TO KNOW YOUR INSTRUMENT PANEL The systems allow the driver to select information by • Right Arrow Button pushing the following buttons mounted on the steering Push and release the right arrow button to access wheel: the information screens or submenu screens of a main menu item.
Page 119: Instrument Cluster Display Menu Items
GETTING TO KNOW YOUR INSTRUMENT PANEL To reset the oil change indicator after performing the sched- Vehicle Info (Customer Information Features) uled maintenance, refer to the following procedure: Push and release the up or down arrow button until the 1. Without pressing the brake pedal, push the ENGINE Vehicle Info Menu item is displayed in the instrument cluster START/STOP button and cycle the ignition to the ON/ display.
Page 120 118 GETTING TO KNOW YOUR INSTRUMENT PANEL 2. Coolant Temperature and a new Range value will display. Range cannot be reset through the OK button. Displays the actual coolant temperature. NOTE: 3. Transmission Temperature — Automatic Transmission Significant changes in driving style or vehicle loading will Only greatly affect the actual drivable distance of the vehicle, regardless of the Range displayed value.
Page 121 GETTING TO KNOW YOUR INSTRUMENT PANEL Trip Info Stored Messages Push and release the up or down arrow button until the Trip Push and release the up or down arrow button until the menu title is displayed in the instrument cluster display. Messages Menu Icon is highlighted in the instrument cluster Toggle the left or right arrow button to select Trip A or Trip display.
Page 122 120 GETTING TO KNOW YOUR INSTRUMENT PANEL Screen Setup Driver Selectable Items Upper Right • None Upper Left • Compass • None • Outside Temp • Compass (default setting) • Date • Outside Temp • Time • Date • Ignition State (default setting) •...
Page 123 GETTING TO KNOW YOUR INSTRUMENT PANEL Center • Display • None • Units • Compass • Clock and Date • Menu Title (default setting) • Security • Date • Safety and Assistance • Outside Temp • Lights • Time • Doors and Locks •...
Page 124 122 GETTING TO KNOW YOUR INSTRUMENT PANEL Units Safety And Assistance By selecting Units, the unit of measurement to use for By selecting the item Safety and Assistance, the following displaying various values can be set. Possible options are: adjustments can be made: •...
Page 125 GETTING TO KNOW YOUR INSTRUMENT PANEL • LaneSense Warning (If Equipped): a selection of the “read- Lights iness” of intervention of LaneSense By selecting Lights, the following adjustments can be made: • Buzzer Volume: There are 4 options: Off, Low, Medium, •...
Page 126 124 GETTING TO KNOW YOUR INSTRUMENT PANEL Doors And Locks • Auto Driver Comfort (If Equipped): activate/deactivate automatic climate control during vehicle starts By selecting Doors and Locks, the following adjustments can • Key in Memory (If Equipped): activate/deactivate be made: memory linked to a key •...
Page 127: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Variance (If Equipped) Battery Saver On/Battery Saver Mode Message — Electrical Load Reduction Actions — If Equipped Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences, This vehicle is equipped with an Intelligent Battery Sensor the variance should be set for the zone where the vehicle is (IBS) to perform additional monitoring of the electrical driven, per the zone map.
Page 128 126 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: • The charging system cannot deliver enough electrical power to the vehicle system because the electrical loads are • The charging system is independent from load reduction. larger than the capability of charging system. The charging The charging system performs a diagnostic on the system is still functioning properly.
Page 129: Trip Computer
GETTING TO KNOW YOUR INSTRUMENT PANEL What to do when an electrical load reduction action TRIP COMPUTER message is present (“Battery Saver On” or “Battery Saver Push and release the up or down arrow button until the Trip Mode”) A or Trip B icon is highlighted in the instrument cluster During a trip: display (Toggle left or right to select Trip A or Trip B).
Page 130: Warning Lights And Messages
128 GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES Brake Warning Light This warning light monitors various brake func- The warning/indicator lights will illuminate in the instru- tions, including brake fluid level and parking brake ment panel together with a dedicated message and/or application.
Page 131 GETTING TO KNOW YOUR INSTRUMENT PANEL The light will remain on until the cause is corrected. Operation of the Brake Warning Light can be checked by turning the ignition switch from the OFF position to the ON/ NOTE: RUN position. The light should illuminate for approximately The light may flash momentarily during sharp cornering two seconds.
Page 132 130 GETTING TO KNOW YOUR INSTRUMENT PANEL Door Open Warning Light Electronic Throttle Control (ETC) Warning Light This indicator will illuminate when a door is ajar/ This warning light will illuminate to indicate a open and not fully closed. problem with the Electronic Throttle Control (ETC) system.
Page 133 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Temperature Warning Light Liftgate Open Warning Light This warning light will illuminate to warn of an This warning light will illuminate when the liftgate overheated engine condition. If the engine coolant is open. temperature is too high, this light will illuminate and a single chime will sound.
Page 134 132 GETTING TO KNOW YOUR INSTRUMENT PANEL slightly faster, with the transmission in PARK or NEUTRAL, Seat Belt Reminder Warning Light until the light turns off. Once the light turns off, you may This warning light indicates when the driver or continue to drive normally.
Page 135: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Yellow Warning Lights Electronic Stability Control (ESC) Active Warning Light — If Equipped Anti-Lock Brake (ABS) Warning Light This warning light will indicate when the Electronic This warning light monitors the Anti-Lock Brake Stability Control (ESC) system is Active. The “ESC System (ABS).
Page 136 134 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) OFF Warning Light — Service LaneSense Warning Light — If Equipped If Equipped This warning light will illuminate when the Lane- This warning light indicates the Electronic Stability Sense system is not operating and requires service. Control (ESC) is off.
Page 137 GETTING TO KNOW YOUR INSTRUMENT PANEL nate when the ignition is in the ON/RUN position before CAUTION! engine start. If the bulb does not come on when turning the Prolonged driving with the Malfunction Indicator Light ignition switch from OFF to ON/RUN, have the condition (MIL) on could cause damage to the vehicle control checked promptly.
Page 138 136 GETTING TO KNOW YOUR INSTRUMENT PANEL Each tire, including the spare (if provided), should be Service Stop/Start System Warning Light — If Equipped checked monthly when cold and inflated to the inflation This warning light will illuminate when the Stop/ pressure recommended by the vehicle manufacturer on the Start system is not functioning properly and service vehicle placard or tire inflation pressure label.
Page 139 GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a TPMS malfunc- CAUTION! tion indicator to indicate when the system is not operating The TPMS has been optimized for the original properly. The TPMS malfunction indicator is combined with equipment tires and wheels.
Page 140: Yellow Indicator Lights
138 GETTING TO KNOW YOUR INSTRUMENT PANEL Yellow Indicator Lights Forward Collision Indicator Light — If Equipped This telltale will turn on to warn you of a possible 4WD Low Indicator Light — If Equipped collision with the vehicle in front of you. This light alerts the driver that the vehicle is in the four-wheel drive LOW mode.
Page 141: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL flash. Turn signals can be activated when the multifunction Green Indicator Lights lever is moved down (left) or up (right). LaneSense Indicator Light — If Equipped NOTE: The LaneSense indicator light illuminates solid • A continuous chime will sound if the vehicle is driven green when both lane markings have been detected more than 1 mile (1.6 km) with either turn signal on.
Page 142: White Indicator Lights
140 GETTING TO KNOW YOUR INSTRUMENT PANEL White Indicator Lights Cruise Control Ready Indicator Light — If Equipped With A Premium Instrument Cluster LaneSense Indicator Light — If Equipped This light will turn on when the speed control has When the LaneSense system is ON, but not armed, been turned on, but not set.
Page 143: Gray Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Gray Indicator Lights CAUTION! • Prolonged driving with the MIL on could cause further Cruise Control Ready Indicator Light — If Equipped With damage to the emission control system. It could also Base Instrument Cluster affect fuel economy and driveability.
Page 144: Emissions Inspection And Maintenance Programs
142 GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND MAINTENANCE WARNING! PROGRAMS • ONLY an authorized service technician should connect equipment to the OBD II connection port in order to In some localities, it may be a legal requirement to pass an read the VIN, diagnose, or service your vehicle.
Page 145 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: If your OBD II system is not ready, you should see an autho- If you crank or start the engine, you will have to start this test rized dealer or repair facility. If your vehicle was recently over.
Page 146: Safety
SAFETY You also may experience the following when ABS activates: SAFETY FEATURES • The ABS motor noise (it may continue to run for a short Anti-Lock Brake System (ABS) time after the stop) The Anti-Lock Brake System (ABS) provides increased •...
Page 147 SAFETY Anti-Lock Brake Warning Light WARNING! (Continued) • Pumping of the Anti-Lock Brakes will diminish their The yellow “Anti-Lock Brake Warning Light” will turn on when the ignition is placed in the ON/RUN mode and may effectiveness and may lead to a collision. Pumping makes the stopping distance longer.
Page 148: Electronic Brake Control (Ebc) System
146 SAFETY axle. If one wheel on a driven axle is spinning faster than the Electronic Brake Control (EBC) System other, the system will apply the brake of the spinning wheel. Your vehicle is equipped with an advanced Electronic Brake This will allow more vehicle torque to be applied to the Control (EBC) system.
Page 149 SAFETY Dynamic Steering Torque (DST) WARNING! The Brake Assist System (BAS) cannot prevent the Dynamic Steering Torque (DST) is a feature of the Electronic natural laws of physics from acting on the vehicle, nor Stability Control (ESC) and Electric Power Steering (EPS) can it increase the traction afforded by prevailing road modules that provides torque at the steering wheel for conditions.
Page 150 148 SAFETY Electronic Brake Force Distribution (EBD) WARNING! The Electronic Brake Force Distribution (EBD) function Many factors, such as vehicle loading, road conditions manages the distribution of the braking torque between the and driving conditions, influence the chance that wheel front and rear axles by limiting braking pressure to the rear lift or rollover may occur.
Page 151 SAFETY ESC uses sensors in the vehicle to determine the vehicle path WARNING! intended by the driver and compares it to the actual path of • Electronic Stability Control (ESC) cannot prevent the the vehicle. When the actual path does not match the natural laws of physics from acting on the vehicle, nor intended path, ESC applies the brake of the appropriate can it increase the traction afforded by prevailing road...
Page 152 150 SAFETY WARNING! (Continued) • Vehicle modifications, or failure to properly maintain your vehicle, may change the handling characteristics of your vehicle, and may negatively affect the perfor- mance of the ESC system. Changes to the steering system, suspension, braking system, tire type and size or wheel size may adversely affect ESC performance.
Page 153 SAFETY Partial Off WARNING! The “Partial Off” mode is intended for times when a more • When in “Partial Off” mode, the TCS functionality of spirited driving experience is desired. This mode may ESC, (except for the limited slip feature described in modify TCS and ESC thresholds for activation, which allows the TCS section), has been disabled and the “ESC OFF for more wheel spin than normally allowed.
Page 154 152 SAFETY In this mode, ESC and TCS, except for the “limited slip” WARNING! feature described in the TCS section, are turned off until the In the "Full Off" mode, the engine torque reduction and vehicle reaches a speed of 40 mph (64 km/h). At 40 mph stability features are disabled.
Page 155 SAFETY tion/Malfunction Indicator Light” begins to flash during Hill Descent Control (HDC) — If Equipped acceleration, ease up on the accelerator and apply as little throttle as possible. Be sure to adapt your speed and driving to the prevailing road conditions. NOTE: •...
Page 156 154 SAFETY HDC has three states: Driver Override: 1. Off (feature is not enabled and will not activate). The driver may override HDC activation speed with throttle or brake application at anytime. 2. Enabled (feature is enabled and ready but activation conditions are not met, or driver is actively overriding Deactivating HDC with brake or throttle application).
Page 157 SAFETY Feedback To The Driver: will continue to hold the brake pressure for a short period. If the driver does not apply the throttle before this time expires, The instrument cluster has an HDC icon and the HDC switch the system will release brake pressure and the vehicle will has an LED, which offer feedback to the driver about the roll down the hill as normal.
Page 158 156 SAFETY WARNING! WARNING! There may be situations where the Hill Start Assist • If you use a trailer brake controller with your trailer, the (HSA) will not activate and slight rolling may occur, trailer brakes may be activated and deactivated with such as on minor hills or with a loaded vehicle, or while the brake switch.
Page 159: Auxiliary Driving Systems
SAFETY NOTE: Rain Brake Support (RBS) TSC cannot stop all trailers from swaying. Always use Rain Brake Support (RBS) may improve braking perfor- caution when towing a trailer and follow the trailer tongue mance in wet conditions. It will periodically apply a small weight recommendations.
Page 160 158 SAFETY motorcycles, etc.) that enter the blind spot zones from the mately 10 ft (3 m) beyond the rear bumper of the vehicle. The rear/front/side of the vehicle. BSM system monitors the detection zones on both sides of the vehicle when the vehicle speed reaches approximately 6 mph (10 km/h) or higher and will alert the driver of vehi- cles in these areas.
Page 161 SAFETY The area on the rear fascia where the radar sensors are present on the same side at the same time, both the visual located must remain free of snow, ice, and dirt/road contam- and audio alerts will be issued. In addition to the audible ination so that the BSM system can function properly.
Page 162 160 SAFETY Entering From The Side Entering From The Rear Vehicles that move into your adjacent lanes from either side Vehicles that come up from behind your vehicle on either of the vehicle. side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h).
Page 163 SAFETY Overtaking Traffic If you pass another vehicle slowly with a relative speed less than 10 mph (16 km/h) and the vehicle remains in the blind spot for approximately 1.5 seconds, the warning light will be illuminated. If the difference in speed between the two vehi- cles is greater than 10 mph (16 km/h), the warning light will not illuminate.
Page 164 162 SAFETY The BSM system is designed not to issue an alert on The BSM system will not alert you of objects that are trav- stationary objects such as guardrails, posts, walls, foliage, eling in the opposite direction of the vehicle in adjacent berms, etc.
Page 165 SAFETY the vehicle is exposed. The RCP system will then have a clear WARNING! view of the cross traffic and if an oncoming vehicle is The Blind Spot Monitoring system is only an aid to help detected, alert the driver. detect objects in the blind spot zones.
Page 166 164 SAFETY NOTE: Modes Of Operation In a parking lot situation, oncoming vehicles can be obscured Three selectable modes of operation are available in the by vehicles parked on either side. If the sensors are blocked Uconnect System. Refer to “Uconnect Settings” in “Multi- by other structures or vehicles, the system will not be able to media”...
Page 167 SAFETY NOTE: blockage. After removing the blockage, reset the system by Whenever an audible alert is requested by the BSM system, cycling the ignition from ON to OFF and then back ON. the radio is also muted. General Information When the system is in RCP, the system shall respond with The following regulatory statement applies to all Radio both visual and audible alerts when a detected object is Frequency (RF) devices equipped in this vehicle:...
Page 168: Forward Collision Warning (Fcw) With Mitigation - If Equipped
166 SAFETY La operación de este equipo está sujeta a las siguientes dos NOTE: condiciones: FCW monitors the information from the forward looking sensors as well as the Electronic Brake Controller (EBC), to 1. es posible que este equipo o dispositivo no cause interfer- calculate the probability of a forward collision.
Page 169 SAFETY • It is unsafe to test the FCW system. To prevent such misuse of the system, after four Active Braking events within a key cycle, the Active Braking portion of FCW will be deac- tivated until the next key cycle. •...
Page 170 168 SAFETY FCW Settings Changing FCW Sensitivity And Operating Status The Forward Collision menu setting is located in the Ucon- The FCW Sensitivity And Operation Settings are program- nect settings. mable through the Uconnect System. Refer to “Uconnect Settings” in “Multimedia” for further information. NOTE: The default status of FCW is “Full On,”...
Page 171 SAFETY NOTE: Service FCW Warning • The system will retain the last setting selected by the driver If the system turns off, and the instrument cluster display after ignition shut down. reads “FCW Unavailable Service Required”, there is an • FCW may not react to irrelevant objects such as overhead internal system fault.
Page 172: Tire Pressure Monitoring System (Tpms)
170 SAFETY Le présent appareil est conforme aux CNR d`Innovation, Tire Pressure Monitoring System (TPMS) Science and Economic Development applicables aux appar- The Tire Pressure Monitoring System (TPMS) will warn the eils radio exempts de licence. L'exploitation est autorisée aux driver of a low tire pressure based on the vehicle recom- deux conditions suivantes: mended cold placard pressure.
