Page 1 2 02 2 G LAD IATOR OW NE R’ S M ANUAL...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................8 GETTING TO KNOW YOUR VEHICLE.
Page 4 INTRODUCTION Keyless Enter ‘n Go™ — Passive Entry Identifying Whether You Have A Rolling Code Or (If Equipped) ....23 Non-Rolling Code Device ....47 SYMBOLS KEY .
Page 5 ONBOARD DIAGNOSTIC SYSTEM — OBD II ..120 BED RAIL TIE DOWN SYSTEM — IF EQUIPPED ..94 Jeep® Wireless Speaker — If Equipped ..62 Onboard Diagnostic System (OBD II) Power Outlets .
Page 6 REFUELING THE VEHICLE — DIESEL ENGINE Engine Idling ....127 To Start The Engine While In Autostop Mode . 143 (IF EQUIPPED) ..... 162 Stopping The Engine .
Page 7 UCONNECT MODES ....199 Connected Services Account FAQs — Periodic Safety Checks You Should Make Steering Wheel Audio Controls — If Equipped . 199 If Equipped .
Page 8 SERVICING AND MAINTENANCE Brake System ....321 TECHNICAL SPECIFICATIONS Front/Rear Axle Fluid ....322 SCHEDULED SERVICING —...
Page 9 Puerto Rico And U.S. Virgin Islands ..364 Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) ... 364 WARRANTY INFORMATION ....365 MOPAR®...
Page 10: Introduction
FCA US LLC aims towards a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Jeep® best, have factory-trained technicians, genuine Mopar® parts, and care about your satisfaction.
Page 11: Symbols Key
INTRODUCTION SYMBOLS KEY ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of vehicles. This vehicle has a higher ground clearance and a higher center of gravity than many pas- WARNING! These statements are against operating senger vehicles.
Page 12: Vehicle Modifications/Alterations
INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS Red Warning Lights Door Open Warning Light WARNING! page 113 Any modifications or alterations to this vehicle could seriously affect its roadworthi- ness and safety and may lead to a collision resulting in serious injury or death. Electric Power Steering (EPS) Fault Warning Light page 113 SYMBOL GLOSSARY...
Page 13 INTRODUCTION Red Warning Lights Yellow Warning Lights Seat Belt Reminder Warning Light Loose Fuel Filler Cap Warning Light page 114 page 115 Transmission Temperature Warning Light Low Fuel Warning Light page 114 page 115 Vehicle Security Warning Light Low Washer Fluid Warning Light page 114 page 115 Yellow Warning Lights...
Page 14 INTRODUCTION Yellow Warning Lights Yellow Indicator Lights 4WD Low Indicator Light Service Stop/Start System Warning Light page 117 page 116 4WD Part Time Indicator Light Cruise Control Fault Warning Light page 117 page 116 Axle Locker Fault Indicator Light Sway Bar Fault Warning Light page 117 page 116 Rear Axle Lock Indicator Light...
Page 15 INTRODUCTION Yellow Indicator Lights Green Indicator Lights Service Adaptive Cruise Control Warning Light Adaptive Cruise Control (ACC) Set With No Target Detected Indicator page 117 Light page 118 Sway Bar Indicator Light page 118 Adaptive Cruise Control (ACC) Set With Target Light page 118 Off Road+ Indicator Light page 118...
Page 16 INTRODUCTION Green Indicator Lights White Indicator Lights Stop/Start Active Indicator Light Cruise Control Ready Indicator Light page 119 page 119 Cruise Control SET Indicator Light Turn Signal Indicator Lights page 119 page 119 White Indicator Lights Cruise Control Ready Indicator Light page 119 Adaptive Cruise Control (ACC) Ready Light page 119...
Page 17: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE NOTE: KEYS CAUTION! • In case the ignition switch does not change with the The electrical components inside of the key fob may push of a button, the key fob may have a low or fully KEY FOB be damaged if the key fob is subjected to strong elec- depleted battery.
Page 18 GETTING TO KNOW YOUR VEHICLE Key Left Vehicle Feature • When a key fob battery is low, a warning will be indi- cated on the vehicle’s instrument cluster, and the If a valid key fob is no longer detected inside the vehicle fob LED will no longer illuminate with a button push.
Page 19: Sentry Key
GETTING TO KNOW YOUR VEHICLE Programming And Requesting SENTRY KEY All of the key fobs provided with your new vehicle have Additional Key Fobs been programmed to the vehicle electronics page 366. The Sentry Key Immobilizer system prevents unauthor- Programming the key fob may be performed by an ized vehicle operation by disabling the engine.
Page 20 GETTING TO KNOW YOUR VEHICLE The push button ignition can be placed in the following WARNING! modes: • Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or oth- • The engine is stopped. ers could be seriously or fatally injured.
Page 21: Remote Start - If Equipped (Gasoline)
GETTING TO KNOW YOUR VEHICLE • REMOTE START — IF EQUIPPED HOW TO USE REMOTE START Vehicle Security system indicator flashing • Ignition in OFF position Push and release the Remote Start button on the key (GASOLINE) • Fuel level meets minimum requirement fob twice within five seconds.
Page 22: Remote Start Front Defrost Activation - If Equipped
GETTING TO KNOW YOUR VEHICLE Automatic Temperature Control (ATC) — If Equipped REMOTE START WINDSHIELD WARNING! The climate controls automatically adjust to an optimal WIPER DE-ICER ACTIVATION — • temperature and mode, dependent upon the outside Do not start or run an engine in a closed garage or IF EQUIPPED ambient temperature.
Page 23: How To Use Remote Start
GETTING TO KNOW YOUR VEHICLE NOTE: • VEHICLE SECURITY SYSTEM — If an engine fault is present or fuel level is low, the vehicle will start and then shut down in 10 seconds. • The vehicle must be equipped with an automatic IF EQUIPPED •...
Page 24: To Disarm The System
GETTING TO KNOW YOUR VEHICLE NOTE: TO DISARM THE SYSTEM REARMING OF THE SYSTEM The mechanical flip key can be used to lock or unlock The Vehicle Security system can be disarmed using any If something triggers the alarm and no action is taken the door cylinders, tailgate, glove compartment, and of the following methods: to disarm it, the Vehicle Security system will turn the...
Page 25: Power Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE • POWER DOOR LOCKS — If the vehicle is unlocked by Passive Entry and no WARNING! door is opened within 60 seconds, the vehicle will IF EQUIPPED • relock and, if equipped, will arm the Vehicle Security Do not leave the key fob in or near the vehicle or in The power door lock switch is located on each front system.
Page 26: Automatic Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: Frequency Operated Button Integrated Key To Lock The Vehicle’s Doors (FOBIK-Safe) With one of the vehicle’s Passive Entry key fobs within • After pushing the door handle button, the driver To minimize the possibility of unintentionally locking a 5 ft (1.5 m) of the driver or passenger front door must wait three seconds before locking or unlocking Passive Entry key fob inside your vehicle, the Passive...
Page 27: Front Door Removal
GETTING TO KNOW YOUR VEHICLE WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the Child-Protection Door Lock system is engaged (locked). NOTE: Always use this device when carrying children. After engaging the child lock on both rear doors, check for effective engagement by trying to open a door with the internal handle.
Page 28 GETTING TO KNOW YOUR VEHICLE 4. Pull up on the red locking tab to unlock the wiring CAUTION! harness. • Hinge pins can break if overtightened during door reinstall (Max Torque: 5.88 ft·lb / 8 N·m). For infor- mation on off-road driving tips, see page 175.
Page 29 GETTING TO KNOW YOUR VEHICLE Open Wiring Harness Door Check Hinge Pin Locations 8. With the door open, lift the door with the help of 2. With the door in the open position, align the door 1 — Wiring Harness Lever (Open Position) another person, to clear the hinge pins from their check bracket with the hole on the body.
Page 30 GETTING TO KNOW YOUR VEHICLE NOTE: e. Using the door handle, slowly push the door open. The check arm will be pulled out of the Make sure there is plenty of slack on the wiring connec- door. You may hear the check arm pop against tor during installation.
Page 31: Rear Door Removal
GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! When reinstalling the door check arm attachment bolt, bolt torque should be between 11.76 ft·lb / 16 N·m and • All occupants must wear seat belts during off-road 27.9 ft·lb / 38 N·m. operation with doors removed.
Page 32: Door Off Mirror Kit - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: DOOR OFF MIRROR KIT — Squeeze the tab on the base of the wiring harness. IF EQUIPPED This will unlock the connector tab, allowing the wir- ing connector to be unplugged. If equipped with the Door Off Mirror Kit, exterior rear- view mirrors can be installed on to the upper body door hinges after the front doors have been removed.