Page 173 SAFETY NOTE: NOTE: When filling warm tires, the tire pressure may need to be Once the low tire pressure warning (Tire Pressure Moni- increased up to an additional 4 psi (28 kPa) above the recom- toring System Warning Light) illuminates, you must increase mended cold placard pressure in order to turn the Tire Pres- the tire pressure to the recommended cold placard pressure sure Monitoring System Warning Light off.
Page 174 172 SAFETY NOTE: as part of the valve stem, transmit tire pressure readings to the receiver module. • The TPMS is not intended to replace normal tire care and maintenance, or to provide warning of a tire failure or NOTE: condition.
Page 175 SAFETY NOTE: When filling warm tires, the tire pressure may need to be increased up to an additional 4 psi (28 kPa) above the recom- mended cold placard pressure in order to turn the Tire Pres- sure Monitoring System Warning Light off. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this information.
Page 176 174 SAFETY message will no longer display, and a pressure value will the graphic in the instrument cluster will still display a display in place of the dashes. A system fault can occur due different color or highlighted pressure value and the to any of the following: “Inflate to XX”...
Page 177 SAFETY tires. The vehicle may need to be driven for up to To reactivate the TPMS, replace all four wheel and tire assem- 20 minutes above 15 mph (24 km/h) in order for the blies (road tires) with tires equipped with TPM sensors. Then, TPMS to receive this information.
Page 178: Occupant Restraint Systems
176 SAFETY Le présent appareil est conforme aux CNR d`Innovation, OCCUPANT RESTRAINT SYSTEMS Science and Economic Development applicables aux appar- Some of the most important safety features in your vehicle eils radio exempts de licence. L'exploitation est autorisée aux are the restraint systems: deux conditions suivantes: Occupant Restraint Systems Features 1.
Page 179 SAFETY Here are some simple steps you can take to minimize the risk 7. The driver and front passenger seats should be moved of harm from a deploying air bag: back as far as practical to allow the front air bags room to inflate.
Page 180: Seat Belt Systems
178 SAFETY Initial Indication Seat Belt Systems If the driver is unbuckled when the ignition switch is first in Buckle up even though you are an excellent driver, even on the START or ON/RUN position, a chime will signal for a short trips.
Page 181 SAFETY Change of Status Lap/Shoulder Belts If the driver or outboard front seat passenger (if equipped All seating positions in your vehicle are equipped with lap/ with outboard front passenger seat BeltAlert) unbuckles shoulder belts. their seat belt while the vehicle is traveling, the BeltAlert The seat belt webbing retractor will lock only during very warning sequence will begin until the seat belts are buckled sudden stops or collisions.
Page 182 180 SAFETY WARNING! WARNING! (Continued) • A lap belt worn too high can increase the risk of injury • It is dangerous to ride in a cargo area, inside or outside in a collision. The seat belt forces won’t be at the strong of a vehicle.
Page 183 SAFETY Lap/Shoulder Belt Operating Instructions WARNING! (Continued) • A seat belt that is worn under your arm is dangerous. 1. Enter the vehicle and close the door. Sit back and adjust the seat. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury.
Page 184 182 SAFETY 3. When the seat belt is long enough to fit, insert the latch plate into the buckle until you hear a “click”. Positioning The Lap Belt 5. Position the shoulder belt across the shoulder and chest with minimal, if any slack so that it is comfortable and not Inserting Latch Plate Into Buckle resting on your neck.
Page 185 SAFETY Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the seat belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 186 184 SAFETY pushing or squeezing the release button. To verify the Second Row Center Seat Belt Operating Instructions shoulder belt anchorage is latched, pull downward on the The second row center seat belt may feature a seat belt with shoulder belt anchorage until it is locked into position. a mini-latch plate and buckle.
Page 187 SAFETY 2. When the seat belt is long enough to fit, insert the 4. When the seat belt is long enough to fit, insert the latch mini-latch plate into the mini-buckle until you hear a plate into the buckle until you hear a “click.” “click.”...
Page 188 186 SAFETY 6. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the seat belt. 7. To release the seat belt, push the red button on the buckle. 8.
Page 189 SAFETY WARNING! WARNING! • If the mini-latch plate and mini-buckle are not properly • ONLY use a Seat Belt Extender if it is physically connected when the seat belt is used by an occupant, required in order to properly fit the original seat belt the seat belt will not be able to provide proper restraint system.
Page 190 188 SAFETY Seat Belts And Pregnant Women Seat Belt Pretensioner The front outboard seat belt system is equipped with preten- sioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices may improve the performance of the seat belt by removing slack from the seat belt early in a collision.
Page 191 SAFETY If the passenger seating position is equipped with an ALR Switchable Automatic Locking Retractors (ALR) and is being used for normal usage, only pull the seat belt The seat belts in the passenger seating positions are webbing out far enough to comfortably wrap around the equipped with a Switchable Automatic Locking Retractor occupant’s mid-section so as to not activate the ALR.
Page 192 190 SAFETY How To Disengage The Automatic Locking Mode WARNING! • Never place a rear-facing child restraint in front of an Unbuckle the combination lap/shoulder belt and allow it to air bag. A deploying passenger front air bag can cause retract completely to disengage the Automatic Locking death or serious injury to a child 12 years or younger, Mode and activate the vehicle sensitive (emergency) locking...
Page 193: Supplemental Restraint Systems (Srs)
SAFETY • Supplemental Side Air Bags Supplemental Restraint Systems (SRS) • Supplemental Knee Air Bags Some of the safety features described in this section may be standard equipment on some models, or may be optional • Front and Side Impact Sensors equipment on others.
Page 194 192 SAFETY The ORC turns on the Air Bag Warning Light in the instru- • The Air Bag Warning Light remains on after the four to ment panel for approximately four to eight seconds for a eight-second interval. self-check when the ignition switch is first in the ON/RUN •...
Page 195 SAFETY The passenger front air bag is mounted in the instrument Redundant Air Bag Warning Light panel, above the glove compartment. The words “SRS If a fault with the Air Bag Warning Light is detected, AIRBAG” or “AIRBAG” are embossed on the air bag covers. which could affect the Supplemental Restraint System (SRS), the Redundant Air Bag Warning Light will illuminate on the instrument panel.
Page 196 194 SAFETY may receive information from the front impact sensors (if WARNING! equipped) or other system components. • Being too close to the steering wheel or instrument panel during front air bag deployment could cause The first stage inflator is triggered immediately during an serious injury, including death.
Page 197 SAFETY vehicle damage — for example, some pole collisions, truck WARNING! underrides, and angle offset collisions. • No objects should be placed over or near the air bag on the instrument panel or steering wheel because any On the other hand, depending on the type and location of such objects could cause harm if the vehicle is in a colli- impact, front air bags may deploy in crashes with little sion severe enough to cause the air bag to inflate.
Page 198 196 SAFETY the ORC. The ORC may reduce the inflation rate of the Occupant Classification System (OCS) — Front Passenger Advanced Front Air Bag deployment based on Passenger Seat occupant classification. In order for the OCS to operate as The Occupant Classification System (OCS) is part of a Feder- designed, it is important for the front passenger to be seated ally regulated safety system for this vehicle.
Page 199 SAFETY Front Passenger Seat Front Passenger Air Bag WARNING! Occupant Status Output • Never place a rear-facing child restraint in front of an Reduced-power air bag. A deploying passenger front air bag can cause Rear-facing child restraint deployment death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint.
Page 200 198 SAFETY In order for the OCS to operate as designed, it is important Lighter Weight Passengers (Including Small Adults) for the front passenger to be seated properly and properly When a lighter weight passenger, including a small adult, wearing the seat belt. Properly seated passengers are: occupies the front passenger seat, the OCS may reduce the •...
Page 201 SAFETY Examples of improper front passenger seating include: The OCS determines the front passenger’s most probable classification. If an occupant in the front passenger seat is • The front passenger’s weight is transferred to another part seated improperly, the occupant may provide an output of the vehicle (like the door, arm rest or instrument panel).
Page 202 200 SAFETY Not Seated Properly Not Seated Properly...
Page 203 SAFETY WARNING! (Continued) • Always wear your seat belt and sit properly, with the seatback in an upright position, your back against the seatback, sitting upright, facing forward, in the center of the seat, with your feet comfortably on or near the floor.
Page 204 202 SAFETY The following requirements must be strictly followed: The Air Bag Warning Light in the instrument panel will turn on whenever the OCS is unable to classify the front • Do not modify the front passenger seat assembly or passenger seat status.
Page 205 SAFETY WARNING! WARNING! • Unapproved modifications or service procedures to the • Do not drill, cut, or tamper with the knee impact passenger seat assembly, its related components, seat bolsters in any way. cover or cushion may inadvertently change the air bag •...
Page 206 204 SAFETY Supplemental Side Air Bags Supplemental Seat-Mounted Side Air Bags (SABs) This vehicle is equipped with Supplemental Seat-Mounted Side Air Bags (SABs). Supplemental Seat-Mounted Side Air Bags (SABs) are located in the outboard side of the front seats. The SABs are marked with “SRS AIRBAG”...
Page 207 SAFETY WARNING! Do not use accessory seat covers or place objects between you and the Side Air Bags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury. Supplemental Side Air Bag Inflatable Curtains (SABICs) This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains (SABICs).
Page 208 206 SAFETY The SABIC deploys downward, covering the side windows. Side Impacts An inflating SABIC pushes the outside edge of the headliner The Side Air Bags are designed to activate in certain side out of the way and covers the window. The SABICs inflate impacts.
Page 209 SAFETY WARNING! WARNING! (Continued) • Occupants, including children, who are up against or • Relying on the Side Air Bags alone could lead to more very close to Side Air Bags can be seriously injured or severe injuries in a collision. The Side Air Bags work killed.
Page 210 208 SAFETY The Side Air Bags and seat belt pretensioners will not deploy • Knee Impact Bolsters in all rollover events. The rollover sensing system deter- • Driver and Front Passenger Air Bags mines if a rollover event may be in progress and whether •...
Page 211 SAFETY If you do have a collision which deploys the air bags, any or Do not drive your vehicle after the air bags have deployed. If all of the following may occur: you are involved in another collision, the air bags will not be in place to protect you.
Page 212 210 SAFETY • Cut off battery power to the: Enhanced Accident Response System • Engine In the event of an impact, if the communication network • Electric Motor (if equipped) remains intact, and the power remains intact, depending on the nature of the event, the Occupant Restraint Controller •...
Page 213 SAFETY Enhanced Accident Response System Reset Procedure After the event occurs, when the system is active, a message regarding fuel cutoff is displayed. Turn the ignition switch from ignition AVV/START or MAR/ACC/ON/RUN to ignition STOP/OFF/LOCK. Carefully check the vehicle for fuel leaks in the engine compartment and on the ground near the engine compartment and fuel tank before resetting the system and starting the engine.
Page 214 212 SAFETY Customer Will See Customer Action NOTE: Each step MUST BE held for at least two seconds Right turn light BLINKS. 6. Place turn signal in neutral state. Left turn light is OFF. Right turn light is ON SOLID. 7.
Page 215 SAFETY Maintaining Your Air Bag System WARNING! (Continued) • Do not attempt to modify any part of your air bag WARNING! system. The air bag may inflate accidentally or may not • Modifications to any part of the air bag system could function properly if modifications are made.
Page 216: Child Restraints
214 SAFETY for a short period of time, typically 30 seconds or less. The To read data recorded by an EDR, special equipment is EDR in this vehicle is designed to record such data as: required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as •...
Page 217 SAFETY NOTE: WARNING! • For additional information, refer http:// In a collision, an unrestrained child can become a www.nhtsa.gov/parents-and-caregivers call: projectile inside the vehicle. The force required to hold 1–888–327–4236 even an infant on your lap could become so great that you could not hold the child, no matter how strong you •...
Page 218 216 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Recommended Type Of Child Child Size, Height, Weight Or Age Restraint Children who are two years old or Either an Infant Carrier or a Convertible younger and who have not reached the Infants and Toddlers Child Restraint, facing rearward in a height or weight limits of their child...
Page 219 SAFETY Infant And Child Restraints WARNING! • Never place a rear-facing child restraint in front of an Safety experts recommend that children ride rear-facing in the vehicle until they are two years old or until they reach air bag. A deploying passenger front air bag can cause death or serious injury to a child 12 years or younger, either the height or weight limit of their rear-facing child restraint.
Page 220 218 SAFETY Older Children And Child Restraints WARNING! Children who are two years old or who have outgrown their • Improper installation can lead to failure of an infant or rear-facing convertible child seat can ride forward-facing in child restraint. It could come loose in a collision. The the vehicle.
Page 221 SAFETY If the answer to any of these questions was “no,” then the Children Too Large For Booster Seats child still needs to use a booster seat in this vehicle. If the Children who are large enough to wear the shoulder belt child is using the lap/shoulder belt, check seat belt fit peri- comfortably, and whose legs are long enough to bend over odically and make sure the seat belt buckle is latched.
Page 222 220 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight LATCH – Lower Restraint Type of the Child + LATCH – Lower Seat Belt + Top Seat Belt Only Anchors + Top Child Restraint Anchors Only Tether Anchor...
Page 223 SAFETY these seating positions, the seat belt must be used with the Lower Anchors And Tethers For CHildren (LATCH) top tether anchorage to install the child restraint. Please see Restraint System the following table for more information. LATCH Positions For Installing Child Restraints In This Vehicle LATCH Label Your vehicle is equipped with the child restraint anchorage...
Page 224 222 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the What is the weight limit (child’s weight combined weight of the child and the child + weight of the child restraint) for using 65 lbs (29.5 kg) restraint is 65 lbs (29.5 kg).
Page 225 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Never “share” a LATCH anchorage with two or more child restraints. If the center position does Can two child restraints be attached not have dedicated LATCH lower anchorages, use using a common lower LATCH the seat belt to install a child seat in the center anchorage? position next to a child seat using the LATCH...
Page 226 224 SAFETY Locating The LATCH Anchorages Locating The Upper Tether Anchorages The lower anchorages are round bars that are found There are tether strap anchorages behind each rear at the rear of the seat cushion where it meets the seat- seating position located on the back of the seat.
Page 227 SAFETY Center Seat LATCH To Install A LATCH-Compatible Child Restraint Do not install child restraints with rigid lower attachments in If the selected seating position has a Switchable Automatic the center seating position. Only install this type of child Locking Retractor (ALR) seat belt, stow the seat belt, restraint in the outboard seating positions.
Page 228 226 SAFETY 5. Tighten all of the straps as you push the child restraint WARNING! rearward and downward into the seat. Remove slack in • Improper installation of a child restraint to the LATCH the straps according to the child restraint manufacturer’s anchorages can lead to failure of the restraint.
Page 229 SAFETY The seat belts in the passenger seating positions are Lap/Shoulder Belt Systems For Installing Child equipped with a Switchable Automatic Locking Retractor Restraints In This Vehicle (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint so that it is not necessary to use a locking clip.
Page 230 228 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s Always use the tether anchor when using the weight + weight of the child seat belt to install a forward facing child restraint) for using the Tether Weight limit of the Child Restraint restraint, up to the recommended weight limit...
Page 231 SAFETY 2. Pull enough of the seat belt webbing from the retractor to Installing A Child Restraint With A Switchable Automatic pass it through the belt path of the child restraint. Do not Locking Retractor (ALR): twist the belt webbing in the belt path. Child restraint systems are designed to be secured in vehicle seats by lap belts or the lap belt portion of a lap/shoulder 3.
Page 232 230 SAFETY 8. If the child restraint has a top tether strap and the seating Installing Child Restraints Using The Top Tether position has a top tether anchorage, connect the tether Anchorage: strap to the anchorage and tighten the tether strap. See the WARNING! section “Installing Child Restraints Using the Top Tether Anchorage”...
Page 233 SAFETY 1. Look behind the seating position where you plan to install the child restraint to find the tether anchorage. You may need to move the seat forward to provide better access to the tether anchorage. If there is no top tether anchorage for that seating position, move the child restraint to another position in the vehicle if one is avail- able.
Page 234: Transporting Pets
232 SAFETY Transporting Pets Exhaust Gas Air Bags deploying in the front seat could harm your pet. An WARNING! unrestrained pet will be thrown about and possibly injured, Exhaust gases can injure or kill. They contain carbon or injure a passenger during panic braking or in a collision. monoxide (CO), which is colorless and odorless.
Page 235: Safety Checks You Should Make Inside The Vehicle
SAFETY Whenever a change is noticed in the sound of the exhaust Air Bag Warning Light system, when exhaust fumes can be detected inside the The Air Bag warning light will turn on for four to eight vehicle, or when the underside or rear of the vehicle is seconds as a bulb check when the ignition switch is first damaged, have a competent mechanic inspect the complete turned to ON/RUN.
Page 236 234 SAFETY is securely attached using the floor mat fasteners so it cannot WARNING! (Continued) slip out of position and interfere with the accelerator, brake • ONLY install floor mats designed to fit your vehicle. or clutch pedals or impair safe operation of your vehicle in NEVER install a floor mat that cannot be properly other ways.
Page 237: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY cracks. Inspect sidewalls for cuts, cracks, and bulges. Check WARNING! (Continued) the wheel nuts for tightness. Check the tires (including • NEVER place any objects under the floor mat (e.g., spare) for proper cold inflation pressure. towels, keys, etc.). These objects could change the posi- tion of the floor mat and may cause interference with Lights the accelerator, brake, or clutch pedals.
Page 238: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE WARNING! (Continued) • Do not leave the key fob in or near the vehicle, or in a Before starting your vehicle, adjust your seat, adjust both location accessible to children, and do not leave the inside and outside mirrors, and fasten your seat belts.
Page 239: Normal Starting
STARTING AND OPERATING Normal Starting Automatic Transmission NOTE: The gear selector must be in the NEUTRAL or PARK posi- tion before you can start the engine. Apply the brakes before Normal starting of either a cold or a warm engine is obtained without pumping or pressing the accelerator pedal.
Page 240 238 STARTING AND OPERATING Keyless Enter-N-Go Functions — Using The ENGINE vehicle and use the accessories follow these steps starting START/STOP Button with the ignition switch in the OFF position: 1. The transmission must be in PARK or NEUTRAL. 1. Push the ENGINE START/STOP button once to change the ignition switch to the RUN position, 2.
Page 241: Cold Weather Operation (Below -22°F Or −30°C)
STARTING AND OPERATING 4. If you wish to stop the cranking of the engine prior to the Cold Weather Operation (Below –22°F Or −30°C) engine starting, push the ENGINE START/STOP button To ensure reliable starting at these temperatures, use of an again.
Page 242: After Starting - Warming Up The Engine
240 STARTING AND OPERATING CAUTION! WARNING! To prevent damage to the starter, do not crank • Never pour fuel or other flammable liquid into the continuously for more than 10 seconds at a time. Wait 10 throttle body air inlet opening in an attempt to start the to 15 seconds before trying again.
Page 243: Engine Block Heater - If Equipped
STARTING AND OPERATING within a few seconds. The engine will shut down, and the For ambient temperatures below 0°F (-18°C), the engine ignition will be placed in the RUN position. block heater is recommended. For ambient temperatures below -20°F (-29°C), the engine block heater is required. Turning off the car (placing the ignition from the RUN posi- tion to the STOP position), the power supply to the accesso- The engine block heater cord is routed under the hood,...
Page 244: Engine Break-In Recommendations
242 STARTING AND OPERATING NOTE: While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in. • The engine block heater cord is a factory installed option. Wide-open throttle acceleration in low gear can be detri- If your vehicle is not equipped, heater cords are available mental and should be avoided.
Page 245: Park Brake
STARTING AND OPERATING PARK BRAKE Electric Park Brake (EPB) Your vehicle is equipped with an Electric Park Brake System (EPB) that offers simple operation, and some additional features that make the parking brake more convenient and useful. The parking brake is primarily intended to prevent the vehicle from rolling while parked.
Page 246 244 STARTING AND OPERATING NOTE: NOTE: The EPB fault lamp will illuminate if the EPB switch is held When parking on a hill, it is important to turn the front for longer than 60 seconds in either the released or applied wheels toward the curb on a downhill grade and away from position.
Page 247 STARTING AND OPERATING WARNING! (Continued) CAUTION! If the Brake System Warning Light remains on with the • Never leave children alone in a vehicle, or with access parking brake released, a brake system malfunction is to an unlocked vehicle. Allowing children to be in a indicated.
Page 248 246 STARTING AND OPERATING In the unlikely event of a malfunction of the Electric Park SafeHold Brake system, a yellow EPB fault lamp will illuminate. This SafeHold is a safety feature of the EPB system that will may be accompanied by the BRAKE warning lamp flashing. engage the park brake automatically if the vehicle is left In this event, urgent service of the electric park brake system unsecured while the ignition switch is in ON/RUN.
Page 249 STARTING AND OPERATING SafeHold can be temporarily bypassed by pushing the EPB Service Mode has requirements that must be met in order to Switch while the driver door is open and the brake pedal is be activated: pressed. Once manually bypassed, SafeHold will be enabled •...
Page 250: Manual Transmission - If Equipped
248 STARTING AND OPERATING When brake service work is complete, the following steps MANUAL TRANSMISSION — IF EQUIPPED must be followed to reset the parking brake system to normal WARNING! operation: You or others could be injured if you leave the vehicle •...
Page 251: Shifting
STARTING AND OPERATING Shift Pattern Gear Selector Shifting To shift the gears, fully press the clutch pedal and place the Fully press the clutch pedal before shifting gears. As you gear selector into the desired gear position (the diagram for release the clutch pedal, lightly press the accelerator pedal.
Page 252 250 STARTING AND OPERATING Recommended Vehicle Shift Speeds To utilize your manual transmission efficiently for fuel economy and performance, it should be upshifted as listed in the recommended shift speed chart. Shift at the vehicle speeds listed for acceleration. When heavily loaded or pulling a trailer, these recommended up-shift speeds may not apply.
Page 253: Downshifting
STARTING AND OPERATING Downshifting CAUTION! (Continued) • When descending a hill, be very careful to downshift Moving from a high gear down to a lower gear is recom- mended to preserve brakes when driving down steep hills. one gear at a time to prevent overspeeding the engine In addition, downshifting at the right time provides better which can cause engine damage, and/or clutch damage, even if the clutch pedal is pressed.
Page 254: Parking
252 STARTING AND OPERATING Maximum Recommended Downshift Speeds CAUTION! Failure follow maximum recommended downshifting speeds may cause the engine to overspeed and/or damage the clutch disc, even if the clutch pedal is pressed. Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4...
Page 255: Automatic Transmission - If Equipped
STARTING AND OPERATING NOTE: WARNING! (Continued) NEVER leave the car with the gearbox in neutral (or, if • It is dangerous to shift out of PARK or NEUTRAL (N) equipped with automatic transmission, before placing the if the engine speed is higher than idle speed. If your gear lever in PARK).
Page 256: Ignition Park Interlock
254 STARTING AND OPERATING NOTE: WARNING! (Continued) You must press and hold the brake pedal while shifting out • Never leave children alone in a vehicle, or with access of PARK. to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of Ignition Park Interlock reasons.
Page 257: Six-Speed Or Nine-Speed Automatic Transmission
STARTING AND OPERATING self-calibrating; therefore, the first few shifts on a new Six-Speed Or Nine-Speed Automatic Transmission vehicle may be somewhat abrupt. This is a normal condition, NOTE: and precision shifts will develop within a few hundred miles Your vehicle may be equipped with a six-speed or (kilometers).
Page 258 256 STARTING AND OPERATING NOTE: Gear Ranges If the gear selector cannot be moved to the PARK, REVERSE, Do not depress the accelerator pedal when shifting from or NEUTRAL position (when pushed forward) it is probably PARK or NEUTRAL into another gear range. in the AutoStick (+/-) position (beside the DRIVE position).
Page 259 STARTING AND OPERATING When exiting the vehicle, always: WARNING! (Continued) 1. Apply the parking brake. • It is dangerous to shift out of PARK or NEUTRAL (N) if the engine speed is higher than idle speed. If your 2. Shift the transmission into PARK. foot is not firmly pressing the brake pedal, the vehicle could accelerate quickly forward or in reverse.
Page 260 258 STARTING AND OPERATING The following indicators should be used to ensure that you WARNING! (Continued) have properly engaged the transmission into the PARK posi- • Never leave children alone in a vehicle, or with access tion: to an unlocked vehicle. Allowing children to be in a •...
Page 261 STARTING AND OPERATING When frequent transmission shifting occurs (such as when WARNING! operating the vehicle under heavy loading conditions, in Do not coast in NEUTRAL and never turn off the hilly terrain, traveling into strong head winds, or while ignition to coast down a hill. These are unsafe practices towing a heavy trailer), use the AutoStick shift control to that limit your response to changing traffic or road select a lower gear (refer to "AutoStick"...
Page 262 260 STARTING AND OPERATING clutch (and, for the nine-speed, shifts into 8th or 9th gear), In AutoStick mode, the transmission will shift up or down are inhibited until the engine and/or transmission is warm when the driver moves the gear selector rearward (+) or (refer to the “Note”...
Page 263 STARTING AND OPERATING • If a requested downshift would cause the engine to Transmission Limp Home Mode over-speed, that shift will not occur. Transmission function is monitored electronically for • The system will ignore attempts to upshift at too low of a abnormal conditions.
Page 264: Four-Wheel Drive Operation - If Equipped
NOTE: FOUR-WHEEL DRIVE OPERATION — IF EQUIPPED Even if the transmission can be reset, we recommend that Jeep Active Drive you visit an authorized dealer at your earliest possible convenience. An authorized dealer has diagnostic equip- Your vehicle may be equipped with a Power Transfer Unit ment to assess the condition of your transmission.
Page 265 STARTING AND OPERATING Active Drive Control — If Equipped Four Wheel Drive (4x4) The four wheel drive (4WD) is fully automatic in normal driving mode. NOTE: It is not possible to carry out the change of mode when the vehicle exceeds the speed of 75 mph (120 km/h). Enabling Four Wheel Drive (4x4) The buttons for the activation of four wheel drive are located on the device Selec-Terrain and allow you to select the...
Page 266 264 STARTING AND OPERATING Active Drive With Low Control — (Trailhawk models Enabling 4WD LOW only) With the vehicle stationary, the ignition in the ON/RUN position or with the engine running, shift the transmission into NEUTRAL (N) and push the button once 4WD LOW. The instrument cluster will display the message "4WD LOW"...
Page 267: Selec-Terrain - If Equipped
STARTING AND OPERATING SELEC-TERRAIN — IF EQUIPPED Selec-Terrain combines the capabilities of the vehicle control systems, along with driver input, to provide the best perfor- mance for all terrains. Mode Selection Guide Rotate the Selec-Terrain knob to select the desired mode. Selec-Terrain Switch (Trailhawk) •...
Page 268: Power Steering
266 STARTING AND OPERATING • SNOW: This mode allows you to have greater stability POWER STEERING under conditions of bad weather. For use on and off road The electric power steering system will give you good on surfaces with poor traction, such as roads covered with vehicle response and increased ease of maneuverability in snow.
Page 269: Stop/Start System - If Equipped
STARTING AND OPERATING displayed on the instrument cluster display, it indicates that This vehicle has been upgraded with a heavy duty starter, extreme steering maneuvers may have occurred, which enhanced battery, and other upgraded engine parts, to caused an over temperature condition in the power steering handle the additional engine starts.
Page 270: Possible Reasons The Engine Does Not Autostop
268 STARTING AND OPERATING Other Factors Which Can Inhibit Autostop Include: Possible Reasons The Engine Does Not Autostop • Accelerator pedal input. Prior to engine shut down, the system will check many safety and comfort conditions to see if they are fulfilled. Detailed •...
Page 271: To Manually Turn Off The Stop/Start System
STARTING AND OPERATING Conditions That Will Cause The Engine To Start Automat- If the Electric Park Brake is applied with the engine off, the ically While In Autostop Mode: engine may require a manual restart and the electric park brake may require a manual release (depress brake pedal •...
Page 272: To Manually Turn On The Stop/Start System
270 STARTING AND OPERATING 2. The “STOP/START OFF” message will appear in instru- SPEED CONTROL — IF EQUIPPED ment cluster display. Refer to “Instrument Cluster When engaged, the Speed Control takes over accelerator Display” in “Getting To Know Your Instrument Panel” operations at speeds greater than 20 mph (32 km/h).
Page 273: To Activate
STARTING AND OPERATING NOTE: WARNING! • In order to ensure proper operation, the Speed Control Leaving the Speed Control system on when not in use is System has been designed to shut down if multiple speed dangerous. You could accidentally set the system or control functions are operated at the same time.
Page 274: To Vary The Speed Setting
272 STARTING AND OPERATING To Decrease Speed To Vary The Speed Setting When the Speed Control is set, you can decrease speed by To Increase Speed pushing the SET (-) button. When the Speed Control is set, you can increase speed by pushing the SET (+) button.
Page 275: To Accelerate For Passing
STARTING AND OPERATING To Accelerate For Passing To Resume Speed Press the accelerator as you would normally. When the pedal To resume a previously set speed, push the RES button and is released, the vehicle will return to the set speed. release.
Page 276: Adaptive Cruise Control (Acc) - If Equipped
274 STARTING AND OPERATING Adaptive Cruise Control (ACC) increases the driving conve- ADAPTIVE CRUISE CONTROL (ACC) — IF EQUIPPED nience provided by cruise control while traveling on high- The Speed Control buttons (located on the right side of the ways and major roadways. However, it is not a safety system steering wheel) operates the ACC system.
Page 277 STARTING AND OPERATING The Cruise Control system has two control modes: WARNING! • Adaptive Cruise Control mode for maintaining an appro- • Adaptive Cruise Control (ACC) is a convenience priate distance between vehicles. system. It is not a substitute for active driving involve- ment.
Page 278: To Activate/Deactivate
276 STARTING AND OPERATING To Activate/Deactivate WARNING! (Continued) • Does not always fully recognize complex driving Push and release the Adaptive Cruise Control (ACC) on/off conditions, which can result in wrong or missing button. The ACC menu in the instrument cluster display will distance warnings.
Page 279: Activating Adaptive Cruise Control (Acc)
STARTING AND OPERATING To turn the system off, push and release the Adaptive Cruise WARNING! Control (ACC) on/off button again. At this time, the system Leaving the Adaptive Cruise Control (ACC) system on will turn off and the instrument cluster display will read when not in use is dangerous.
Page 280: To Set A Desired Acc Speed
278 STARTING AND OPERATING NOTE: If the system is set when the vehicle speed is below 20 mph You cannot engage ACC under the following conditions: (32 km/h), the set speed shall be defaulted to 20 mph (32 km/h). If the system is set when the vehicle speed is •...
Page 281: To Cancel
STARTING AND OPERATING To Cancel To Turn Off The following conditions cancel the system: The system will turn off and clear the set speed in memory if: • The brake pedal is applied. • The Adaptive Cruise Control (ACC) on/off button is pushed.
Page 282: To Vary The Speed Setting
280 STARTING AND OPERATING Metric Speed (km/h) To Vary The Speed Setting • Pushing the SET (+) button once will result in a 1 km/h To Increase Speed increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h. While ACC is set, you can increase the set speed by pushing the SET (+) button.
Page 283 STARTING AND OPERATING Metric Speed (km/h) • If equipped with a automatic transmission, The ACC system decelerates the vehicle to a full stop when • Pushing the SET (-) button once will result in a 1 km/h following a target vehicle. If an ACC host vehicle follows a decrease in set speed.
Page 284: Setting The Following Distance In Acc
282 STARTING AND OPERATING Setting The Following Distance In ACC The specified following distance for ACC can be set by varying the distance setting between four bars (longest), three bars (long), two bars (medium) and one bar (short). Using this distance setting and the vehicle speed, ACC calcu- lates and sets the distance to the vehicle ahead.
Page 285 STARTING AND OPERATING Distance Setting 2 Bars (Medium) Distance Setting 1 Bar (Short) To increase the distance setting, push the Distance Setting — Increase button and release. Each time the button is pushed, the distance setting increases by one bar (longer). Once the longest setting is reached, if the button is pushed again it will be set to the shortest setting available.