Page 33 GETTING TO KNOW YOUR VEHICLE To install the Door Off Mirrors, proceed as follows: 5. Insert the hinge shoulder bolt through the bottom of the upper door hinge up into the mirror bracket, 1. Remove both front doors page 25. then rotate the bracket knob toward the rear of the 2.
Page 34: Half-Doors - If Equipped
GETTING TO KNOW YOUR VEHICLE Half-Door Installation NOTE: If this kit is being installed with the optional lamp To install the front or rear half-doors, proceed as bracket, the bracket bushing from step 4 is not needed. follows: Use the spacer from the lamp bracket. 1.
Page 35 GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! For front doors, make sure the wiring harness is closed completely. • Do not close the door before reattaching the door check to the body. Damage may occur to the door check. • Do not overtighten Torx fasteners, damage to the vehicle’s parts will occur.
Page 36 GETTING TO KNOW YOUR VEHICLE 9. Push down firmly on the inside of the upper half- 2. With the bolts loose, hold the door in the almost door until it is fully seated in the lower half. closed position, and check that the latch and striker align.
Page 37 GETTING TO KNOW YOUR VEHICLE NOTE: Do not adjust the body mounted hinges, or any part of the door latch, as modifications to these parts will affect installation of the full door. 2. With the bolts loose, the door can be moved forward by pushing the door handle toward the front of the vehicle, and/or upward by grabbing the door handle and lifting towards the roof.
Page 38 GETTING TO KNOW YOUR VEHICLE Half-Door Mirror Installation 4. Tighten the nut inside the bottom of the post using c. Slide the shim onto a pencil or similar tool. the wrench and make sure the screw head is flush To install the front door exterior mirrors on the half- d.
Page 39: Steering Wheel
GETTING TO KNOW YOUR VEHICLE 3. Place the base of the exterior mirror into the hole on the door, and support it while attaching the three mirror bolts through the inside of the door using a #T40 Torx head driver. Push Upward To Remove Upper Half-Door Tilt/Telescoping Steering Column Control To unlock the steering column, push the control down-...
Page 40: Heated Steering Wheel - If Equipped
GETTING TO KNOW YOUR VEHICLE HEATED STEERING WHEEL — MANUAL ADJUSTMENT FRONT WARNING! IF EQUIPPED SEATS • Do not place anything on the steering wheel that insulates against heat, such as a blanket or steer- The steering wheel contains a heating ele- Manual Front Seat Forward/Rearward ing wheel covers of any type and material.
Page 41: 60/40 Split Folding Rear Seat
GETTING TO KNOW YOUR VEHICLE Manual Front Seatback Recline WARNING! Adjustment • Seats should be adjusted before fastening the seat To recline the seat, pull on the recline strap and lean belts and while the vehicle is parked. Serious forward or rearward, depending on the direction you injury or death could result from a poorly adjusted would like the seatback to move.
Page 42 GETTING TO KNOW YOUR VEHICLE • The center head restraints must be in the lowest To raise the seatback to the proper position, manually position to avoid contact with the center console lift the seatback until it locks into place. To return the when folding the seat.
Page 43: Rear Seat Stadium Position
GETTING TO KNOW YOUR VEHICLE NOTE: 2. Raise the seat bottom upward into the Stadium WARNING! Position. • The engine must be running for the heated seats to Be certain that the seatback is securely locked into operate. position. Perform a “push - pull - push” check to con- •...
Page 44: Rear Seat Armrest - If Equipped
GETTING TO KNOW YOUR VEHICLE REAR SEAT ARMREST — HEAD RESTRAINTS IF EQUIPPED Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear The center part of the rear seat can also be used as a impact.
Page 45: Uconnect Voice Recognition
GETTING TO KNOW YOUR VEHICLE Rear Head Restraints UCONNECT VOICE RECOGNITION To reinstall the head restraint, put the head restraint posts into the holes and push downward. Then, adjust it The rear seat is equipped with nonadjustable, but fold- to the appropriate height using the adjustment button. able, outboard head restraints, as well as an adjust- INTRODUCING VOICE For information on child seat tether routing, see...
Page 46: Basic Voice Commands
GETTING TO KNOW YOUR VEHICLE GET STARTED ADDITIONAL INFORMATION VR button is used to activate/deactivate your © 2022 FCA US LLC. All rights reserved. Mopar and Voice Recognition system. Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC. SiriusXM® and Helpful hints for using Voice Recognition: all related marks and logos are trademarks of •...
Page 47: Illuminated Vanity Mirrors
GETTING TO KNOW YOUR VEHICLE The Automatic Dimming feature can be turned on or off OUTSIDE MIRRORS through the Uconnect Controls button on the The Outside Mirrors are located on the front driver and touchscreen. passenger side doors, and are adjusted manually or by power adjustment (if equipped).
Page 48: Heated Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE • HEATED MIRRORS — IF EQUIPPED UNIVERSAL GARAGE DOOR OPENER The HomeLink® indicator light is located above the center button. These mirrors are heated to melt frost or ice. (HOMELINK®) NOTE: This feature will be activated whenever you turn on the rear window defroster HomeLink®...
Page 49: Identifying Whether You Have A Rolling Code Or Non-Rolling Code Device
GETTING TO KNOW YOUR VEHICLE IDENTIFYING WHETHER YOU HAVE 1. Place the ignition switch into the ON/RUN position. 3. Push the programmed HomeLink® button to con- firm that the garage door opener motor operates. If A ROLLING CODE OR NON-ROLLING 2.
Page 50: Programming Homelink® To A Miscellaneous Device
GETTING TO KNOW YOUR VEHICLE NOTE: PROGRAMMING HOMELINK® TO A CANADIAN/GATE OPERATOR ○ If the indicator light stays on constantly, program- MISCELLANEOUS DEVICE PROGRAMMING ming is complete and the garage door/device should activate when the HomeLink® button is The procedure on how to program HomeLink® to a mis- For programming transmitters in Canada/United States pressed.
Page 51: Troubleshooting Tips
GETTING TO KNOW YOUR VEHICLE NOTE: EXTERIOR LIGHTS The universal garage door opener only operates when the engine is running for security reasons associated HEADLIGHT SWITCH with removable tops and doors. The headlight switch is located on the left side of the TROUBLESHOOTING TIPS instrument panel.
Page 52: Daytime Running Lights (Drls) - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: With the headlight switch activated, push the multifunc- tion lever toward the instrument panel to switch the For vehicles sold in Canada, rotate the headlight switch • The Automatic High Beam Headlamp Control can be headlights to high beams.
Page 53: Lights-On Reminder
GETTING TO KNOW YOUR VEHICLE NOTE: The engine must be running before the headlights will come on in the automatic mode. LIGHTS-ON REMINDER If the headlights or parking lights are left on after the ignition is placed in the OFF position, the vehicle will chime when the driver’s door is opened.
Page 54: Interior Lights
GETTING TO KNOW YOUR VEHICLE INTERIOR LIGHTS DIMMER CONTROLS With the parking lights or headlights on, rotating the right dimmer control upward will increase the bright- The dimmer controls are part of the headlight switch ness of the instrument panel lights. Rotating the left and are located on the left side of the instrument INTERIOR COURTESY LIGHTS dimmer control will adjust the ambient light levels...
Page 55: Climate Controls
GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Rotate the end of the lever upward to the first detent If the lever is pulled while in the off position, the wipers past the intermittent settings for low-speed wiper will operate for two or three wipe cycles. Then, the wip- operation.
Page 56 GETTING TO KNOW YOUR VEHICLE AUTO Button The Air Conditioning (A/C) button allows the operator to manually activate or deactivate the air conditioning sys- Press and release this button on the touch- tem. When the air conditioning system is turned on, screen, or push the button on the faceplate, cool dehumidified air will flow through the outlets into to change the current setting.
Page 57 GETTING TO KNOW YOUR VEHICLE SYNC Button Mode Control CAUTION! Press the SYNC button on the touchscreen Turn the mode control knob or press one of Failure to follow these cautions can cause damage to to toggle the Sync feature on/off. The SYNC the Mode buttons on the touchscreen to the heating elements: indicator illuminates when SYNC is on.
Page 58: Manual Climate Control Descriptions And
GETTING TO KNOW YOUR VEHICLE Mix Mode MAX A/C Setting conditions such as smoke, odors, dust, or high humidity are present. Recirculation can be used in all modes Air is directed through the floor, defrost, and Set the temperature control knob to the MAX except for Defrost.