Page 286 284 STARTING AND OPERATING If there is no vehicle ahead, the vehicle will maintain the set the set distance. If this occurs, a visual alert “BRAKE” will speed. If a slower moving vehicle is detected in the same flash in the instrument cluster display and a chime will lane, the instrument cluster display will show the “Sensed sound while ACC continues to apply its maximum braking Vehicle Indicator”...
Page 287: Overtake Aid
STARTING AND OPERATING While ACC is holding your vehicle at a standstill, if the Overtake Aid driver seatbelt is unbuckled or the driver door is opened, the When driving with ACC engaged and following a vehicle, parking brake will be activated, and the ACC system will be the system will provide an additional acceleration up to the cancelled.
Page 288: Display Warnings And Maintenance
286 STARTING AND OPERATING Adaptive Cruise Control Ready Display Warnings And Maintenance When ACC is activated but the vehicle speed setting has not “Wipe Front Radar Sensor In Front Of Vehicle” Warning been selected, the display will read “Adaptive Cruise The “ACC/FCW Unavailable Wipe Front Radar Sensor”...
Page 289 STARTING AND OPERATING If weather conditions are not a factor, the driver should NOTE: examine the sensor. It may require cleaning or removal of an • If the “ACC/FCW Unavailable Wipe Front Radar Sensor” obstruction. The sensor is located in the center of the vehicle message occurs frequently (e.g.
Page 290: Precautions While Driving With Acc
288 STARTING AND OPERATING recover after the vehicle has left these areas. Under rare Service ACC/FCW Warning conditions, when the camera is not tracking any vehicles or If the system turns off, and the instrument cluster display objects in its path this warning may temporarily occur. reads “ACC/FCW Unavailable Service Required”...
Page 291 STARTING AND OPERATING Offset Driving Turns And Bends ACC may not detect a vehicle in the same lane that is offset When driving on a curve with ACC engaged, the system from your direct line of travel, or a vehicle merging in from may decrease the vehicle speed and acceleration for stability a side lane.
Page 292 290 STARTING AND OPERATING Using ACC On Hills Lane Changing When driving on hills, ACC may not detect a vehicle in your ACC may not detect a vehicle until it is completely in the lane. Depending on the speed, vehicle load, traffic condi- lane in which you are traveling.
Page 293 STARTING AND OPERATING Narrow Vehicles Stationary Objects And Vehicles Some narrow vehicles traveling near the outer edges of the ACC does not react to stationary objects and stationary vehi- lane or edging into the lane are not detected until they have cles.
Page 294: General Information
292 STARTING AND OPERATING La operación de este equipo está sujeta a las siguientes dos General Information condiciones: The following regulatory statement applies to all Radio 1. es posible que este equipo o dispositivo no cause interfer- Frequency (RF) devices equipped in this vehicle: encia perjudicial y This device complies with Part 15 of the FCC Rules and with 2.
Page 295 STARTING AND OPERATING To change between the different control modes, push the To Set A Desired Speed Adaptive Cruise Control (ACC) on/off button which turns Turn the Normal (Fixed Speed) Cruise Control on. the ACC on and the Normal (Fixed Speed) Cruise Control When the vehicle has reached the desired speed, off.
Page 296 294 STARTING AND OPERATING U.S. Speed (mph) more information. The speed decrement shown is dependent on the speed of U.S. (mph) or Metric (km/h) units: • Pushing the SET (+) button once will result in a 1 mph increase in set speed. Each subsequent tap of the button U.S.
Page 297 STARTING AND OPERATING To Cancel To Resume Speed The following conditions will cancel the Normal (Fixed To resume a previously set speed, push the RES button and Speed) Cruise Control without clearing the memory: release. Resume can be used at any speed above 20 mph (32 km/h).
Page 298: Parksense Rear Park Assist - If Equipped
296 STARTING AND OPERATING PARKSENSE REAR PARK ASSIST — IF EQUIPPED ParkSense Sensors The ParkSense Rear Park Assist system provides visual and The four ParkSense sensors, located in the rear fascia/ audible indications of the distance between the rear fascia bumper, monitor the area behind the vehicle that is within the and a detected obstacle when backing up (e.g.
Page 299: Parksense Display
STARTING AND OPERATING ParkSense Display When the vehicle is in REVERSE, the instrument cluster display will show the park assist system status. The system will indicate a detected obstacle by showing a single arc in one or more regions based on the obstacle’s distance and location relative to the vehicle.
Page 300 298 STARTING AND OPERATING Slow Tone/Solid Arc Slow Tone/Solid Arc...
Page 301 STARTING AND OPERATING Fast Tone/Flashing Arc Fast Tone/Flashing Arc...
Page 302 300 STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: Continuous Tone/Flashing Arc...
Page 303 STARTING AND OPERATING WARNING ALERTS Greater than Less than Rear Distance 79-59 inches 59-47 inches 47-39 inches 39-25 inches 25-12 inches 79 inches 12 inches (inches/cm) (200-150 cm) (150-120 cm) (120-100 cm) (100-65 cm) (65-30 cm) (200 cm) (30 cm) Arcs —...
Page 304: Enabling And Disabling Parksense
302 STARTING AND OPERATING SENSE UNAVAILABLE SERVICE REQUIRED” message. Enabling And Disabling ParkSense Refer to “Instrument Cluster Display” for more information. ParkSense can be enabled and disabled with the Under this condition, ParkSense will not operate. ParkSense switch, located on the switch panel below If “PARKSENSE UNAVAILABLE WIPE REAR SENSORS”...
Page 305: Parksense System Usage Precautions
STARTING AND OPERATING causing the “PARKSENSE UNAVAILABLE SERVICE ParkSense System Usage Precautions REQUIRED” message to be displayed in the instrument • Ensure that the rear bumper is free of snow, ice, mud, dirt cluster display. and debris to keep the ParkSense system operating prop- erly.
Page 306: Lanesense - If Equipped
304 STARTING AND OPERATING LANESENSE — IF EQUIPPED WARNING! (Continued) • Before using ParkSense, it is strongly recommended LaneSense Operation that the ball mount and hitch ball assembly is discon- The LaneSense system is operational at speeds above 37 mph nected from the vehicle when the vehicle is not used for (60 km/h) and below 112 mph (180 km/h).
Page 307: Turning Lanesense On Or Off
STARTING AND OPERATING NOTE: When operating conditions have been met, the LaneSense system will monitor if the driver’s hands are on the steering wheel and provide an audible and visual warning to the driver when the driver’s hands are not detected on the steering wheel.
Page 308: Lanesense Warning Message
306 STARTING AND OPERATING LaneSense Warning Message The LaneSense system will indicate the current lane drift condition through the instrument cluster display. Base Instrument Cluster Display — If Equipped When the LaneSense system is on; the lane lines are gray when both of the lane boundaries have not been detected and the LaneSense telltale is solid white.
Page 309 STARTING AND OPERATING • When the LaneSense system senses the lane has been Left Lane Departure — Both Lanes Detected approached and is in a lane departure situation, the left • When the LaneSense system is on, the lane lines turn from thick lane line flashes from white to gray, the left thin line gray to white to indicate that both of the lane markings remains solid white and the LaneSense telltale...
Page 310 308 STARTING AND OPERATING • When the LaneSense system senses a lane drift situation, • When the LaneSense system senses the lane has been the left thick lane line and the left thin line turn solid white. approached and is in a lane departure situation, the left thick lane line flashes from white to gray, the left thin line The LaneSense telltale changes from solid green to solid...
Page 311 STARTING AND OPERATING NOTE: The LaneSense system operates with similar behavior for a right lane departure. Premium Instrument Cluster Display — If Equipped When the LaneSense system is on; the lane lines are gray when both of the lane boundaries have not been detected and the LaneSense telltale is solid white.
Page 312 310 STARTING AND OPERATING • When the LaneSense system senses the lane has been Left Lane Departure — Both Lanes Detected approached and is in a lane departure situation, the left • When the LaneSense system is on, the lane lines turn from thick lane line flashes yellow, the left thin line remains gray to white to indicate that both of the lane markings solid yellow and the LaneSense telltale...
Page 313 STARTING AND OPERATING • When the LaneSense system senses a lane drift situation, thick lane line flashes yellow and the left thin line remains the left thick lane line and left thin line turn solid yellow. solid yellow. The LaneSense telltale stays solid yellow.
Page 314: Changing Lanesense Status
312 STARTING AND OPERATING NOTE: Changing LaneSense Status The ParkView Rear Back Up Camera has programmable The LaneSense system has settings to adjust the intensity of modes of operation that may be selected through the Ucon- the torque warning (Low/Medium/High) and the warning nect System.
Page 315 STARTING AND OPERATING The following table shows the approximate distances for each zone: Zone Distance To The Rear Of The Vehicle 0 - 1 ft (0 - 30 cm) Yellow 1 ft - 6.5 ft (30 cm - 2 m) Green 6.5 ft or greater (2 m or greater) WARNING!
Page 316: Refueling The Vehicle
314 STARTING AND OPERATING REFUELING THE VEHICLE The Capless Fuel System uses a flapper placed at the filler pipe of the fuel tank; it opens and closes automatically upon insertion/extraction of the fuel nozzle. The Capless Fuel System is designed so that it prevents the filling of an incor- rect type of fuel.
Page 317 STARTING AND OPERATING Emergency Gas Can Refueling 3. Ensure funnel is inserted fully to hold flapper door open. Most gas cans will not open the flapper door. A funnel is 4. Pour fuel into funnel opening. provided to open the flapper door to allow emergency refu- 5.
Page 318: Vehicle Loading
316 STARTING AND OPERATING VEHICLE LOADING Payload The payload of a vehicle is defined as the allowable load Certification Label weight a truck can carry, including the weight of the driver, As required by National Highway Traffic Safety Administra- all passengers, options and cargo. tion regulations, your vehicle has a certification label affixed to the driver's side door or pillar.
Page 319: Trailer Towing
STARTING AND OPERATING rear to front as appropriate until the specified weight limita- Inflation Pressure tions are met. Store the heavier items down low and be sure This is the cold tire inflation pressure for your vehicle for all that the weight is distributed equally. Stow all loose items loading conditions up to full GAWR.
Page 320: Common Towing Definitions
318 STARTING AND OPERATING Common Towing Definitions Gross Axle Weight Rating (GAWR) The GAWR is the maximum capacity of the front and rear The following trailer towing related definitions will assist axles. Distribute the load over the front and rear axles evenly. you in understanding the following information: Make sure that you do not exceed either front or rear GAWR.
Page 321 STARTING AND OPERATING for a more level ride, offering more consistent steering and Trailer Sway Control brake control thereby enhancing towing safety. The addition The Trailer Sway Control (TSC) can be a mechanical tele- of a friction/hydraulic sway control also dampens sway scoping link that can be installed between the hitch receiver caused by traffic and crosswinds and contributes positively and the trailer tongue that typically provides adjustable fric-...
Page 322: Trailer Towing Weights (Maximum Trailer Weight Ratings)
320 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) Maximum GTW Maximum Tongue Wt. Engine/Transmission Model (Gross Trailer Wt.) (See Note) 2.4L / Manual Trailer towing is not recommended. 2.4L / Manual 2,000 lbs (907 kg) 200 lbs (90 kg) 2.4L / 6 Speed Auto FWD or 4WD Trailer towing is not recommended.
Page 323: Trailer And Tongue Weight
STARTING AND OPERATING Consider the following items when computing the weight on Trailer And Tongue Weight the front/rear axles of the vehicle: Never exceed the maximum tongue weight stamped on your • The trailer tongue weight of the trailer. trailer hitch. •...
Page 324: Towing Requirements
322 STARTING AND OPERATING Towing Requirements WARNING! • Make certain that the load is secured in the trailer and To promote proper break-in of your new vehicle drivetrain will not shift during travel. When trailering cargo that components, the following guidelines are recommended. is not fully secured, dynamic load shifts can occur that CAUTION! may be difficult for the driver to control.
Page 325 STARTING AND OPERATING • Check the trailer tires for proper tire inflation pressures WARNING! (Continued) before trailer usage. • Total weight must be distributed between the tow • Check for signs of tire wear or visible tire damage before vehicle and the trailer such that the following four towing a trailer.
Page 326 324 STARTING AND OPERATING Towing Requirements — Trailer Lights And Wiring WARNING! • Do not connect trailer brakes to your vehicle's Whenever you pull a trailer, regardless of the trailer size, hydraulic brake lines. It can overload your brake stoplights and turn signals on the trailer are required for system and cause it to fail.
Page 327 STARTING AND OPERATING Four-Pin Connector Seven-Pin Connector 1 — Female Pins 1 — Battery 2 — Male Pin 2 — Backup Lamps 3 — Ground 3 — Right Stop/Turn 4 — Park 4 — Electric Brakes 5 — Left Stop/Turn 5 —...
Page 328: Towing Tips
326 STARTING AND OPERATING Towing Tips Cooling System To reduce potential for engine and transmission over- Before setting out on a trip, practice turning, stopping, and heating, take the following actions: backing up the trailer in an area located away from heavy traffic.
Page 329: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle WHEELS OFF THE FRONT WHEEL DRIVE FOUR-WHEEL DRIVE TOWING CONDITION GROUND (FWD) (4WD) Flat Tow NONE NOT ALLOWED NOT ALLOWED REAR NOT ALLOWED NOT ALLOWED Dolly Tow FRONT NOT ALLOWED On Trailer...
Page 330: Recreational Towing - Front-Wheel Drive (Fwd) Models
328 STARTING AND OPERATING Recreational Towing — Front-Wheel Drive (FWD) CAUTION! Models • Towing with the front wheels on the ground will cause severe transmission damage. Damage from improper Recreational towing is allowed ONLY if the front wheels are towing is not covered under the New Vehicle Limited OFF the ground.
Page 331: Driving Tips
STARTING AND OPERATING to extreme situations such as deep snow, mud, or sand where DRIVING TIPS additional low speed pulling power is needed. Vehicle speeds On-Road Driving Tips in excess of 25 mph (40 km/h) should be avoided when in 4WD LOW range.
Page 332 330 STARTING AND OPERATING Flowing Water contaminated. Contaminated fluids and lubricants (milky, foamy in appearance) should be flushed/changed as soon as If the water is swift flowing and rising (as in storm run-off) possible to prevent component damage. avoid crossing until the water level recedes and/or the flow rate is reduced.
Page 333 STARTING AND OPERATING NOTE: If the wheels start to slip as you approach the crest of a hill, Brakes should be applied at increased slippage, but before ease off the accelerator and maintain headway by turning the coming to a stop to avoid digging into the loose surface and front wheels slowly left and right.
Page 334 332 STARTING AND OPERATING • After extended operation in mud, sand, water, or similar After Driving Off-Road dirty conditions, have the radiator, fan, brake rotors, Off-road operation puts more stress on your vehicle than wheels, brake linings, and axle yokes inspected and does most on-road driving.
Page 335: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS ASSIST AND SOS MIRROR — IF EQUIPPED The Hazard Warning flasher switch is located in the lower center area of the instrument panel. Push the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 336 334 IN CASE OF EMERGENCY ASSIST Call WARNING! ALWAYS obey traffic laws and pay attention to the road. The ASSIST Button is used to automatically connect you to ALWAYS drive safely with your hands on the steering any one of the following support centers: wheel.
Page 337 IN CASE OF EMERGENCY 2. The LED light located between the ASSIST and SOS NOTE: buttons on the Rearview Mirror will turn green once a • Your vehicle may be transmitting data as authorized by connection to a SOS operator has been made. the subscriber.
Page 338 336 IN CASE OF EMERGENCY WARNING! (Continued) WARNING! (Continued) • Never place anything on or near the vehicle’s operable • Modifications to any part of the SOS Call system could network and GPS antennas. You could prevent oper- cause the air bag system to fail when you need it. You able network and GPS signal reception, which can could be injured if the air bag system is not there to prevent your vehicle from placing an emergency call.
Page 339 IN CASE OF EMERGENCY • The vehicle battery loses power or becomes disconnected WARNING! during a vehicle crash • Ignoring the Rearview Mirror light could mean you • LTE (voice/data) or 4G (data) network and/or Global will not have SOS Call services. If the Rearview Mirror Positioning Satellite signals are unavailable or obstructed light is illuminated, have your authorized dealer service the SOS Call system immediately.