Page 59: Automatic Temperature Control (Atc) - If Equipped
GETTING TO KNOW YOUR VEHICLE Blower Control Floor Mode CAUTION! Blower Control regulates the amount of air Air comes from the floor outlets. A slight Failure to follow these cautions can cause damage to forced through the climate system. There are amount of air is directed through the defrost the heating elements: seven blower speeds available.
Page 60: Climate Voice Commands
GETTING TO KNOW YOUR VEHICLE Window Fogging Did You Know: Voice Command for Climate may only be 3. When the system is set up for your comfort level, it is not necessary to change the settings. You will used to adjust the interior temperature of your vehicle. Vehicle windows tend to fog on the inside in mild, rainy, experience the greatest efficiency by simply allowing Voice Command will not work to adjust the heated...
Page 61: Interior Storage And Equipment
GETTING TO KNOW YOUR VEHICLE Operating Tips Chart Console Storage Compartment INTERIOR STORAGE AND EQUIPMENT The center console has both an upper and lower stor- age compartment. To open the upper storage compart- WEATHER CONTROL SETTINGS STORAGE ment, lift the top latch. To access the lower storage Hot Weather And Vehicle Set the mode control to compartment, lift the bottom latch.
Page 62 GETTING TO KNOW YOUR VEHICLE Non-Locking Storage Wall If equipped, the Locking Storage Bin is located below Your Locking Storage Bin also has a front handle that the rear seats. It can be accessed by folding the rear makes it easier to carry and pull out from the floor of seat bottom upward into the Stadium Position.
Page 63: Aux/Usb Control
GETTING TO KNOW YOUR VEHICLE Rear Wall Netting NOTE: The rear wall netting can be accessed the same way as • Once a device is connected to the USB port, it will the rear wall storage bin. begin charging and is ready for use with the system. Type C and Type A charge-only USB ports can be used at the same time but cannot be used simulta- neously while playing media.
Page 64: Jeep® Wireless Speaker - If Equipped
A third and fourth USB port are located behind the cen- collision. ter console, above the power inverter. Both ports are charge only. JEEP® WIRELESS SPEAKER — IF EQUIPPED Your vehicle may be equipped with a wireless Bluetooth® speaker. Rear Speaker Outlets Getting To Know Your Speaker 1 —...
Page 65 The Jeep® wireless speaker is located behind the right NOTE: rear passenger seat. In order to access the Jeep® wire- less speaker, the seat will need to be folded down or Jeep® wireless speaker will not charge within vehicle tilted forward.
Page 66 The Jeep® wireless speaker contains a lithium-ion rechargeable battery. Typical charging temperatures for these types of batteries are from 0 to 45°C (32 to 113°F). NOTE: The functions described are for when the Jeep® wireless speaker is undocked from the vehicle. When plugged into the docking station, the Jeep® wireless speaker functions as part of the vehicle’s sound system.
Page 67 GETTING TO KNOW YOUR VEHICLE Below are the steps needed for Qualcomm TrueWire- ately. Do not expose the Jeep® wireless speaker or bat- CAUTION! less™ Stereo: tery to excessive heat, including direct sunlight or fire. Do not store or use inside cars in hot weather, where it Ensure the Jeep®...
Page 68: Power Outlets
• Do not exceed the maximum power of 160 W Jeep® wireless speaker as it could cause damage to The front power outlet is located in the center of the (13 A) at 12 Volts. If the 160 W (13 A) power rating...
Page 69: Power Inverters - If Equipped
GETTING TO KNOW YOUR VEHICLE CAUTION! • Many accessories that can be plugged in draw power from the vehicle's battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle's battery will discharge sufficiently to degrade battery life and/or prevent the engine from starting.
Page 70: Auxiliary Switches - If Equipped
GETTING TO KNOW YOUR VEHICLE The power inverter is designed with built-in overload protection. If the power rating of 400 W is exceeded, the power inverter automatically shuts down. Once the electrical device has been removed from the outlet, the inverter should automatically reset.
Page 71: Power Windows - If Equipped
GETTING TO KNOW YOUR VEHICLE Wire Color Chart Circuit Function Fuse Wire Color Locations Interior (passenger side under instrument panel) & Underhood (right side Aux Switch 1 F93 – 40 Amp Beige/Pink near battery) Interior (passenger side under instrument panel) & Underhood (right side Aux Switch 2 F92 –...
Page 72: Auto-Down Feature
GETTING TO KNOW YOUR VEHICLE NOTE: WIND BUFFETING • The power window switches will remain active for up Wind buffeting can be described as the perception of to 10 minutes after the ignition is placed in the OFF pressure on the ears or a helicopter-type sound in the position.
Page 73: Lowering The Soft Top
GETTING TO KNOW YOUR VEHICLE Place the vehicle in a warm area. Pull steadily on the WARNING! top fabric. The vinyl will stretch back to its original size and the top can then be installed. If the temperature is • Do not drive the vehicle with the rear window 41°F (5°C) or below, do not attempt to put the top up/removed unless the quarter windows are also...
Page 74 GETTING TO KNOW YOUR VEHICLE Side View Top And Components 1 — #1 Bow 6 — Quarter Panel Upper Hook And Loop 2 — #2 Bow 7 — Quarter Panel Vertical Retainer 3 — #3 Bow 8 — Rear Window Vertical Retainer 4 —...
Page 75 GETTING TO KNOW YOUR VEHICLE Rear Window View And Components 1 — Top Retainer 4 — Pull Tabs 2 — Left Vertical Retainer 5 — Lower Center Retainer 3 — Lower Retainers 6 — Right Vertical Retainer...
Page 76 GETTING TO KNOW YOUR VEHICLE Lowering The Soft Top Into The Sunrider® Position: 5. Secure the top in this position by using the two Use this QR code to access your digital hook-and-loop fasteners provided in the center console. experience. 1.
Page 77 GETTING TO KNOW YOUR VEHICLE Removing The Rear Window And 2. While keeping the rear window level, slide it outward Quarter Panel Cover Assemblies in either direction until it is completely separate from its retainer. Do not pull downward while NOTE: removing the rear window.
Page 78 GETTING TO KNOW YOUR VEHICLE Soft Top Rear Window Storage Bag — 2. Fold the divider upward, covering the rear window. If Equipped To safely store the soft top rear window, proceed as follows: 1. With the bag opened completely, fold the fabric divider downward and lay the rear window in the bottom of the bag.
Page 79: Raising The Soft Top
GETTING TO KNOW YOUR VEHICLE RAISING THE SOFT TOP 2. Using the side link, lift and push the soft top toward 3. From inside the vehicle, pull the handle on the the front of the vehicle, manually guiding the top header latch downward to engage the hook into its Use this QR code to access your digital into the closed position.
Page 80 GETTING TO KNOW YOUR VEHICLE Installing The Rear Window And Quarter 4. From either side, guide the rear window into the Panel Cover Assemblies retainer while keeping the window level. NOTE: Both quarter panel cover assemblies and the rear win- dow must ALL be removed together, or installed together.
Page 81: Removing The Soft Top
GETTING TO KNOW YOUR VEHICLE 6. Engage the vertical retainers up the right and left CAUTION! side of the rear window. Quarter panel cover assemblies and rear window must be either all in or all out. REMOVING THE SOFT TOP Use this QR code to access your digital experience.
Page 82: Installing The Soft Top
GETTING TO KNOW YOUR VEHICLE 3. Unsnap and remove the storage bag. This bag CAUTION! should be discarded. It was intended as a protective cover for shipping only. Do not overtighten Torx fasteners. Damage to the retainers will occur. 4. Ensure the top is secured with the provided hook- and-loop fasteners, then lift the soft top onto the rear of the cab.
Page 83: Hard Top Front Panel(S) Removal
GETTING TO KNOW YOUR VEHICLE HARD TOP FRONT PANEL(S) REMOVAL Use this QR code to access your digital experience. Scan me CAUTION! Step Five Step Five • The hard top is not designed to carry any addi- 6. Before driving the vehicle with the top in the tional loads, such as after-market roof racks, spare Sunrider®...
Page 84 GETTING TO KNOW YOUR VEHICLE Hard Top Components 1 — Right Side Panel 2 — Left Side Panel 3 — Hard Top NOTE: The left side panel must be removed before removing the right side panel.
Page 85 GETTING TO KNOW YOUR VEHICLE • 1. Fold down the sun visor against the windshield. There is a pouch located on the front of the bag to store the provided hard top edge protectors that are 2. Turn the three L-shaped locks on the left side panel used when the hard top is not installed on the (one at the front, the rear, and outside), unlocking vehicle.
Page 86: Hard Top Front Panel(S) Installation
GETTING TO KNOW YOUR VEHICLE HARD TOP FRONT PANEL(S) 5. Remove the Torx head fasteners that secure the hard top to the vehicle: two along the interior body INSTALLATION side, rearward of the back doors, followed by the four fasteners along the back of the vehicle cab 1.
Page 87 GETTING TO KNOW YOUR VEHICLE 8. Remove the hard top from the vehicle. Install the provided edge protectors along the bottom edges of the hard top, and place the hard top on a soft sur- face to prevent damage. CAUTION! The removal of the Hard Top requires four adults located on each corner.
Page 88: Installing The Hard Top
GETTING TO KNOW YOUR VEHICLE INSTALLING THE HARD TOP SUNRIDER® FOR HARD TOP — IF EQUIPPED If the door frames are installed from soft top usage, they must be removed prior to installation of the hard page 88. WARNING! To install the hard top, place the hard top on the vehicle while making sure that the top is sitting flush with the Do not open or close the Sunrider®...
Page 89 GETTING TO KNOW YOUR VEHICLE NOTE: The recommended torque specification for the rear clamp attachment bolts is 3.7 ft-lb (5 N·m). 7. From inside the vehicle, lift and pull the Sunrider® top forward using the integrated handle on the front header of the top.
Page 90: Door Frame - If Equipped With A Soft Top
GETTING TO KNOW YOUR VEHICLE 3. From the front of the Sunrider® top, lift and push DOOR FRAME — IF EQUIPPED WITH A DOOR FRAME REMOVAL the top rearward to the Sunrider® position. NOTE: SOFT TOP The rear door frames must be removed first, followed by the front door frames.
Page 91: Door Frame Installation
GETTING TO KNOW YOUR VEHICLE WARNING! Target Torque Specification Do not drive your vehicle on public roads with the Maximum Minimum For Torx door and/or door frame(s) removed as you will lose Fasteners the protection that they can provide. This procedure is furnished for use during off-road operation only.
Page 92: Folding Windshield
GETTING TO KNOW YOUR VEHICLE speed of the vehicle be limited to 10 mph (16 km/h), LOWERING THE WINDSHIELD with low range operation preferred if you are driving off-road with the windshield folded down. 1. Before completing the following steps: ○...
Page 93 GETTING TO KNOW YOUR VEHICLE 3. Using the provided 15 mm socket, remove the two 1. Secure the top part of the cover so that it hinges to hex bolts and remove the wiper arms. the header. 4. Move to the inside of the vehicle and lower both sun 2.
Page 94: Raising The Windshield
GETTING TO KNOW YOUR VEHICLE RAISING THE WINDSHIELD 5. Reinstall the protective caps over the wiper arm hex bolts and push gently until they snap into place. 1. Release the strap that secured the windshield in the lowered position. 2. Raise the windshield. 3.
Page 95: Closing The Hood
GETTING TO KNOW YOUR VEHICLE NOTE: TAILGATE • Vehicle must be at a stop and the gear selector must be in PARK. OPENING • You may have to push down slightly on the hood before pushing the safety latch. • While lifting the hood, use both hands.
Page 96: Closing
GETTING TO KNOW YOUR VEHICLE CLOSING To close the tailgate, lift upward until both sides latch into place. CAUTION! After closing, pull back on the tailgate firmly to ensure it is securely latched. Failure to securely latch the tailgate could result in damage to the vehicle or cargo.
Page 97: Tonneau Cover - If Equipped
GETTING TO KNOW YOUR VEHICLE The Bed Rail Tie Down system allows you to properly Each utility rail cleat must be tightened down in one of TONNEAU COVER INSTALLATION secure cargo in the truck bed. the detents along either utility rail in order to keep To install the Tonneau Cover, proceed as follows: cargo properly secured.
Page 98 GETTING TO KNOW YOUR VEHICLE Release Stowage Strap Correctly Seated Retainer Push Downward To Lock NOTE: 5. Roll the Tonneau Cover rearward toward the back of the truck bed. If desired, the Tonneau Cover can be left in this position (rear panel folded forward) while the tail- gate is closed, or the tailgate can be raised to the mid-position page 93.
Page 99: Tonneau Cover Removal
GETTING TO KNOW YOUR VEHICLE NOTE: 4. Roll the Tonneau Cover forward, starting with the rear bar and continue to roll toward the front of the If not leaving the tailgate in the mid-position, the truck bed. Tonneau Cover must be closed completely prior to fully closing the tailgate.
Page 100 GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! Crossbars can be purchased at an authorized dealer • through Mopar® parts. Travel at reduced speeds and turn corners care- fully when carrying large or heavy loads on the roof External racks do not increase the total load carrying rack.
Page 101: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL GASOLINE INSTRUMENT CLUSTERS...
Page 102 GETTING TO KNOW YOUR INSTRUMENT PANEL...
Page 103: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER CAUTION! DESCRIPTIONS Driving with a hot engine cooling system could dam- 1. Tachometer age your vehicle. If the temperature gauge reads “H” pull over and stop the vehicle. Idle the vehicle with ○...
Page 104: Diesel Instrument Clusters
GETTING TO KNOW YOUR INSTRUMENT PANEL DIESEL INSTRUMENT CLUSTERS...
Page 105 GETTING TO KNOW YOUR INSTRUMENT PANEL...
Page 106: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER panel, indicates how systems are operating and gives CAUTION! you warnings when a system, or systems, needs your DESCRIPTIONS attention. The steering wheel mounted controls allow Driving with a hot engine cooling system could dam- you to scroll through and enter the main menus and 1.
Page 107: Oil Life Reset - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Left And Right Secondary Method For Oil Change Reset Procedure • The main display area where the menus and pop-up Arrow Buttons: messages are displayed. Using the left or right arrow button allow you to 1.
Page 108: Instrument Cluster Display Selectable Items
GETTING TO KNOW YOUR INSTRUMENT PANEL Off Road — If Equipped • 4L: Cruise Control — Cruise Control Unavailable in INSTRUMENT CLUSTER DISPLAY 4WD Low Push and release the up or down MENU ITEMS arrow button • 4L: Adaptive Cruise Control — Adaptive Cruise Con- until the Off Road menu icon is displayed in the instru- trol (ACC) Unavailable in 4WD Low ment cluster display.
Page 109 GETTING TO KNOW YOUR INSTRUMENT PANEL Driver Assist — If Equipped NOTE: The Trip A and Trip B information will display the following: The instrument cluster display will return to the last The Driver Assist menu displays the status of the ACC •...
Page 110: Battery Saver On, Battery Saver Mode Message, And Electrical Load Reduction Actions (If Equipped)
GETTING TO KNOW YOUR INSTRUMENT PANEL When no messages are present, main menu icon will BATTERY SAVER ON, BATTERY Upper Center be a closed envelope, and “No Stored Messages” will SAVER MODE MESSAGE, AND None Time Current Econ display. ELECTRICAL LOAD REDUCTION Compass Range to Empty Trip A Distance...
Page 111: Diesel Displays
GETTING TO KNOW YOUR INSTRUMENT PANEL • • The electrical loads that may be switched off The battery was used for an extended period with Exhaust System – Filter XX% Full Service Required (if equipped), and vehicle functions which can be the engine not running to supply radio, lights, char- See Dealer affected by load reduction:...
Page 112: Fuel System Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: • Exhaust System Regeneration in Process Continue CAUTION! Driving — This message indicates that the DPF is Failing to follow the oil change indicator, changing self-cleaning. Maintain your current driving condition your oil and resetting the oil change indicator by The engine may be switched off even if the warning until regeneration is completed.
Page 113 GETTING TO KNOW YOUR INSTRUMENT PANEL MESSAGE DESCRIPTION Diesel Emissions Additive AdBlue® (UREA) Warning Messages: The first low level warning will be given at around a 1,490 miles (2,400 km) range, and is determined according to the current con- sumption rate. The “UREA Low Level” warning light and message will display on the instrument panel. The UREA low level warning light will remain lit until the AdBlue®...
Page 114: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL MESSAGE DESCRIPTION Gasoline Particulate Filter (GPF) System Messages — If Equipped: The engine control unit has detected an issue with the gasoline particulate filter system. See an authorized dealer. Exhaust System Service Required The regeneration procedure is controlled automatically by the engine control unit according to the filter conditions and car use con- Exhaust System Regeneration in Process ditions.