Page 340: General Information
338 IN CASE OF EMERGENCY NOTE: General Information • Your vehicle may be transmitting data as authorized by The following regulatory statement applies to all Radio the subscriber. Frequency (RF) devices equipped in this vehicle: • Never place anything on or near the vehicle’s LTE (voice/ This device complies with Part 15 of the FCC Rules and with data) or 4G (data) and GPS antennas.
Page 341: Bulb Replacement
IN CASE OF EMERGENCY La operación de este equipo está sujeta a las siguientes dos NOTE: condiciones: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s 1. es posible que este equipo o dispositivo no cause interfer- authority to operate the equipment.
Page 342 340 IN CASE OF EMERGENCY Exterior Bulbs Exterior Bulbs Lamps Bulb Number Low Beam Headlamps (Halogen) H11LL High Beam Headlamps (Halogen) 9005LL Front Position/Daytime Running Lights (DRL ) PSX24W Front Direction Indicator Lamps 7444NA Front Position – Premium LED LED (Serviced At An Authorized Dealer) Front Fog Lamps H11LL Low Beam / High Beam Headlamps (HID)
Page 343: High Intensity Discharge (Hid) Headlamps - If Equipped
IN CASE OF EMERGENCY High Intensity Discharge (HID) Headlamps — If Replacing Exterior Bulbs Equipped Headlamps The headlamps contain a type of high voltage discharge light Hi/Lo Beam Light Halogen source. High voltage can remain in the circuit even with the headlamp switch off.
Page 344 342 IN CASE OF EMERGENCY 3. Remove the headlamp bulb cap. Headlamp Bulb Socket 5. Push on the locking tab on the headlamp bulb connector Headlamp and remove the bulb and socket. 1 — Low Beam Bulb Cap 2 — High Beam Bulb Cap 6.
Page 345 IN CASE OF EMERGENCY 6. For the turn signal bulb, rotate in a counterclockwise WARNING! direction and remove the bulb and bulb socket. Pull the Carry out the operation of replacing lamps only with the bulb axially to remove it from the socket. engine off.
Page 346 344 IN CASE OF EMERGENCY 4. Rotate the bulb counterclockwise, and then replace the 6. Reconnect the electrical connector. bulb. 7. Reinstall the wheel liner. NOTE: We advise referring to an authorized dealer. Side Indicators The Side Indicators are LED. For their replacement see your authorized dealer.
Page 347 IN CASE OF EMERGENCY To replace the bulbs proceed as follows: 3. Disconnect the electrical connector by pushing the release. 1. Open the liftgate. 4. Remove the rear body side tail lamp, sliding it away from 2. Using a suitable tool remove fasteners. the back of the vehicle.
Page 348 346 IN CASE OF EMERGENCY 5. Replace the bulb as necessary by turning and removing 9. Reinstall the body side lamp making sure to align the ball the bulb housing. studs. Reverse Side of Tail Lamp Body Side Tail Lamp 1 —...
Page 349 IN CASE OF EMERGENCY Reverse Lamps 4. Remove bulb and replace making sure it is properly locked. 1. Open the liftgate. 5. Reconnect the electrical connector. 2. Using a suitable tool remove the access panel for body side lamps, remove lift gate access cover for lift gate 6.
Page 350: Replacing Interior Bulbs
348 IN CASE OF EMERGENCY 2. Release the retainer clips and bulb housing as shown. Replacing Interior Bulbs Front Courtesy Light To replace the bulbs proceed as follows: 1. Using a suitable tool remove the front courtesy light assembly. Front Courtesy Bulb Housing 1 —...
Page 351 IN CASE OF EMERGENCY 3. Replace the bulbs by pulling straight out of bulb housing. Dome Light Vanity Mirror — If Equipped To replace the bulbs proceed as follows: 1. Lift the cover of the mirror and pull out the mirror frame with the mirror light cover attached.
Page 352 350 IN CASE OF EMERGENCY 3. Reinstall the visor mirror light cover making sure that it 3. Insert the new bulb, making sure it is properly locked. is properly locked. Dome Light 4. Finally lower the visor mirror cover to the mirror. To replace the bulbs proceed as follows: Dome Light Glove Compartment 1.
Page 353 IN CASE OF EMERGENCY 2. Replace the bulb by removing it from the side contacts. Interior Cargo Lights To replace the bulbs proceed as follows: 1. Using thumb with slight pressure – push bulb holder to the side. Bulb 3. Insert the new bulb, locking it between the contacts. 4.
Page 354 352 IN CASE OF EMERGENCY 2. Fully disengage the bulb holder from the housing. 3. Rotate bulb holder to replace bulb. Bulb Holder Bulb...
Page 355: Fuses
IN CASE OF EMERGENCY FUSES WARNING! • Modifications or repair of the electrical system WARNING! performed incorrectly and without taking into account • When replacing a blown fuse, always use an appro- the technical characteristics can cause malfunctions priate replacement fuse with the same amp rating as the with the risk of fire.
Page 356: General Information
354 IN CASE OF EMERGENCY General Information Fuse Location The fuses protect electrical systems against excessive current. The fuses are grouped into controllers located in the engine compartment. When a device does not work, you must check the fuse element inside the blade fuse for a break/melt. Engine Compartment Fuses/Distribution Unit Also, please be aware that when using power outlets for The engine compartment fuse panel is located on the left side...
Page 357 IN CASE OF EMERGENCY Removing Fuse Cover and Locking Screw Proceed as follows: 1. Slowly turn the screw counterclockwise. 2. Slowly release the screw. 3. Remove the fuse cover by sliding it upward. Fuse Panel & Cover 1 — Cover Screw 2 —...
Page 358 356 IN CASE OF EMERGENCY Mounting Fuse Cover and Locking Screw Proceed as follows: 1. Properly secure the fuse cover to the box, slide completely from top to bottom. 2. Fully depress the screw, using the special screwdriver supplied, in the rear cargo area. 3.
Page 359 IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description Brake Control Electronics – 40 Amp Tan – Module – 40 Amp Tan – PTC Heater 40 Amp Orange – – Starter Relay Rear Distribution Unit For 40 Amp Orange –...
Page 360 358 IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description – – 10 Amp Red Engine Secondary Loads 12V Rear Cargo Outlet – – 20 Amp Yellow Ignition Powered Air Conditioner – – 7.5 Amp Brown Compressor –...
Page 361 IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description Power Supply All Wheel – – 30 Amp Green Drive Gear Selector Automatic – – 5 Amp Tan Transmission – – 7.5 Amp Brown Heated Outside Mirrors – –...
Page 362: Interior Fuses
360 IN CASE OF EMERGENCY Interior Fuses The interior fuse panel is located in the driver compartment on the left side dash panel under the instrument panel. Cavity Blade Fuse Description 7.5 Amp Brown Occupant Restraint Controller 20 Amp Yellow Window Motor Passenger 20 Amp Yellow Window Motor Driver...
Page 363 IN CASE OF EMERGENCY Cavity Blade Fuse Description Park Assist, Blind Spot, Voltage Stabilizer, Humidity Sensor, 7.5 Amp Brown Electronic Steering Lock, Temp Sense, Mirror, Heated Seats, Light And Rain Sensor, Start Stop Switch 7.5 Amp Brown Occupant Restraint Controller Electronic Climate Control, Occupant Classification, Rear View Camera, Climate Control, Headlamp Leveling, Terrain 7.5 Amp Brown...
Page 364: Rear Cargo Fuse/Relay Distribution Unit
362 IN CASE OF EMERGENCY To remove fuse cover, press on the tabs and lift upward. Rear Cargo Fuse/Relay Distribution Unit To access the fuses, remove the access door from the left rear panel of the rear cargo area. Rear Cargo Fuse Panel Cover Rear Cargo Fuse Panel Access Door...
Page 365 IN CASE OF EMERGENCY The fuses may be contained in two units. Fuse holder No. 1 is located closest to the rear of the vehicle and fuse holder No. 2 (if equipped with trailer towing) is located closest to the front of the vehicle. Rear Cargo Fuse Cavities 1 —...
Page 366 364 IN CASE OF EMERGENCY Fuse Holder No. 1 (Continued) (Sheet 2 of 2) Cavity Mini Fuse Description Power Lumbar (Power Seats) 7.5 Amp Brown Heated Steering Wheel / Ventilated 15 Amp Blue Seats 20 Amp Yellow Heated Seats Fuse Holder No. 2 Cavity Mini Fuse Description...
Page 367: Jacking And Tire Changing
IN CASE OF EMERGENCY On the Rear Cargo Fuse/Relay Distribution Unit bracket, there is a Maxi Fuse holder for the Power Liftgate and an ATO / Uni Val fuse holder for the HIFI Audio System. Cavity Maxi Fuse Description 30 Amp Green Power Liftgate Cavity ATO / Uni-Val Fuse...
Page 368: Jack Location/Spare Tire Stowage
366 IN CASE OF EMERGENCY Jack Location/Spare Tire Stowage If equipped, the jack and tools are located in the rear storage compartment, below the spare tire. NOTE: Items may vary depending on the trim level. Jack And Tools Location 1 — Jack 2 —...
Page 369 IN CASE OF EMERGENCY 2. Lift the access cover using the load floor handle. 3. Remove the fastener securing the spare tire, and remove the spare wheel from the vehicle. The jack will be found beneath. Load Floor Handle Spare Tire Fastener 4.
Page 370: Preparations For Jacking
368 IN CASE OF EMERGENCY 5. Remove the jack and wheel bolt wrench. WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided.
Page 371: Jacking Instructions
IN CASE OF EMERGENCY 5. Place the ignition in the OFF position. Jacking Instructions 6. Block both the front and rear of the wheel diagonally WARNING! opposite the jacking position. For example, if the right Carefully follow these tire changing warnings to help front wheel is being changed, block the left rear wheel.
Page 372 370 IN CASE OF EMERGENCY CAUTION! WARNING! (Continued) Do not attempt to raise the vehicle by jacking on • Only use the jack in the positions indicated and for locations other than those indicated in the Jacking lifting this vehicle during a tire change. Instructions for this vehicle.
Page 373 IN CASE OF EMERGENCY Jacking Locations Front Lifting Point...
Page 374 372 IN CASE OF EMERGENCY Front Jacking Location Rear Lifting Point...
Page 375 IN CASE OF EMERGENCY 7. Remove the alignment pin from the jack assembly and thread the pin into the wheel hub to assist in mounting the spare tire. 8. Mount the spare tire. CAUTION! Be sure to mount the spare tire with the valve stem facing outward.
Page 376: Road Tire Installation
374 IN CASE OF EMERGENCY NOTE: 12. Place the jack on the foam tray and open it far enough so that it is secured. Once placed in position, rotate it clock- • For vehicles equipped, do not attempt to install a center wise to lock it in.
Page 377: Tire Service Kit - If Equipped
IN CASE OF EMERGENCY 3. Lower the vehicle to the ground by turning the jack nails) should not be removed from the tire. Tire Service Kit handle counterclockwise. can be used in outside temperatures down to approximately -4°F (-20°C). This kit will provide a temporary tire seal, 4.
Page 378 376 IN CASE OF EMERGENCY Tire Service Kit And Components And Operation Using The Mode Select Knob And Hoses Your Tire Service Kit is equipped with the following symbols to indicate the air or sealant mode. • Selecting Air Mode Push in the Mode Select Knob and turn to this position for air pump operation only.
Page 379 IN CASE OF EMERGENCY Tire Service Kit Usage Precautions items to avoid injecting sealant into them. The Tire Service Kit Sealant is only intended to seal punctures less than 1/4 inch • Replace the Tire Service Kit Sealant Bottle prior to the expi- (6 mm) diameter in the tread of your vehicle.
Page 380 378 IN CASE OF EMERGENCY Sealing A Tire With Tire Service Kit WARNING! (Continued) Whenever You Stop To Use Tire Service Kit: • A loose Tire Service Kit thrown forward in a collision or hard stop could endanger the occupants of the 1.
Page 381 IN CASE OF EMERGENCY 3. Remove the cap from the valve stem and then If the sealant (white fluid) does not flow within 0 – 10 seconds screw the fitting at the end of the Sealant Hose through the Sealant Hose: onto the valve stem.
Page 382 380 IN CASE OF EMERGENCY 2. The pump will start to inject air into the tire 3. Immediately disconnect the Sealant Hose from the valve immediately after the Sealant Bottle is empty. stem, reinstall the cap on the fitting at the end of the hose, Continue to operate the pump and inflate the tire and place the Tire Service Kit in the vehicle storage loca- to the cold tire inflation pressure found on the tire and...
Page 383 IN CASE OF EMERGENCY 1. Uncoil the Sealant Hose, and then remove the cap from If tire pressure is less than 19 psi (1.3 Bar): the fitting at the end of the hose. The tire is too badly damaged. Do not attempt to drive the 2.
Page 384 382 IN CASE OF EMERGENCY 5. Remove the Speed Limit sticker from the steering wheel Sealant Bottle Replacement: after the tire has been repaired. 1. Unwrap the power cord. 6. Replace the Sealant Bottle at an authorized dealer as soon 2.
Page 385 IN CASE OF EMERGENCY 3. Remove the bottle cover. 4. Rotate the bottle up beyond vertical to release. Remove The Bottle Cover Rotate The Bottle Up...
Page 386: Jump Starting
384 IN CASE OF EMERGENCY 5. Pull the bottle away from the Compressor. JUMP STARTING If your vehicle has a discharged battery, it can be jump started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. Jump starting can be dangerous if done improperly, so please follow the procedures in this section carefully.
Page 387: Preparations For Jump Start
IN CASE OF EMERGENCY Preparations For Jump Start The battery in your vehicle is located in the front of the engine compartment, behind the left headlight assembly. NOTE: The positive battery post is covered with a protective cap. Lift up on the cap to gain access to the post. Positive Battery Post Battery Post Cover...
Page 388: Jump Starting Procedure
386 IN CASE OF EMERGENCY WARNING! WARNING! • Take care to avoid the radiator cooling fan whenever Do not allow vehicles to touch each other as this could the hood is raised. It can start anytime the ignition establish a ground connection and personal injury could switch is ON.
Page 389 IN CASE OF EMERGENCY 3. Connect the negative (-) end of the jumper cable to the WARNING! negative (-) post of the booster battery. Do not connect the jumper cable to the negative (-) post of the discharged battery. The resulting electrical spark 4.
Page 390: Refueling In Emergency - If Equipped
388 IN CASE OF EMERGENCY 4. Disconnect the opposite end of the positive (+) jumper REFUELING IN EMERGENCY – IF EQUIPPED cable from the positive (+) post of the vehicle with the The fuel filling procedure for in case of an emergency is discharged battery.
Page 391: If Your Engine Overheats
IN CASE OF EMERGENCY CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads “H,” pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range.
Page 392: Gear Selector Override
390 IN CASE OF EMERGENCY 3. Grasp the boot material rearward of the gear selector and WARNING! pull up to carefully separate the gear selector bezel and You or others can be badly burned by hot engine coolant boot assembly from the center console. (antifreeze) or steam from your radiator.
Page 393: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY 5. Insert a small screwdriver or similar tool down into the FREEING A STUCK VEHICLE gear selector override access hole (at the right rear corner If your vehicle becomes stuck in mud, sand or snow, it can of the gear selector assembly), and push and hold the often be moved using a rocking motion.
Page 394 392 IN CASE OF EMERGENCY Use the least amount of accelerator pedal pressure that will CAUTION! maintain the rocking motion without spinning the wheels or • Racing the engine or spinning the wheels may lead to racing the engine. transmission overheating and failure. Allow the engine to idle with the transmission in NEUTRAL for at least WARNING! one minute after every five rocking-motion cycles.
Page 395: Towing A Disabled Vehicle
IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Wheels OFF Towing Condition FWD MODELS 4X4 MODELS The Ground Flat Tow NONE NOT ALLOWED NOT ALLOWED Rear NOT ALLOWED NOT ALLOWED Wheel Lift Or Dolly...
Page 396: Without The Key Fob
394 IN CASE OF EMERGENCY If you must use the accessories (wipers, defrosters, etc.) CAUTION! while being towed, the ignition must be in the ON/RUN • Do not use sling-type equipment when towing. Vehicle mode. damage may occur. Note that the Safehold feature will engage the Electric Park •...