Page 115 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Vehicles equipped with the Anti-Lock Brake System If the light continues to flash when the vehicle is run- (ABS) are also equipped with Electronic Brake Force ning, immediate service is required and you may experi- If the vehicle is moving, there will also be a single Distribution (EBD).
Page 116: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Oil Pressure Warning Light Transmission Temperature Warning CAUTION! Light — If Equipped This warning light will illuminate, and a Continuous driving with the Transmission Tempera- chime will sound, to indicate low engine oil This warning light will illuminate to warn of a ture Warning Light illuminated will eventually cause pressure.
Page 117 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) Active Loose Fuel Filler Cap Warning Light — Certain conditions, such as a loose or missing gas cap, Warning Light — If Equipped If Equipped poor quality fuel, etc., may illuminate the light after engine start.
Page 118 GETTING TO KNOW YOUR INSTRUMENT PANEL Service 4WD Warning Light — Sway Bar Fault Warning Light — As an added safety feature, your vehicle has been If Equipped If Equipped equipped with a TPMS that illuminates a low tire pres- sure telltale when one or more of your tires is signifi- This warning light will illuminate to signal a This light will illuminate when there is a fault...
Page 119: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Rear Axle Lock Indicator Light — YELLOW INDICATOR LIGHTS CAUTION! If Equipped 4WD Indicator Light — If Equipped The TPMS has been optimized for the original equip- This light indicates when the rear axle lock ment tires and wheels.
Page 120: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Sway Bar Indicator Light — If Equipped Low Diesel Exhaust Emissions Additive GREEN INDICATOR LIGHTS AdBlue® (UREA) Indicator Light — This indicator light will illuminate when the Adaptive Cruise Control (ACC) Set With If Equipped front sway bar is disconnected.
Page 121: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Front Fog Indicator Light — If Equipped Cruise Control Ready Indicator Light — WHITE INDICATOR LIGHTS If Equipped With A Premium Instrument This indicator light will illuminate when the Adaptive Cruise Control (ACC) Ready Cluster front fog lights are on page 49.
Page 122: Blue Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL BLUE INDICATOR LIGHTS WARNING! CAUTION! High Beam Indicator Light • If unauthorized equipment is connected to the • Prolonged driving with the MIL on could cause fur- OBD II connection port, such as a driver-behavior ther damage to the emission control system.
Page 123 GETTING TO KNOW YOUR INSTRUMENT PANEL If your OBD II system is not ready, you should see an Your vehicle has a simple ignition actuated test, which you can use prior to going to the test station. To check if authorized dealer or repair facility.
Page 124: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE — GASOLINE MANUAL TRANSMISSION — 3. The system starts the vehicle. If the vehicle fails to start, the starter will disengage automatically after IF EQUIPPED 10 seconds. ENGINE (IF EQUIPPED) Apply the parking brake, place the gear selector in NEU- 4.
Page 125: Autopark
STARTING AND OPERATING NOTE: If the vehicle is not in PARK and the driver exits the WARNING! vehicle with the engine running, the vehicle may The system will automatically time out and the ignition AutoPark. will cycle to the OFF position after 30 minutes of inac- •...
Page 126: Extreme Cold Weather (Below -22°F Or −30°C)
STARTING AND OPERATING EXTREME COLD WEATHER (BELOW IF ENGINE FAILS TO START WARNING! –22°F OR −30°C) If the engine fails to start after you have followed the If vehicle speed is above 1.2 mph (1.9 km/h), the “Normal Starting” procedure and the vehicle has not To ensure reliable starting at these temperatures, use transmission will default to NEUTRAL until the vehicle experienced an extended park condition as defined...
Page 127: After Starting
STARTING AND OPERATING AUTOMATIC TRANSMISSION WARNING! CAUTION! Start the engine with the transmission gear selector in reasons. A child or others could be seriously or To prevent damage to the starter, do not continuously the PARK (P) position. Apply the brake before shifting to fatally injured.
Page 128: Normal Starting
STARTING AND OPERATING NORMAL STARTING 5. Check that the Oil Pressure Warning Light has NORMAL OPERATION — DIESEL ENGINE turned off. Observe the instrument cluster lights when starting the Observe the following when the diesel engine is 6. Release the parking brake. engine.
Page 129: Engine Idling
STARTING AND OPERATING • Climatized ULSD fuel is a blend of Number 2 ULSD If temperatures are below 32°F (0°C), operate the fuel and Number 1 ULSD fuel which reduces the engine at moderate speeds for five minutes before full temperature at which wax crystals form in fuel.
Page 130: Cooling System Tips - Automatic Transmission
STARTING AND OPERATING NOTE: NOTE: ENGINE BREAK-IN RECOMMENDATIONS Under certain conditions, the Stop/Start functionality Do not operate the vehicle until the cause is corrected. — GASOLINE ENGINE (IF EQUIPPED) may be temporarily disabled and the engine fan will run This light does not show how much oil is in the engine. after the engine is turned off to protect the engine.
Page 131: Engine Break-In Recommendations - Diesel Engine (If Equipped)
STARTING AND OPERATING • ENGINE BREAK-IN RECOMMENDATIONS PARKING BRAKE This light only shows that the parking brake is applied. It does not show the degree of brake — DIESEL ENGINE (IF EQUIPPED) application. Before exiting the vehicle, make sure that the parking When parking on a hill, it is important to turn the front brake is fully applied.
Page 132: Manual Transmission - If Equipped
STARTING AND OPERATING To engage REVERSE gear from the NEUTRAL position, WARNING! CAUTION! lift the REVERSE ring, located below the knob and move • the gear selector all the way left and then forward. Always fully apply the parking brake when leaving cause the clutch to overheat and cause permanent your vehicle or it may roll and cause damage or damage to the clutch.
Page 133: Downshifting
STARTING AND OPERATING Recommended Vehicle Shift Speeds To utilize your manual transmission efficiently for both fuel economy and performance, it should be upshifted as listed in the recommended shift speed chart. Shift at the vehicle speeds listed for acceleration. When heavily loaded or pulling a trailer, these recommended up shift speeds may not apply. Manual Transmission Shift Speeds in MPH (KM/H) Engine Speeds...
Page 134: Automatic Transmission - If Equipped
STARTING AND OPERATING Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4 4 to 3 3 to 2 2 to 1 Maximum Speed 80 (129) 70 (113) 50 (81) 30 (48) 15 (24) NOTE: Vehicle speeds shown in the preceding chart are for 2H and 4H only, vehicle speeds in 4L would be significantly less.
Page 135: Ignition Park Interlock
STARTING AND OPERATING IGNITION PARK INTERLOCK must also press the brake pedal to shift from NEUTRAL into DRIVE or REVERSE when the vehicle is stopped or This vehicle is equipped with an Ignition Park Interlock moving at low speeds. Select the DRIVE range for nor- system which requires the transmission to be in PARK mal driving.
Page 136 STARTING AND OPERATING PARK (P) • DRIVE (D) When shifting into PARK, push the lock button on the gear selector and firmly move the gear selector This range supplements the parking brake by locking This range should be used for most city and highway all the way forward until it stops and is fully seated.
Page 137 STARTING AND OPERATING Transmission Limp Home Mode • 3. Push and hold the ENGINE START/STOP button until The transmission will automatically downshift to the engine turns off. FIRST gear when coming to a stop. After a stop, the Transmission function is monitored electronically for driver should manually upshift (+) the transmission 4.
Page 138: Four-Wheel Drive Operation
STARTING AND OPERATING FOUR–WHEEL DRIVE OPERATION For additional information on the appropriate use of each transfer case position, see the following: Four-Wheel Drive Low Range — This range provides low speed four-wheel drive. It maximizes torque to the front driveshaft, forcing the front and rear wheels to rotate at WARNING! Two-Wheel Drive High Range —...
Page 139: Five-Position Transfer Case - If Equipped
STARTING AND OPERATING Shifting Procedures 4H TO 4L OR 4L TO 4H FIVE-POSITION TRANSFER CASE — IF EQUIPPED 2H TO 4H OR 4H TO 2H With the vehicle rolling at 1 to 3 mph (2 to 5 km/h), shift an automatic transmission into NEUTRAL (N), or Shifting between 2H and 4H can be made with the press the clutch pedal on a manual transmission.
Page 140 STARTING AND OPERATING 4H AUTO When operating your vehicle in 4L, the engine speed will be approximately three times (four times for Rubi- Four-Wheel Drive Auto High Range — This range sends Four-Wheel Drive Low Range — This range provides low con models) that of the 2H or 4H positions at a given power to the front wheels.
Page 141: Trac-Lok Rear Axle - If Equipped
STARTING AND OPERATING NOTE: NOTE: WARNING! Shifting into or out of 4L is possible with the vehicle • Do not attempt to make a shift while only the front completely stopped; however, difficulty may occur due On vehicles equipped with a limited-slip differential, or rear wheels are spinning.
Page 142: Axle Lock (Tru-Lok) Rear Only - If Equipped
STARTING AND OPERATING NOTE: To activate the system, push the AXLE LOCK switch The AXLE LOCK switch is located on the instrument down to lock the rear axle only (the “REAR ONLY” will panel (to the right of the steering column). The indicator lights will flash until the rear axle is fully illuminate), push the switch up to lock the front axle locked or unlocked.
Page 143: Off Road+ - If Equipped
STARTING AND OPERATING Push the SWAY BAR switch to disconnect or connect the To return to on-road mode, push the SWAY BAR switch When activated, OFF ROAD+ is designed to improve the sway bar. The Sway Bar Indicator Light (located in the again.
Page 144: Electro-Hydraulic Power Steering
STARTING AND OPERATING STOP/START SYSTEM — AUTOMATIC CAUTION! • Engine/Transmission Calibration: Improved sand TRANSMISSION (IF EQUIPPED) performance/wheel slip focus, change in shift Extreme steering maneuvers may cause the electri- schedule for sport mode, pedal calibration set to cally driven pump to reduce or stop power steering aggressive, operates at elevated vehicle speeds assistance in order to prevent damage to the system.
Page 145: Autostop Mode
STARTING AND OPERATING To Activate The Autostop Mode, The Following Must • Engine has not reached normal operating Occur: temperature • • The system must be in STOP/START READY state. A Engine or exhaust temperature is too high STOP/START READY message will be displayed in •...
Page 146: To Manually Turn Off The Stop/Start System
STARTING AND OPERATING NOTE: • Secondary Battery HVAC system temperature or fan speed is manually adjusted The Stop/Start system will reset itself back to an ON Your vehicle may be equipped with a secondary battery • condition every time the ignition is turned off and back Battery voltage drops too low used to power the Stop/Start system and the 12 Volt vehicle electrical system.
Page 147: Possible Reasons The Engine Does Not Autostop
STARTING AND OPERATING • • The Stop/Start feature is enabled after every normal When driving in REVERSE Stop/Start OFF switch is pressed customer engine start. It will remain in STOP/START • • Hood is open Transfer case is in 4L or N (Neutral) NOT READY until you drive forward with a vehicle speed •...
Page 148: To Manually Turn On The Stop/Start System
STARTING AND OPERATING • TO MANUALLY TURN ON THE Only one Cruise Control feature can operate at a WARNING! time. For example, if Fixed Speed Cruise Control is STOP/START SYSTEM enabled, Adaptive Cruise Control will be unavailable, Cruise Control can be dangerous where the system and vice versa.
Page 149: Adaptive Cruise Control (Acc)
STARTING AND OPERATING USING CRUISE CONTROL ON HILLS • When the vehicle has reached the desired speed, push Clutch pedal is pressed (manual transmission only) the SET (+) or SET (-) button and release. Release the • Vehicle is operating at a low RPM (manual transmis- The transmission may downshift on hills to maintain the accelerator and the vehicle will operate at the selected sion only)
Page 150 STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation Adaptive Cruise Control Ready WARNING! When ACC is activated, but the vehicle speed setting The buttons on the right side of the steering wheel • has not been selected, the display will read “Adaptive Adaptive Cruise Control (ACC) is a convenience operate the ACC system.
Page 151 STARTING AND OPERATING To Set A Desired Speed NOTE: • When the parking brake is applied • When the automatic transmission is in PARK, When the vehicle reaches the speed desired, push the • Keeping your foot on the accelerator pedal can SET (+) button or the SET (-) button and release.
Page 152 STARTING AND OPERATING NOTE: • Metric Speed (km/h) The driver shifts to FIRST gear (manual transmission only) Pushing the SET (+), or SET (-) button once will • • While in ACC mode when the vehicle comes to a • Vehicle is operating at a low RPM (manual transmis- result in a 1 km/h speed adjustment.
Page 153 STARTING AND OPERATING Setting The Following Distance In ACC Overtake Aid If there is no vehicle ahead, the vehicle will maintain the set speed. If a slower moving vehicle is detected in The specified following distance for ACC can be set by When driving with ACC engaged and following a vehicle, the same lane, the instrument cluster displays the ACC varying the distance setting between four bars (lon-...
Page 154 STARTING AND OPERATING “CLEAN FRONT WINDSHIELD” WARNING If weather conditions are not a factor, the driver should WARNING! examine the sensor. It may require cleaning or removal The “ACC/FCW Limited Functionality Clean Front Wind- of an obstruction. The sensor is located in the center of When the ACC system is resumed, the driver must shield”...
Page 155 STARTING AND OPERATING SERVICE ACC/FCW WARNING USING ACC ON HILLS If the system turns off, and the instrument cluster dis- ACC performance may be limited when driving on hills. play reads “ACC/FCW Unavailable Service Required” or ACC may not detect a vehicle in your lane depending on “Cruise/FCW Unavailable Service Required”, there may the speed, vehicle load, traffic conditions, and the be an internal system fault or a temporary malfunction...
Page 156: Parksense Front/Rear Park Assist System - If Equipped
STARTING AND OPERATING STATIONARY OBJECTS AND VEHICLES ParkSense can be active only when the gear selector is in REVERSE or DRIVE. If ParkSense is enabled at one of ACC does not react to stationary objects or vehicles. For these gear selector positions, the system will remain example, ACC will not react in situations where the active until the vehicle speed is increased to approxi- vehicle you are following exits your lane and the vehicle...
Page 157: Parksense Display
STARTING AND OPERATING PARKSENSE DISPLAY The warning display will turn on indicating the system status when the vehicle is in REVERSE or when the vehicle is in DRIVE and an obstacle has been detected. The system will indicate a detected obstacle by showing a single arc in one or more regions based on the obsta- cle’s distance and location relative to the vehicle.
Page 158 STARTING AND OPERATING ParkSense Arcs 1 — No Tone/Solid Arc 6 — Fast Tone/Flashing Arc 2 — No Tone/Flashing Arc 7 — Fast Tone/Flashing Arc 3 — Fast Tone/Flashing Arc 8 — Slow Tone/Solid Arc 4 — Continuous Tone/Flashing Arc 9 —...
Page 159 STARTING AND OPERATING The vehicle is close to the obstacle when the display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the sys- tem is detecting an obstacle: WARNING ALERTS FOR REAR Greater than Rear Distance 79-59 inches...
Page 160: Enabling And Disabling Parksense
STARTING AND OPERATING Front Park Assist Audible Alerts SERVICE THE PARKSENSE PARK PARKSENSE SYSTEM USAGE ParkSense will turn off the Front Park Assist audible ASSIST SYSTEM PRECAUTIONS alert (chime) after approximately three seconds when an obstacle has been detected, the vehicle is station- During vehicle start up, when the ParkSense system has NOTE: ary, and the brake pedal is applied.
Page 161: Parkview Rear Back Up Camera
STARTING AND OPERATING (30 cm) of the rear fascia/bumper. Failure to do so When the vehicle is shifted out of REVERSE with Cam- CAUTION! can result in the system misinterpreting a close era delay turned off, the rear Camera mode is exited obstacle as a sensor problem, causing the and the previous screen appears again.
Page 162: Trailcam System - If Equipped
STARTING AND OPERATING NOTE: The following table shows the approximate distances TRAILCAM SYSTEM — IF EQUIPPED for each zone: If snow, ice, mud, or any foreign substance builds up on Your vehicle may be equipped with a TrailCam that the camera lens, clean the lens, rinse with water, and allows you to you see an on-screen image of the front Distance To The Rear Of dry with a soft cloth.
Page 163: Refueling The Vehicle - Gasoline Engine (If Equipped)
STARTING AND OPERATING Cleaning The TrailCam The TrailCam view can also be activated by pressing the 1. Open the fuel filler door. icon on the Back Up Camera view. The Back Up Press and hold the Clean Camera button located on the Camera view can also be activated by pressing the TrailCam view to wash the TrailCam.