Page 397: Front-Wheel Drive (Fwd) Models - With Key Fob
IN CASE OF EMERGENCY Acceptable methods are to tow the vehicle on a flatbed, or Front-Wheel Drive (FWD) Models — With Key Fob with one end of the vehicle raised and the opposite end on a The manufacturer recommends towing your vehicle with all towing dolly.
Page 398: Emergency Tow Hooks - If Equipped
396 IN CASE OF EMERGENCY Emergency Tow Hooks — If Equipped If your vehicle is equipped with tow hooks, there will be one in the rear and two mounted on the front of the vehicle. The rear hook will be located on the driver's side of the vehicle. NOTE: For off-road recovery, it is recommended to use both of the front tow hooks to minimize the risk of damage to the...
Page 399: Enhanced Accident Response System (Ears)
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) WARNING! • Do not use a chain for freeing a stuck vehicle. Chains This vehicle is equipped with an Enhanced Accident may break, causing serious injury or death. Response System. • Stand clear of vehicles when pulling with tow hooks. Please refer to “Occupant Restraint Systems”...
Page 400: Servicing And Maintenance
SERVICING AND MAINTENANCE An authorized dealer will reset the oil change indicator SCHEDULED SERVICING message after completing the scheduled oil change. If a Your vehicle is equipped with an automatic oil change indi- scheduled oil change is performed by someone other than an cator system.
Page 401: Maintenance Plan
SERVICING AND MAINTENANCE NOTE: Maintenance Plan The Oil Change Indicator will not illuminate under these Refer to the “Maintenance Plan” on the following page for conditions. the required maintenance intervals. Once A Month Or Before A Long Trip: Required Maintenance Intervals. •...
Page 402 400 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: If using your vehicle in dusty or off-road conditions, inspect the air cleaner filter, and replace if necessary. Inspect the brake linings, replace if necessary. Inspect the front suspension, tie rod ends and boot seals, replace if necessary.
Page 403 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Replace spark plugs. Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Inspect and replace PCV valve if necessary.
Page 404: Engine Compartment
402 SERVICING AND MAINTENANCE ENGINE COMPARTMENT 2.4L Engine 1 — Engine Air Cleaner Filter 6 — Washer Fluid Reservoir Cap 2 — Engine Oil Fill 7 — Secondary Battery 3 — Brake Fluid Reservoir Cap 8 — Coolant Pressure Bottle Cap 4 —...
Page 405: Checking Oil Level
SERVICING AND MAINTENANCE Checking Oil Level CAUTION! Overfilling or underfilling the crankcase will cause aeration To ensure proper engine lubrication, the engine oil must be or loss of oil pressure. This could damage your engine. maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop.
Page 406: Maintenance-Free Battery
404 SERVICING AND MAINTENANCE Maintenance-Free Battery CAUTION! • It is essential when replacing the cables on the battery Your vehicle is equipped with a maintenance-free battery. that the positive cable is attached to the positive post You will never have to add water, nor is periodic mainte- and the negative cable is attached to the negative post.
Page 407: Dealer Service
SERVICING AND MAINTENANCE DEALER SERVICE Engine Oil An authorized dealer has the qualified service personnel, Change Engine Oil special tools, and equipment to perform all service opera- Refer to the “Scheduled Servicing” in this section for the tions in an expert manner. Service Manuals are available proper maintenance intervals.
Page 408 406 SERVICING AND MAINTENANCE Lubricants which do not have both the engine oil certifica- American Petroleum Institute (API) Engine Oil tion mark and the correct SAE viscosity grade number Identification Symbol should not be used. This symbol means that the oil has been certified by the American Petroleum Institute (API).
Page 409: Engine Oil Filter
SERVICING AND MAINTENANCE Contact an authorized dealer, service station or govern- WARNING! mental agency for advice on how and where used oil and oil The air induction system (air cleaner, hoses, etc.) can filters can be safely discarded in your area. provide a measure of protection in the case of engine backfire.
Page 410: Body Lubrication
408 SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling R-134a — If WARNING! Equipped • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- R-134a Air Conditioning Refrigerant is a hydrofluorocarbon tioning system. Some unapproved refrigerants are (HFC) that is an ozone-friendly substance.
Page 411: Wiper Blades
SERVICING AND MAINTENANCE should be removed. Particular attention should also be given Avoid using the wiper blades to remove frost or ice from the to hood latching components to ensure proper function. windshield or rear window. Make sure that they are not When performing other underhood services, the hood latch, frozen to the glass before turning them on to avoid damaging release mechanism and safety catch should be cleaned and...
Page 412 410 SERVICING AND MAINTENANCE Wiper Blade Removal/Installation CAUTION! Do not allow the wiper arm to spring back against the glass without the wiper blade in place or the glass may be damaged. 1. Lift the wiper arm to raise the wiper blade off of the glass, until the wiper arm is in the full up position.
Page 413 SERVICING AND MAINTENANCE 2. To disengage the wiper blade from the wiper arm, flip up 3. Tilt the lower end of the wiper blade away from the arm the locking tab. and use one finger push the release tab toward the wiper arm.
Page 414: Exhaust System
412 SERVICING AND MAINTENANCE 5. With the wiper blade disengaged, remove the wiper Installing The Front Wipers blade from the wiper arm by holding the wiper arm with 1. Lift the wiper arm off of the glass, until the wiper arm is one hand and separating the wiper blade from the wiper in the full up position.
Page 415 SERVICING AND MAINTENANCE system and adjacent body areas for broken, damaged, dete- CAUTION! riorated, or mispositioned parts. Open seams or loose • The catalytic converter requires the use of unleaded connections could permit exhaust fumes to seep into the fuel only. Leaded gasoline will destroy the effective- passenger compartment.
Page 416: Cooling System
414 SERVICING AND MAINTENANCE In unusual situations involving grossly malfunctioning Cooling System engine operation, a scorching odor may suggest severe and WARNING! abnormal catalyst overheating. If this occurs, stop the vehicle, turn off the engine and allow it to cool. Service, •...
Page 417 SERVICING AND MAINTENANCE Coolant Checks Selection Of Coolant Check engine coolant (antifreeze) protection every Refer to “Fluids And Lubricants” in “Technical Specifica- 12 months (before the onset of freezing weather, where tions” for further information. applicable). If the engine coolant (antifreeze) is dirty or rusty NOTE: in appearance, the system should be drained, flushed and refilled with fresh engine coolant (antifreeze).
Page 418 416 SERVICING AND MAINTENANCE • This vehicle has not been designed for use with propylene Please review these recommendations for using Organic glycol-based engine coolant (antifreeze). Use of propylene Additive Technology (OAT) engine coolant (antifreeze) that glycolbased engine coolant (antifreeze) is not recom- meets the requirements of FCA Material Standard MS.90032.
Page 419 SERVICING AND MAINTENANCE NOTE: The cap should be inspected and cleaned if there is any accu- mulation of foreign material on the sealing surfaces. • It is the owner's responsibility to maintain the proper level of protection against freezing according to the tempera- WARNING! tures occurring in the area where the vehicle is operated.
Page 420 418 SERVICING AND MAINTENANCE not store ethylene glycol-based coolant in open containers or ture from rain, snow, or high humidity accumulating on the allow it to remain in puddles on the ground. If ingested by a radiator and being vaporized when the thermostat opens, child or pet, seek emergency assistance immediately.
Page 421: Brake System
SERVICING AND MAINTENANCE • Make sure that the coolant expansion bottle overflow Brake Master Cylinder hoses are not kinked or obstructed. The fluid in the master cylinder should be checked when • Keep the front of the radiator clean. If your vehicle is performing under hood services or immediately if the equipped with air conditioning, keep the front of the “Brake Warning Light”...
Page 422: Manual Transmission - If Equipped
420 SERVICING AND MAINTENANCE Manual Transmission — If Equipped WARNING! (Continued) • To avoid contamination from foreign matter or mois- Lubricant Selection ture, use only new brake fluid or fluid that has been in Use only the manufacturers recommended transmission a tightly closed container.
Page 423: Automatic Transmission - If Equipped
SERVICING AND MAINTENANCE NOTE: Special Additives If contaminated with water, the fluid should be changed The manufacturer strongly recommends against using any immediately. special additives in the transmission. Automatic Transmis- sion Fluid (ATF) is an engineered product and its perfor- Automatic Transmission —...
Page 424: Raising The Vehicle
422 SERVICING AND MAINTENANCE Fluid Level Check Fluid And Filter Changes The fluid level is preset at the factory and does not require Under normal operating conditions, the fluid installed at the adjustment under normal operating conditions. Routine factory will provide satisfactory lubrication for the life of the fluid level checks are not required;...
Page 425 SERVICING AND MAINTENANCE NOTE: Tire Markings • P (Passenger) — Metric tire sizing is based on US design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Example: P215/65R15 95H. • European — Metric tire sizing is based on European design standards.
Page 426 424 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 427 SERVICING AND MAINTENANCE EXAMPLE: Service Description: 95 = Load Index • A numerical code associated with the maximum load a tire can carry H = Speed Symbol • A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain oper- ating conditions •...
Page 428 426 SERVICING AND MAINTENANCE the tire. Look for the TIN on the outboard side of black side- Tire Identification Number (TIN) wall tires as mounted on the vehicle. If the TIN is not found The Tire Identification Number (TIN) may be found on one on the outboard side, then you will find it on the inboard side or both sides of the tire;...
Page 429 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition The vehicle B-Pillar is the structural member of the body located behind B-Pillar the front door. Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile Cold Tire Inflation Pressure (1.6 km) after sitting for a minimum of three hours.
Page 430 428 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver's side door. Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recom- mended pressure for your vehicle.
Page 431 SERVICING AND MAINTENANCE Tire And Loading Information Placard Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire's load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pres- sures specified on the Tire and Loading Information placard in “Vehicle Loading”...
Page 432 430 SERVICING AND MAINTENANCE Steps For Determining Correct Load Limit— (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this (1) Locate the statement “The combined weight of occu- manual to determine how this reduces the available cargo pants and cargo should never exceed XXX kg or XXX lbs.”...
Page 433 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.
Page 434: Tires - General Information
432 SERVICING AND MAINTENANCE Tires — General Information WARNING! (Continued) • Overinflated or underinflated tires can affect vehicle Tire Pressure handling and can fail suddenly, resulting in loss of Proper tire inflation pressure is essential to the safe and satis- vehicle control.
Page 435 SERVICING AND MAINTENANCE Fuel Economy CAUTION! Underinflated tires will increase tire rolling resistance After inspecting or adjusting the tire pressure, always resulting in higher fuel consumption. reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could Tread Wear damage the valve stem.
Page 436 434 SERVICING AND MAINTENANCE Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) Radial Ply Tires during operation. DO NOT reduce this normal pressure WARNING! build up or your tire pressure will be too low. Combining radial ply tires with other types of tires on Tire Pressures For High Speed Operation your vehicle will cause your vehicle to handle poorly.
Page 437 SERVICING AND MAINTENANCE Run Flat Tires — If Equipped Tire Spinning Run Flat tires allow you the capability to drive 50 miles When stuck in mud, sand, snow, or ice conditions, do not (80 km) at 50 mph (80 km/h) after a rapid loss of inflation spin your vehicle's wheels above 30 mph (48 km/h) or for pressure.
Page 438 436 SERVICING AND MAINTENANCE Refer to “Replacement Tires” in this section for further infor- Tread Wear Indicators mation. Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: •...
Page 439 SERVICING AND MAINTENANCE NOTE: It is recommended to replace the two front tires or two rear Wheel Valve Stem must be replaced as well when installing tires as a pair. Replacing just one tire can seriously affect new tires due to wear and tear in existing tires. your vehicle’s handling.
Page 440: Tire Types
438 SERVICING AND MAINTENANCE tire sidewall. Use all season tires only in sets of four; failure WARNING! (Continued) to do so may adversely affect the safety and handling of your • Never use a tire with a smaller load index or capacity, vehicle.
Page 441: Spare Tires - If Equipped
SERVICING AND MAINTENANCE Spare Tires — If Equipped Snow Tires Some areas of the country require the use of snow tires NOTE: during the Winter. Snow tires can be identified by a “moun- For vehicles equipped with Tire Service Kit instead of a spare tain/snowflake”...
Page 442 440 SERVICING AND MAINTENANCE This spare tire may be used in the tire rotation for your WARNING! vehicle. If your vehicle has this option, refer to an authorized Compact and collapsible spares are for temporary tire dealer for the recommended tire rotation pattern. emergency use only.
Page 443: Tire Chains (Traction Devices)
SERVICING AND MAINTENANCE Tire Chains (Traction Devices) Limited Use Spare — If Equipped The limited use spare tire is for temporary emergency use Use of traction devices require sufficient tire-to-body clear- only. This tire is identified by a label located on the limited ance.
Page 444: Tire Rotation Recommendations
442 SERVICING AND MAINTENANCE Tire Rotation Recommendations CAUTION! To avoid damage to your vehicle or tires, observe the The tires on the front and rear of your vehicle operate at following precautions: different loads and perform different steering, handling, and braking functions.
Page 445 SERVICING AND MAINTENANCE The suggested Front Wheel Drive (FWD) rotation method is the “forward cross” shown in the following diagram. This rotation pattern does not apply to some directional tires that must not be reversed. Tire Rotation (Rearward Cross) CAUTION! Proper operation of four-wheel drive vehicles depends on tires of equal size, type and circumference on each Tire Rotation (Forward Cross)
Page 446: Department Of Transportation Uniform Tire Quality Grades
444 SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION UNIFORM Traction Grades TIRE QUALITY GRADES The Traction grades, from highest to lowest, are AA, A, B, The following tire grading categories were established by and C. These grades represent the tire's ability to stop on the National Highway Traffic Safety Administration.
Page 447: Storing The Vehicle
SERVICING AND MAINTENANCE Sustained high temperature can cause the material of the • Disconnect the negative (-) terminal from the battery post tire to degenerate and reduce tire life, and excessive and be sure that the battery is fully charged. During storage check battery charge quarterly.
Page 448: Bodywork
446 SERVICING AND MAINTENANCE • Do not drain the engine cooling system. BODYWORK • Whenever you leave the vehicle stationary for two weeks Protection From Atmospheric Agents or more, idle the engine for approximately five minutes, with the air conditioning system on and high fan speed. Vehicle body care requirements vary according to This will ensure proper lubrication of the system, thus geographic locations and usage.
Page 449: Body And Underbody Maintenance
SERVICING AND MAINTENANCE Your wheels are susceptible to deterioration caused by salt, What Causes Corrosion? sodium chloride, magnesium chloride, calcium chloride, etc., Corrosion is the result of deterioration or removal of paint and other road chemicals used to melt ice or control dust on and protective coatings from your vehicle.
Page 450 448 SERVICING AND MAINTENANCE When cleaning extremely dirty wheels including excessive Dark Vapor Chrome, Black Satin Chrome, or Low Gloss Clear Coat Wheels brake dust, care must be taken in the selection of tire and wheel cleaning chemicals and equipment to prevent damage to the CAUTION! wheels.
Page 451: Preserving The Bodywork
SERVICING AND MAINTENANCE Do not use abrasive cleaning components, solvents, steel Special Care wool or other aggressive material to clean the lenses. • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month. Preserving The Bodywork •...
Page 452: Interiors
450 SERVICING AND MAINTENANCE • For grease stains, apply Mopar Multi-Purpose Cleaner to a INTERIORS clean, damp cloth and remove stain. Use a fresh, damp Seats And Fabric Parts towel to remove soap residue. Use Mopar Total Clean to clean fabric upholstery and •...
Page 453: Plastic And Coated Parts
SERVICING AND MAINTENANCE Cleaning Plastic Instrument Cluster Lenses WARNING! A frayed or torn belt could rip apart in a collision and The lenses in front of the instruments in this vehicle are leave you with no protection. Inspect the belt system molded in clear plastic.
Page 454: Glass Surfaces
452 SERVICING AND MAINTENANCE cleaning fluids, solvents, detergents, or ammonia-based Glass Surfaces cleaners to clean your leather upholstery. Application of a All glass surfaces should be cleaned on a regular basis with leather conditioner is not required to maintain the original Mopar Glass Cleaner, or any commercial household-type condition.
Page 455: Technical Specifications
TECHNICAL SPECIFICATIONS IDENTIFICATION DATA Vehicle Identification Number The Vehicle Identification Number (VIN) is found on the left front corner of the windshield and is visible from the outside of the vehicle. The VIN number also is stamped into the right front body, on the front floor.