Page 164: Loose Fuel Filler Cap Message
STARTING AND OPERATING NOTE: 3. Fully insert the gasoline nozzle into the filler pipe. 1. Open the fuel filler door. Fill the vehicle with fuel. • When the fuel nozzle “clicks” or shuts off, the fuel 4. When the fuel nozzle “clicks” or shuts off, the fuel tank is full.
Page 165: Avoid Using Contaminated Fuel
STARTING AND OPERATING System Overview NOTE: 4. When the nozzle “clicks” or shuts off, the fuel tank is full. Wait five seconds before removing the fuel When a diesel engine is allowed to run out of fuel, air is This vehicle is equipped with a Diesel Exhaust Fluid nozzle to allow excess fuel to drain from nozzle.
Page 166 STARTING AND OPERATING Diesel Exhaust Fluid Storage DEF FILL PROCEDURE ○ The DEF gauge may also not immediately update after a refill if the temperature of the DEF fluid is NOTE: Diesel Exhaust Fluid (DEF) is considered a very stable below 12°F (-11°C).
Page 167: Vehicle Loading
STARTING AND OPERATING VEHICLE LOADING Each axle GAWR is determined by the components in CAUTION! the system with the lowest load carrying capacity (axle, springs, tires or wheels). Heavier axles or suspension • To avoid DEF spillage, and possible damage to the CERTIFICATION LABEL components sometimes specified by purchasers for DEF tank from overfilling, do not “top off”...
Page 168: Trailer Towing
STARTING AND OPERATING Loading TRAILER TOWING WARNING! The actual total weight and the weight of the front and In this section you will find safety tips and information If the gross trailer weight is 2,000 lb (907 kg) or rear of your vehicle at the ground can best be deter- on limits to the type of towing you can reasonably do more, it is recommended to use a weight-distributing mined by weighing it when it is loaded and ready for...
Page 169 STARTING AND OPERATING Frontal Area WARNING! The frontal area is the maximum height multiplied by • An improperly adjusted Weight-Distributing Hitch the maximum width of the front of a trailer. system may reduce handling, stability, braking per- Trailer Sway Control (TSC) — If Equipped formance, and could result in a collision.
Page 170: Trailer Hitch Classification
STARTING AND OPERATING Recommended Distribution Hitch Adjustment 3. Attach the trailer to the vehicle without the weight distribution bars connected. 1. Position the truck to be ready to connect to the trailer (do not connect the trailer). 4. Measure the height from the top of the front fender to ground, this is height H2.
Page 171: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) Model GCWR Frontal Area Maximum GTW Maximum Trailer TW (See Note) Sport - Manual Transmission 9,100 lb (4,128 kg) 40 ft (3.72 m 4,000 lb (1,814 kg) 400 lb (181 kg) Sport - Automatic Transmission 9,650 lb (4,377 kg) 40 ft...
Page 172: Trailer And Tongue Weight
STARTING AND OPERATING Model GCWR Frontal Area Maximum GTW Maximum Trailer TW (See Note) Overland - Automatic Transmis- 11,100 lb (5,035 kg) 40 ft (3.72 m 6,000 lb (2,722 kg) 600 lb (272 kg) sion (Tow Package) Diesel Overland - Automatic 12,100 lb (5,488 kg) 40 ft (3.72 m...
Page 173: Towing Requirements
STARTING AND OPERATING Towing Requirements — Trailer Brakes TOWING REQUIREMENTS WARNING! Do not interconnect the hydraulic brake system or • To promote proper break-in of your new vehicle drive- Total weight must be distributed between the tow • vacuum system of your vehicle with that of the train components, the following guidelines are vehicle and the trailer such that the following four trailer.
Page 174 STARTING AND OPERATING If the trailer weighs more than 1,000 lbs (453 kg) loaded, it should have its own brakes and they should be of adequate capacity. Failure to do this could lead to accelerated brake lining wear, higher brake pedal effort, and longer stopping distances.
Page 175: Towing Tips
STARTING AND OPERATING NOTE: • TOWING TIPS To prevent excess heat generation, avoid continuous driving at high RPM. Return to a higher gear or Using a lower gear while operating the vehicle under Before towing, practice turning, stopping and backing vehicle speed when grade and road conditions heavy loading conditions, will improve performance and the trailer in an area away from heavy traffic.
Page 176: Recreational Towing - Four-Wheel Drive Models
STARTING AND OPERATING RECREATIONAL TOWING — 4. Turn the engine off. CAUTION! FOUR-WHEEL DRIVE MODELS 5. Shift the transfer case lever into N (Neutral). • Do not use a bumper-mounted clamp-on tow bar 6. Start the engine. on your vehicle. The bumper face bar will be NOTE: damaged.
Page 177: Driving Tips
STARTING AND OPERATING Shifting Out of N (Neutral) DRIVING TIPS Use the following procedure to prepare your vehicle for normal usage. ON-ROAD DRIVING TIPS 1. Bring the vehicle to a complete stop, leaving it con- Utility vehicles have higher ground clearance and a nar- nected to the tow vehicle.
Page 178 STARTING AND OPERATING NOTE: 3. After all bolts and nuts have been removed, pull the side step assembly off of the vehicle. It is recommended that the Stop/Start system be dis- abled during off-road use. 4. To reinstall the side steps align the studs to the body side holes and fasten all nuts on all four brack- ets.
Page 179 STARTING AND OPERATING Simultaneous Brake And Throttle Crossing Obstacles (Rocks And Other turning your steering wheel no more than a quarter turn Operation quickly back and forth for additional traction. Mud High Points) holes pose an increased threat of vehicle damage and Many off-road driving conditions require the simultane- While driving off-road, you will encounter many types of getting stuck.
Page 180 STARTING AND OPERATING Hill Climbing CROSSING LOGS The tread of the tire is tougher and thicker than the side wall and is designed to take the abuse. Always look To cross a log, approach it at a slight angle (approxi- Hill climbing requires good judgment and a good under- ahead and make every effort to cross the large rocks mately 10 to 15 degrees).
Page 181 STARTING AND OPERATING Driving Through Water DRIVING ACROSS AN INCLINE into the surface and will usually provide enough trac- tion to complete the climb. If you do not make it to the If at all possible, avoid driving across an incline. If it is Extreme care should be taken crossing any type of top, place the vehicle in REVERSE and back straight necessary, know your vehicle's abilities.
Page 182 STARTING AND OPERATING BEFORE YOU CROSS ANY TYPE OF WATER CROSSING DITCHES, STREAMS, SHALLOW • Completely inspect the underbody of your vehicle. Check tires, body structure, steering, suspension, RIVERS OR OTHER FLOWING WATER As you approach any type of water, you need to deter- driveline, and exhaust system for damage.
Page 183: Multimedia
MULTIMEDIA UCONNECT SYSTEMS UCONNECT SETTINGS WARNING! • For detailed information about your Uconnect 4/4C/4C The Uconnect system uses a combination of buttons on ONLY insert trusted devices/components into your NAV With 8.4-inch Display system, refer to your the touchscreen and buttons on the faceplate located vehicle.
Page 184: Customer Programmable Features
MULTIMEDIA NOTE: CUSTOMER PROGRAMMABLE FEATURES • Depending on the vehicle’s options, feature settings may vary. • All settings should be changed with the ignition in the ON/RUN position. When making a selection, only press one button at a time to enter the desired menu. Once in the desired menu, press and release the preferred setting option until a check mark appears next to the setting, showing that setting has been selected.
Page 185 MULTIMEDIA Language When the Language button is pressed on the touchscreen, the system displays the different language options. Once an option is selected, the system will display in the chosen language. The available setting is: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Language...
Page 186 MULTIMEDIA Setting Name Description Keyboard This setting will change the keyboard type on the display. The selectable keyboards are “ABCDEF Keyboard”, “QWERTY Keyboard”, and “AZERTY Keyboard”. Touchscreen Beep This setting will allow you to turn the touchscreen beep on or off. Control Screen Timeout This setting allows you to set the Control Screen to turn off automatically after five seconds or stay open until manually closed.
Page 187 MULTIMEDIA Voice When the Voice button is pressed on the touchscreen, the system displays the options related to the vehicle’s Voice Recognition feature. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Voice Response Length This setting will change the response length for the Voice Recognition system. The “Brief” setting provides a shortened audio description from the system.
Page 188 MULTIMEDIA Camera When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description ParkView Backup Camera Delay This setting will add a timed delay to the ParkView Backup Camera when shifting out of REVERSE. ParkView Backup Camera Active Guidelines This setting will turn the ParkView Backup Camera Active Guidelines on or off.