Page 456 454 TECHNICAL SPECIFICATIONS Right Front Body VIN Location Opening The VIN Door NOTE: It is illegal to remove or alter the VIN.
Page 457: Wheel And Tire Torque Specifications
TECHNICAL SPECIFICATIONS WHEEL AND TIRE TORQUE SPECIFICATIONS Proper lug nut/bolt torque is very important to ensure that the wheel is properly mounted to the vehicle. Any time a wheel has been removed and reinstalled on the vehicle, the lug nuts/bolts should be torqued using a properly calibrated torque wrench using a high quality six sided (hex) deep wall socket.
Page 458: Fuel Requirements
456 TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS 2.4L Engine This engine is designed to meet all emissions regula- tions and provide excellent fuel economy and performance when using high quality unleaded “regular” gasoline having a octane rating of 87 using the (R+M)/2 method. The use of premium gasoline is not recom- mended, as it will not provide any benefit over regular gaso- line in these engines.
Page 459: Reformulated Gasoline
TECHNICAL SPECIFICATIONS Problems that result from using gasoline containing more Reformulated Gasoline than 15% ethanol (E-15) or gasoline containing methanol are Many areas of the country require the use of cleaner burning not the responsibility of the manufacturer and may void or gasoline referred to as “Reformulated Gasoline”.
Page 460: Cng And Lp Fuel System Modifications
458 TECHNICAL SPECIFICATIONS CNG And LP Fuel System Modifications Materials Added To Fuel Modifications that allow the engine to run on compressed Besides using unleaded gasoline with the proper octane natural gas (CNG) or liquid propane (LP) may result in rating, gasolines that contain detergents, corrosion and damage to the engine, emissions, and fuel system compo- stability additives are recommended.
Page 461: Fuel System Cautions
TECHNICAL SPECIFICATIONS NOTE: Fuel System Cautions Intentional tampering with the emissions control system can CAUTION! result in civil penalties being assessed against you. Follow these guidelines to maintain your vehicle’s Carbon Monoxide Warnings performance: WARNING! • The use of leaded gasoline is prohibited by Federal law.
Page 462: Fluid Capacities
460 TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 2.4L Gasoline Engine 13.5 Gallons 51 Liters Engine Oil With Filter 5.2 Liters 2.4L Gasoline Engine (SAE 0W-20, API Certified) 5.5 Quarts Cooling System* 2.4L Gasoline Engine (Mopar Antifreeze/Engine 6.8 Quarts 6.5 Liters Coolant 10 Year/150,000 Mile Formula) * Includes heater and coolant recovery bottle filled to MAX level.
Page 463: Fluids And Lubricants
TECHNICAL SPECIFICATIONS FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Engine Coolant (240,000 Kilometers) Formula OAT (Organic Additive Technology) meeting the requirements of FCA Material Standard MS.90032. We recommend you use SAE 0W-20 API Certified Engine Oil, meeting the requirements of FCA Material Standard MS-6395 such as Mopar, Engine Oil –...
Page 464: Chassis
462 TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar C Series Manual & Dual Dry Clutch Manual Transmission – If Equipped Transmission Fluid. Use only Mopar AW-1 Automatic Transmission Fluid, or Six-Speed Automatic Transmission (FWD Models) – equivalent.
Page 465: Multimedia
MULTIMEDIA UCONNECT SYSTEMS For detailed information about your Uconnect system or pairing a phone to your Uconnect system, refer to your Uconnect Owner’s Manual Supplement. NOTE: Uconnect screen images are for illustration purposes only and may not reflect exact software for your vehicle. DRAG &...
Page 466: Cybersecurity
464 MULTIMEDIA CYBERSECURITY WARNING! • It is not possible to know or to predict all of the Your vehicle may be a connected vehicle and may be possible outcomes if your vehicle’s systems are equipped with both wired and wireless networks. These breached.
Page 467: Uconnect Settings
MULTIMEDIA NOTE: UCONNECT SETTINGS • FCA US LLC or your dealer may contact you directly The Uconnect system uses a combination of buttons on the regarding software updates. touchscreen and buttons on the faceplate located on the • To help further improve vehicle security and minimize the center of the instrument panel.
Page 468: Customer Programmable Features - Uconnect 3
466 MULTIMEDIA Push the Settings button on the touchscreen to display the Customer Programmable Features — Uconnect 3 settings menu screen. In this mode the Uconnect system Settings allows you to access all of the available programmable features. NOTE: Only one touchscreen area may be selected at a time. When making a selection, press the button on the touch- screen to enter the desired mode.
Page 469 MULTIMEDIA Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto Manual Brightness NOTE: The “Brightness” setting can also be adjusted by selecting any point on the scale between the + and - buttons on the touch- screen.
Page 470 468 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measurement. • The “Custom” option allows setting the “Fuel Consumption” (L/100km, or km/L) and “Pressure” (kPa, or bar) units of measurement independently.
Page 471 MULTIMEDIA Setting Name Selectable Options Set Date Up Arrow Down Arrow NOTE: Within the “Set Date” setting, press the corresponding Arrow buttons on the touchscreen to adjust to the correct date. Show Time Status — If Equipped Sync Time — If Equipped Safety/Assistance After pressing the Safety/Assistance button on the touchscreen, the following settings will be available: Setting Name...
Page 472 470 MULTIMEDIA Setting Name Selectable Options Forward Collision Warning Plus (FCW+) Sensitivity — If Near Equipped NOTE: The “Forward Collision Warning Plus (FCW+) Sensitivity” setting determines at what relative distance the vehicle directly in front of you needs to be at before the system will warn you of a possible collision, based on the option selected. “Far” will give you the most amount of reaction time, whereas “Near”...
Page 473 MULTIMEDIA Setting Name Selectable Options NOTE: The “LaneSense Warning” setting determines at what distance the LaneSense system will warn you, through steering wheel feedback, of a possible lane departure. LaneSense Strength — If Medium High Equipped Blind Spot Alert — If Lights Lights and Chime Equipped...
Page 474 472 MULTIMEDIA Brakes — If Equipped After pressing the Brakes button on the touchscreen the following setting will be available: Setting Name Selectable Options Auto Park Brake Lights After pressing the Lights button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Sensitivity —...
Page 475 MULTIMEDIA Setting Name Selectable Options Daytime Running Lights NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. This feature is only allowed by law in the country of the vehicle purchase. Cornering Lights NOTE: When the “Cornering Lights”...
Page 476 474 MULTIMEDIA Doors & Locks After pressing the Doors & Locks button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto Unlock On Exit NOTE: When this feature is selected, all doors will unlock when the vehicle is stopped and the transmission is in the PARK or NEUTRAL (N) position and the driver's door is opened.
Page 477 MULTIMEDIA Setting Name Selectable Options Auto Door Locks — If Equipped NOTE: When this feature is selected, all doors will lock automatically when the vehicle reaches a speed of 12 mph (20 km/h). Auto Comfort Systems — If Equipped After pressing the Auto-On Comfort Systems button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated Seat &...
Page 478 476 MULTIMEDIA Engine Off Options After pressing the Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay 0 sec 30 sec 60 sec 90 sec NOTE: When this feature is selected, it allows the adjustment of the amount of time the headlights remain on after the engine is shut off.
Page 479 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Equalizer Bass Treble NOTE: When in this display, you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the + and – setting buttons on the touchscreen or by selecting any point on the scale between the + and –...
Page 480 478 MULTIMEDIA Setting Name Selectable Options NOTE: The “Loudness” feature improves sound quality at lower volumes when enabled. AUX Volume Offset — If Equipped NOTE: The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input.
Page 481 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Channel Skip List of Channels NOTE: SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude unde- sirable channels while scanning.
Page 482 480 MULTIMEDIA Restore Settings After pressing the Restore Settings button on the touchscreen, the following settings will be available: Setting Name Selectable Options Restore Settings Cancel NOTE: When the “Restore Settings” feature is selected, it will reset all of the audio settings to their default settings. Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following settings will be available: Setting Name...
Page 483: Customer Programmable Features - Uconnect 4
MULTIMEDIA Press the Settings button on the bottom bar, or press the Customer Programmable Features — Uconnect 4 Apps button, then press the Settings button on the touch- Settings screen to display the menu setting screen. In this mode the Uconnect system allows you to access all of the available programmable features.
Page 484 482 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Français Español Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode...
Page 485 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measurement. • The “Custom” option allows setting the “Distance, Fuel Consumption” (MPG (US), MPG(UK), L/100km, or km/L),“Pres- sure”...
Page 486 484 MULTIMEDIA Time & Date After pressing the Time & Date button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. Set Time Minutes NOTE: The “Set Time Minutes”...
Page 487 MULTIMEDIA Safety/Driving Assistance — If Equipped After pressing the Safety/Driving Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning Plus (FCW+) — If Warning + Active Warning Only Equipped Braking NOTE: The “Forward Collision Warning Plus (FCW+)”...
Page 488 486 MULTIMEDIA Setting Name Selectable Options LaneSense Strength — If Equipped High ParkSense — If Equipped Sound Sound and Display Rear ParkSense Volume Medium High Blind Spot Alert — If Equipped Lights Lights and Chime NOTE: If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged, the sensor may have become misaligned.
Page 489 MULTIMEDIA Brakes After pressing the Brakes button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto Park Brake Brake Service — If Equipped NOTE: Selecting the “Brake Service” feature will display a pop-up asking whether you would like to retract the park brakes to allow brake system service.
Page 490 488 MULTIMEDIA Setting Name Selectable Options Headlight Off Delay NOTE: When the “Headlight Off Delay” feature is selected, it allows the adjustment of the amount of time the headlights remain on after the engine is shut off. Greeting Lights Daytime Running Lights NOTE: When the “Daytime Running Lights”...
Page 491 MULTIMEDIA Doors & Locks After pressing the Doors & Locks button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto Unlock On Exit NOTE: When this feature is selected, all doors will unlock when the vehicle is stopped and the transmission is in the PARK or NEUTRAL (N) position and the driver's door is opened.
Page 492 490 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance & Fade NOTE: When in this display, you may adjust the “Balance & Fade” of the audio by pressing and dragging the “Speaker Icon” toward any location in the box.
Page 493 MULTIMEDIA Setting Name Selectable Options Auto Play — If Equipped NOTE: The “Auto Play” feature automatically starts playing audio when a USB device is connected and turned on. Radio Off With Door — If Equipped NOTE: The “Radio Off With Door” feature will keep the radio on until the driver or passenger door is opened, or when the “Radio Off Delay”...
Page 494 492 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Channel Skip List Of Channels NOTE: SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude unde- sirable channels while scanning.
Page 495 MULTIMEDIA Restore Settings After pressing the Restore Settings button on the touchscreen, the following settings will be available: Setting Name Selectable Options Restore Settings Cancel NOTE: When this feature is selected it will reset the audio settings to their default. Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following settings will be available: Setting Name...
Page 496: Customer Programmable Features - Uconnect 4C/4C Nav Settings
494 MULTIMEDIA Press the Apps button, then press the Settings button Customer Programmable Features — Uconnect 4C/ on the touchscreen to display the menu setting screen. In this 4C NAV Settings mode the Uconnect system allows you to access all of the available programmable features.
Page 497 MULTIMEDIA Language After pressing the Set Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Language NOTE: When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 498 496 MULTIMEDIA Setting Name Selectable Options Display Brightness With Headlights OFF NOTE: To make changes to the "Display Brightness With Headlights OFF" setting, the headlights must be off and the interior dimmer switch must not be in the "party" or "parade" position. Set Theme Options NOTE: When in this display, you may select the theme for the display screen.
Page 499 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measurement. • The “Custom” option allows setting the “Fuel Consumption” (L/100km, or km/L), “Pressure” (kPa, or bar), and “Temperature”...
Page 500 498 MULTIMEDIA Clock & Date After pressing the Clock button on the touchscreen, the following settings will be available: Setting Name Selectable Options Sync Time With GPS — If Equipped Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. The “Sync Time With GPS” button on the touchscreen must be unchecked.
Page 501 MULTIMEDIA Camera After pressing the Camera button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to 10 seconds after the vehicle is shifted out of REVERSE (R).
Page 502 500 MULTIMEDIA Safety & Driving Assistance After pressing the Safety & Driving Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning Sensitivity — If Near Medium Equipped NOTE: The “Forward Collision Warning Sensitivity” setting determines at what relative distance the vehicle directly in front of you needs to be at before the system will warn you of a possible collision based on the option selected.
Page 503 MULTIMEDIA Setting Name Selectable Options ParkSense — If Equipped Sound Only Sound & Display Rear ParkSense Volume High Blind Spot Alert — If Equipped Lights Lights & Chime NOTE: If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged, the sensor may have become misaligned.
Page 504 502 MULTIMEDIA Brakes After pressing the Brakes button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto Park Brake Brake Service — If Equipped NOTE: This feature provides a means for a technician or vehicle owner to utilize a vehicle integrated, menu driven system, to command the electric park brake retraction, to service the rear foundation brakes (brake pads, calipers, rotors, etc.).
Page 505 MULTIMEDIA Setting Name Selectable Options Headlight Illumination On Approach 0 sec 30 sec 60 sec 90 sec Greeting Lights — If Equipped Daytime Running Lights NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. This feature is only allowed by law in the country of the vehicle purchase.
Page 506 504 MULTIMEDIA Doors & Locks After pressing the Doors & Locks button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto Unlock On Exit NOTE: When the “Auto Unlock On Exit” feature is selected, all doors will unlock when the vehicle is stopped, the transmission is in the PARK or NEUTRAL (N) position, and the driver's door is opened.
Page 507 MULTIMEDIA Setting Name Selectable Options NOTE: When "Driver Door" is selected with 1st Press Of Key Fob Unlocks, only the driver's door will unlock with the first press of the key fob unlock button. You must press the key fob unlock button twice to unlock the passengers’ doors. When "All Doors" is programmed for 1st Press Of Key Fob Unlocks, all doors will unlock on the first press of the key fob unlock button.
Page 508 506 MULTIMEDIA Auto-On Comfort Systems — If Equipped After pressing the Auto-On Comfort Systems button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated Seat & Steering Wheel With Vehicle Start — If Remote Start All Starts Equipped...
Page 509 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance/Fade Speaker Icon NOTE: When in this display, you may adjust the “Balance/Fade” of the audio by pressing and dragging the Speaker Icon toward any location in the box.
Page 510 508 MULTIMEDIA Phone/Bluetooth® After pressing the Phone/Bluetooth® button on the touchscreen, the following settings will be available: Setting Name Selectable Options Do Not Disturb List of Settings NOTE: Press “Do Not Disturb” to access the available settings. The following settings are: Auto Reply (both, text, call), Auto Reply Message (custom, default), and Custom Auto Reply Message (create message).
Page 511 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Tune Start Channel Skip List Of Channels NOTE: SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude unde- sirable channels while scanning.
Page 512 510 MULTIMEDIA Reset After pressing the Reset button on the touchscreen, the following settings will be available: Setting Name Selectable Options Reset App Drawer Cancel Restore Settings Cancel NOTE: When this feature is selected, it will reset all of the audio settings to their default settings. Clear Personal Data Cancel NOTE:...
Page 513: Steering Wheel Audio Controls - If Equipped
MULTIMEDIA Pushing the center button will make the radio switch STEERING WHEEL AUDIO CONTROLS — IF between the various modes available (AM/FM/SXM or EQUIPPED Media etc.). The remote sound system controls are located on the rear The left-hand control is a rocker-type switch with a surface of the steering wheel at the three and nine o’clock push-button in the center.
Page 514: Aux/Usb/Mp3 Control
512 MULTIMEDIA The USB port allows interaction with a connected smart- AUX/USB/MP3 CONTROL phone via Android Auto™ or Apple CarPlay® if the vehicle There is a USB and AUX Jack in the center console. This is equipped with a Uconnect 4/4C NAV. The port is for feature allows an external device to be plugged into the USB charge only if the vehicle is equipped with a Uconnect 3 with or AUX ports.
Page 515: Radio Operation And Mobile Phones
MULTIMEDIA The radio manufacturer believes the internal wireless radio RADIO OPERATION AND MOBILE PHONES is safe for use by consumers. The level of energy emitted is Under certain conditions, the mobile phone being on in your far less than the electromagnetic energy emitted by wireless vehicle can cause erratic or noisy performance from your devices such as mobile phones.
Page 516 514 MULTIMEDIA Le présent appareil est conforme aux CNR d`Innovation, NOTE: Science and Economic Development applicables aux appar- • This equipment has been tested and found to comply with eils radio exempts de licence. L'exploitation est autorisée aux the limits for a Class B digital device, pursuant to Part 15 deux conditions suivantes: of the FCC Rules.
Page 517: Uconnect Voice Recognition Quick Tips
MULTIMEDIA UCONNECT VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect 3, Uconnect 4, or Uconnect 4C/4C NAV system. Uconnect 4 Uconnect 3...
Page 518: Get Started
516 MULTIMEDIA Get Started All you need to control your Uconnect system with your voice are the buttons on your steering wheel. Helpful hints for using Voice Recognition: • Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instruc- tions.
Page 519: Basic Voice Commands
MULTIMEDIA • You can interrupt the help message or system prompts by Basic Voice Commands pushing the VR or Phone button and saying a Voice The basic Voice Commands below can be given at any point Command from the current category. while using your Uconnect system.
Page 520: Radio
518 MULTIMEDIA Radio Use your voice to quickly get to the AM, FM, or SiriusXM® Satellite Radio stations you would like to hear. (Subscription or included SiriusXM® Satellite Radio trial required.) Push the VR button . After the beep, say: •...
Page 521 MULTIMEDIA Uconnect 4 Radio Uconnect 4C/4C NAV Radio...
Page 522: Media
520 MULTIMEDIA TIP: Media Press the Browse button on the touchscreen to see all of the Uconnect offers connections via USB, Bluetooth®, and auxil- music on your USB device. Your Voice Command must iary ports (if equipped). Voice operation is only available for match exactly how the artist, album, song, and genre infor- connected USB and AUX devices.
Page 523 MULTIMEDIA Uconnect 4 Media Uconnect 4C/4C NAV Media...
Page 524: Phone
522 MULTIMEDIA TIP: Phone When providing a Voice Command, push the VR button Making and answering hands-free phone calls is easy with or Phone button and say “Call”, then pronounce the name Uconnect. When the Phonebook button is illuminated on exactly as it appears in your phone book.
Page 525 MULTIMEDIA Uconnect 4 Phone Uconnect 4C/4C NAV Phone...
Page 526: Voice Text Reply - If Equipped
524 MULTIMEDIA Voice Text Reply — If Equipped PRE-DEFINED VOICE TEXT REPLY RESPONSES Yes. Stuck in traffic. See you later. Uconnect announces incoming text messages. Push the VR Start without me. I’ll be late. button or Phone button (if enabled) and say “Listen”. (Must have compatible mobile phone paired to Uconnect Okay.
Page 527: Climate
MULTIMEDIA Apple® iPhone® iOS 6 or higher supports reading incoming TIP: text messages only. To enable this feature on your Apple® Voice Text Reply is not compatible with iPhone®, but if your iPhone®, follow these four simple steps: vehicle is equipped with Siri® Eyes Free, you can use your voice to send a text message.
Page 528 526 MULTIMEDIA TIP: Voice Command for Climate may only be used to adjust the interior temperature of your vehicle. Voice Command will not work to adjust the heated seats or steering wheel if equipped. Uconnect 4C/4C NAV Climate Uconnect 4 Climate...
Page 529: Navigation (4C Nav) - If Equipped
MULTIMEDIA Navigation (4C NAV) — If Equipped The Uconnect navigation feature helps you save time and become more productive when you know exactly how to get to where you want to go. 1. To enter a destination, push the VR button .
Page 530: Siriusxm Guardian™ (4C/4C Nav) - If Equipped
528 MULTIMEDIA NOTE: SiriusXM Guardian™ (4C/4C NAV) — If Equipped SiriusXM Guardian™ is available only on equipped vehicles CAUTION! purchased within the continental United States, Alaska, Hawaii, and Canada. Services can only be used where Some SiriusXM Guardian™ services, including SOS coverage is available;...
Page 531: Register (4C/4C Nav)
MULTIMEDIA Register (4C/4C NAV) Mobile App (4C/4C NAV) To unlock the full potential of SiriusXM Guardian™ in your You’re only a few steps away from using remote commands vehicle, you must activate your SiriusXM Guardian™ and sending a destination from your phone to your vehicle. services.
Page 532: Siriusxm® Travel Link (4C Nav)
530 MULTIMEDIA 2. Once on the “Remote” screen, you can begin using Push the VR button . After the beep, say one of the Remote Door Lock/Unlock, Remote Vehicle Start, and following commands: activate your horn and lights remotely, if equipped. •...
Page 533: Siri® Eyes Free - If Equipped
MULTIMEDIA Siri® Eyes Free — If Equipped Siri lets you use your voice to send text messages, select media, place phone calls and much more. Siri uses your natural language to understand what you mean and responds back to confirm your requests. The system is designed to keep your eyes on the road and your hands on the wheel by letting Siri help you perform useful tasks.
Page 534: Using Do Not Disturb
532 MULTIMEDIA Using Do Not Disturb Android Auto™ — If Equipped With Do Not Disturb, you can disable notifications from NOTE: incoming calls and texts, allowing you to keep your eyes on Feature availability depends on your carrier and mobile the road and hands on the wheel.
Page 535 MULTIMEDIA VR, which recognizes natural voice commands, to use a list of your smartphone’s features: • Maps • Music • Phone • Text Messages • Additional Apps Android Auto™ On 8.4-inch Display Refer to your Uconnect Owner’s Manual Supplement for further information.
Page 536: Apple Carplay® - If Equipped
534 MULTIMEDIA • Messages Apple CarPlay® — If Equipped • Maps — If Equipped NOTE: Feature availability depends on your carrier and mobile • Additional Apps — If Equipped phone manufacturer. Some Apple CarPlay® features may or may not be available in every region and/or language. Apple CarPlay®...
Page 537: General Information
MULTIMEDIA NOTE: Requires compatible iPhone®. See dealer for phone compat- ibility. Data plan rates apply. Vehicle user interface is a product of Apple®. Apple CarPlay® is a trademark of Apple® Inc. iPhone® is a trademark of Apple® Inc., regis- tered in the US and other countries. Apple® terms of use and privacy statements apply.
Page 538: Additional Information
536 MULTIMEDIA Le présent appareil est conforme aux CNR d`Innovation, Additional Information Science and Economic Development applicables aux appar- © 2019 FCA US LLC. All rights reserved. Mopar and Ucon- eils radio exempts de licence. L'exploitation est autorisée aux nect are registered trademarks and Mopar Owner Connect is deux conditions suivantes: a trademark of FCA US LLC.
Page 539: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with the service Prepare For The Appointment advisor and list the items in order of priority.
Page 540: Fca Us Llc Customer Center
538 CUSTOMER ASSISTANCE This is why you should always talk to an authorized dealer FCA Canada Inc. Customer Center service manager first. Most matters can be resolved with this P.O. Box 1621 process. • If for some reason you are still not satisfied, talk to the Windsor, Ontario N9A 4H6 general manager or owner of the authorized dealer.
Page 541: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
CUSTOMER ASSISTANCE the vehicle delivery date. If you have any questions about the Customer Assistance For The Hearing Or Speech service contract, call the manufacturer's Service Contract Impaired (TDD/TTY) National Customer Hotline at 1-800-521-9922 (Canadian resi- To assist customers who have hearing difficulties, the manu- dents, call (800) 465-2001 English / (800) 387-9983 French).
Page 542: Warranty Information
540 CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS WARNING! Engine exhaust (internal combustion engines only), In The 50 United States And Washington, D.C. some of its constituents, and certain vehicle components If you believe that your vehicle has a defect that could contain, or emit, chemicals known to the State of cause a crash or cause injury or death, you should imme- California to cause cancer and birth defects, or other...
Page 543: In Canada
CUSTOMER ASSISTANCE Diagnostic Procedure Manuals In Canada If you believe that your vehicle has a safety defect, you Diagnostic Procedure Manuals are filled with diagrams, charts and detailed illustrations. These practical manuals should contact the Customer Service Department imme- make it easy for students and technicians to find and fix diately.
Page 544 INDEX Air Conditioning Filter.............88, 408 Adaptive Cruise Control (ACC) (Cruise Control) .....274 Air Conditioning, Operating Tips ..........87 Adding Engine Coolant (Antifreeze) ........416 Air Filter ...................407 Additives, Fuel ................458 Air Pressure Air Bag..................193 Tires..................433 Air Bag Operation ...............195 Alarm Air Bag Warning Light..........191, 196 Arm The System ..............31 Driver Knee Air Bag ............203 Disarm The System ...............31...
Page 545 Auto Unlock, Doors..............40 B-Pillar Location..............428 Auto Up Power Windows ............90 Brake Assist System ..............146 Automatic Dimming Mirror............58 Brake Control System, Electronic .........146 Automatic Door Locks .............40 Brake Fluid ................462 Automatic Headlights ..............65 Brake System................419 Automatic High Beams ............64 Fluid Check ..............419, 462 Automatic Temperature Control (ATC) ........87 Master Cylinder..............419 Automatic Transaxle ..............253...
Page 546 Cellular Phone .................513 Coin Holder ................106 Certification Label..............316 Cold Weather Operation............239 Chains, Tire................441 Compact Spare Tire ..............440 Change Oil Indicator ..............116 Computer, Trip/Travel ............127 Changing A Flat Tire ............365, 422 Connector Chart, Tire Sizing ..............424 Universal Consumer Interface (UCI)........512 Check Engine Light (Malfunction Indicator Light) ...142 Console ..................106 Checking Your Vehicle For Safety........232...
Page 547 Electronic Speed Control (Cruise Control)......270 Daytime Running Lights ........... 63, 64 Electronic Stability Control (ESC).........148 Dealer Service ................405 Electronic Throttle Control Warning Light ......130 Defroster, Windshield ............233 Emergency Gas Can Refueling..........388 Diagnostic System, Onboard..........141 Emergency, In Case Of Dimmer Switch Hazard Warning Flasher............333 Headlight................
Page 548 Oil Synthetic.................406 Fluid Capacities ...............460 Overheating .................389 Fluid Leaks................235 Starting................236, 237 Fluid Level Checks Engine Oil Viscosity ...............406 Brake..................419 Engine Oil Viscosity Chart ............406 Engine Oil................403 Enhanced Accident Response Feature......210, 397 Fluid, Brake ................462 Ethanol..................457 Fluids And Lubricants............461 Exhaust Gas Cautions ............232, 459 Fog Lights................63, 66 Exhaust System ...............232, 412 Fold-Flat Seats ................41...
Page 549 High Beam/Low Beam Select (Dimmer) Switch....64 Gas Cap (Fuel Filler Cap)............314 Hill Descent Control ...............153 Gasoline, (Fuel) ...............456 Hill Descent Control Indicator ..........153 Gasoline, Clean Air..............457 Hill Start Assist................155 Gasoline, Reformulated ............457 Holder, Coin ................106 Gear Ranges ..............250, 256 Holder, Cup ................106 Gear Selector Override............390 Hood Prop..................96 Glass Cleaning.................452...
Page 550 Liftgate..................97, 98 Jack Location................366 Liftgate Window Wiper/Washer ...........72 Jack Operation ............365, 369, 422 Light Bulbs ................235 Jacking Instructions ..............369 Lights ..................235 Jump Starting................384 Air Bag ................191, 233 Automatic Headlights ............65 Key Fob Battery Saver ................67 Arm The Alarm ..............31 Brake Assist Warning ............152 Disarm The Alarm ..............31 Brake Warning ..............128 Programming Additional Key Fobs ......20, 30...
Page 551 Low Fuel................134 Lug Nuts/Bolts................455 Malfunction Indicator (Check Engine)......134 Luggage Carrier ..............110 Park ..................139 Passing ................63, 65 Maintenance................95 Seat Belt Reminder..............132 Maintenance Free Battery ............404 Security Alarm..............132 Maintenance Schedule............398 Service...................339 Malfunction Indicator Light (Check Engine) ....134, 142 Tire Pressure Monitoring (TPMS)........170 Manual Traction Control ..............152 Service ...................541...
Page 552 Modifications/Alterations Synthetic ................406 Vehicle ..................13 Viscosity................406, 460 Monitor, Tire Pressure System..........170 Onboard Diagnostic System ..........141 Mopar Parts ................540 Operating Precautions............141 Multi-Function Control Lever..........63 Operator Manual Owner's Manual ............12, 541 New Vehicle Break-In Period..........242 Outlet Power ..................107 Occupant Restraints..............176 Outside Rearview Mirrors ..........58, 59 Octane Rating, Gasoline (Fuel) ........456, 461 Overheating, Engine ...............389 Oil Filter, Change..............407...
Page 553 Pregnant Women And Seat Belts..........188 Programming Additional Key Fobs ......20, 30 Preparation For Jacking ............368 Remote Sound System (Radio) Control .......511 Pretensioners Remote Starting Seat Belts................188 Exit Remote Start Mode............27 Uconnect Customer Programmable Features ....27 Radial Ply Tires ...............434 Uconnect Settings ..............27 Radiator Cap (Coolant Pressure Cap)........
Page 554 Adjustable Upper Shoulder Anchorage ......183 Seatback Release ..............44 Adjustable Upper Shoulder Belt Anchorage....183 Tilting ..................41 Child Restraints ..............214 Ventilated ................52 Energy Management Feature ..........188 Security Alarm..............31, 132 Extender................187 Arm The System ..............31 Front Seat..............178, 179, 181 Disarm The System ...............31 Inspection ................233 Selection Of Coolant (Antifreeze) .........461 Lap/Shoulder Belt Operation ...........
Page 555 Spare Tires..............439, 440, 441 Storage ..................105 Spark Plugs ................461 Storage, Vehicle .................88 Specifications Stuck, Freeing ................391 Fuel (Gasoline)..............461 Sun Roof ................92, 95 Oil ..................461 Sun Visor ..................63 Speed Control Supplemental Restraint System – Air Bag......193 Cancel..................273 Sway Control, Trailer .............157 Distance Setting (ACC Only)..........274 Synthetic Engine Oil ...............406 Mode Setting (ACC Only)..........274...
Page 556 General Information ...........432, 439 Tow Hooks High Speed................434 Emergency................396 Inflation Pressure ..............433 Towing..................317 Jacking ................365, 422 Disabled Vehicle ..............393 Life Of Tires .................436 Guide..................320 Load Capacity..............428, 429 Recreational................327 Pressure Monitoring System (TPMS).......136, 170 Weight...................320 Quality Grading ..............444 Towing Behind A Motorhome ..........327 Radial ..................434 Traction Control ..............146 Replacement.................437...
Page 557 Transaxle Automatic................253 Vanity Mirrors ................62 Operation................253 Vehicle Identification Number (VIN) ........453 Transfer Case Vehicle Loading...............316, 429 Fluid ..................462 Vehicle Modifications/Alterations.........13 Transmission................255 Vehicle Security Alarm.............31 Automatic..............255, 421 Vehicle Storage ................88 Fluid ..................462 Vehicle User Guide Maintenance.................421 In Vehicle Help ..............14 Manual..................248 Navigation................14 Transporting Pets..............232...
Page 558 Windows ..................89 Warning Lights (Instrument Cluster Descriptions) ...134 Close ..................89 Warnings And Cautions ............13 Down..................89 Warnings, Roll Over ..............12 Open ..................89 Warranty Information ............540 Power ..................89 Washers, Windshield ............70, 403 Up ....................89 Washing Vehicle ..............449 Windshield Defroster .............233 Wheel And Wheel Tire Care ..........447 Windshield Washers............70, 403 Wheel And Wheel Tire Trim ..........447...
Page 559 Mobile radio equipment with output power greater than INSTALLATION OF RADIO TRANSMITTING normal may require special precautions. EQUIPMENT Special design considerations are incorporated into this All installations should be checked for possible interference between the communications equipment vehicle’s electronic system to provide immunity to radio and the vehicle’s electronic systems.
Page 560 ©2019 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep Compass 2020 Owner's Manual

Introduction

Getting to Know Your Vehicle

3 Getting to Know Your Instrument Panel

Safety

Quick Links

Related Manuals for Jeep Compass 2020

Summary of Contents for Jeep Compass 2020