Page 189 MULTIMEDIA Setting Name Description Forward Collision Warning This setting will turn the Forward Collision Warning system on or off. The “Off” setting will deactivate the FCW system. The “Warning Only” setting will provide only an audible chime when a collision is detected. The “Warning + Active Braking” set- ting will provide an audible chime and apply some brake pressure when a collision is detected.
Page 190 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE: • When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchased.
Page 191 MULTIMEDIA Setting Name Description Sound Horn With Lock This setting will sound the horn when the Lock button is pushed on the key fob. The “Off” setting will not sound the horn when the Lock button is pushed. The “1st Press” setting will sound the horn when the Lock button is pushed once. The “2nd Press”...
Page 192 MULTIMEDIA AUX Switches — If Equipped When the AUX button is pressed on the touchscreen, the system displays the options related to the four vehicle AUX switches: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description AUX 1-4 This setting will adjust the type and power source for the four vehicle AUX switches.
Page 193 MULTIMEDIA Compass Settings — If Equipped When the Compass Settings button is pressed on the touchscreen, the system displays the options related to compass variance and calibration. These settings will only activate when the ignition is set to OFF. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 194 MULTIMEDIA Setting Name Description Speed Adjusted Volume This setting will adjust audio volume as speeds increase. At a higher setting, the volume will increase more as the vehicle speeds up. The available settings are “Off”, “1”, “2”, and “3”. Surround Sound This setting will turn the Surround Sound system on or off.
Page 195 MULTIMEDIA SiriusXM® Setup — If Equipped When the SiriusXM® Setup button is pressed on the touchscreen, the system displays options related to SiriusXM® satellite radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning. NOTE: •...
Page 196 MULTIMEDIA System Information When the System Information button is pressed on the touchscreen, the system displays the radio system information. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Software Licenses This will display the software licensing information screen. Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following setting will be available: NOTE:...
Page 197: Uconnect Introduction
MULTIMEDIA UCONNECT INTRODUCTION SYSTEM OVERVIEW Uconnect 3 With 5-inch Display 1 — RADIO Button 6 — COMPASS Button 2 — MEDIA Button 7 — SETTINGS Button 3 — PHONE Button 8 — MORE Button 4 — VOLUME & On/Off Button 9 —...
Page 198 MULTIMEDIA Uconnect 4 With 7-inch Display 1 — Radio Button 5 — Controls Button 2 — Media Button 6 — Phone Button 3 — Climate Button 7 — Settings Button 4 — Apps Button NOTE: Uconnect screen images are for illustration purposes only and may not reflect exact software for your vehicle.
Page 199 MULTIMEDIA Feature Description Radio/Media Press/Push the Radio button or Media button to enter Radio Mode/Media Mode and access the radio functions and external audio sources page 199. Phone Press/Push the Phone button to enter Phone Mode and access the hands-free phone system page 210.
Page 200: Drag & Drop Menu Bar
MULTIMEDIA Feature Description Compass Push the COMPASS button on the faceplate to access the vehicle’s compass. More Push the MORE button on the faceplate to access additional options. Feature Description Controls — If Equipped Press the Controls button to access vehicle-specific features like heated seats and steering wheel.
Page 201: Uconnect Modes
MULTIMEDIA Safe Usage Of The Uconnect System UCONNECT MODES The left-hand control is a rocker-type switch with a push button in the center. The function of the left-hand con- • The Uconnect system is a sophisticated electronic trol is different depending on which mode you are in. device.
Page 202: Radio Mode
MULTIMEDIA Volume & On/Off Control RADIO MODE Push the VOLUME & On/Off control knob to turn on and Radio Controls off the Uconnect system. The electronic volume control turns continuously (360 degrees) in either direction, without stopping. Turning the VOLUME & On/Off control knob clockwise increases the volume, and counterclockwise decreases When the audio system is turned on, the sound will be set at the same volume level as last played.
Page 203 MULTIMEDIA Fast Seek Up and Fast Seek Down RADIO VOICE COMMANDS Press and hold, and then release the Seek Up Use your voice to quickly get to the AM, FM, or Seek Down button to advance the radio through SiriusXM® Satellite Radio stations you would like to the available stations or channels at a faster rate.
Page 204 MULTIMEDIA All fees and programming subject to change. SiriusXM® When in Satellite Mode: satellite service is available only to those at least • The SXM button on the touchscreen is highlighted. 18 and older in the 48 contiguous US and D.C. Our •...
Page 205 MULTIMEDIA REPLAY Replay provides a means to store and replay up to 22 minutes of music audio and 48 minutes of talk radio. Once the channel is switched, content in replay memory is lost. Press the Replay button on the touchscreen. The Play/Pause, Rewind/Forward and Live buttons will display at the top of the screen, along with the replay time. You can exit by pressing the Replay button on the touchscreen any time during the Replay Mode.
Page 206 MULTIMEDIA FAVORITES BROWSE IN SXM • Genre List: Press the Genre button on the touch- screen to display a list of Genres. You can select any Press the Favorites button on the touchscreen to acti- desired Genre by pressing the Genre List. The radio vate the favorites menu, which will time out within tunes to a channel with the content in the selected 20 seconds in absence of user interaction.
Page 207 MULTIMEDIA Remove Favorites Alert Settings Press the Remove Favorites tab at the top of the Press the Alert Setting tab at the top of the screen. The screen. Press the Delete All button on the touchscreen Alert Settings menu allows you to choose from “Alert to delete all of the Favorites or press the Trash Can icon me to on-air games upon start”...
Page 208 MULTIMEDIA Audio Settings PRESET FEATURES — IF EQUIPPED Browse In AM/FM Press the Audio button within the settings main menu to activate the Audio Settings screen. When in either AM or FM, the Browse screen provides a means to edit the Presets List and is entered by push- The audio settings can also be accessed on the Radio ing the ENTER/BROWSE button.
Page 209 MULTIMEDIA Audio Setting Description Press the Balance/Fade button on the touchscreen to balance audio between the front speakers or fade the audio between the rear and front speakers. Press the Front, Balance/Fade Rear, Left or Right button or press and drag the red Speaker icon to adjust the Balance/Fade.
Page 210: Media Mode
MULTIMEDIA • MEDIA MODE Media Mode is entered by pushing the MEDIA button Albums located on the faceplate. • Genres Operating Media Mode • Songs • Playlists • Folders You can press the Source, Pause/Play, or the Info but- ton on the touchscreen for artist information on the current song playing.
Page 211 MULTIMEDIA Before proceeding, the Bluetooth® device must be To insert an Auxiliary device, gently insert the Auxiliary you can browse through the contents of the USB device. paired to the Uconnect Phone to communicate with the device cable into the AUX port. If you insert an Auxiliary If supported by the device, you can browse by Folder, Uconnect system.
Page 212: Phone Mode
MULTIMEDIA Shuffle • Push the VR button located on the steering wheel. Viewing call logs on screen (“Show Incoming Calls,” After the beep, say one of the following commands and “Show Outgoing Calls,” “Show Missed Calls,” or In USB Mode, press the Shuffle button on the touch- follow the prompts to switch your media source or “Show Recent Calls”).
Page 213 MULTIMEDIA Phone Operation NATURAL SPEECH WARNING! Your Uconnect Phone Voice system uses a Natural Lan- OPERATION guage Voice Recognition (VR) engine. ALWAYS drive safely with your hands on the steering wheel. You have full responsibility and assume all Voice commands can be used to operate the Uconnect Natural speech allows the user to speak commands in risks related to the use of the Uconnect features and Phone and to navigate its menu structure.
Page 214 MULTIMEDIA PAIR (LINK) UCONNECT PHONE TO A MOBILE 4. Search for available devices on your Bluetooth®-enabled mobile phone. PHONE ○ Press the Settings button on your mobile phone. Use this QR code to access your digital ○ Select “Bluetooth®” and ensure it is enabled. experience.
Page 215 MULTIMEDIA PAIR A BLUETOOTH® STREAMING AUDIO vehicle. Only one mobile phone and/or one You can also use a following VR command to bring up a Bluetooth® audio device can be connected to the list of paired audio devices: DEVICE Uconnect system at a time. If “No” is selected, sim- •...
Page 216 MULTIMEDIA • 3. Press the Make Favorite button on the touchscreen; Only the phonebook of the currently connected you will see the chosen device move to the top of mobile phone is accessible. the list. • This downloaded phonebook cannot be edited or deleted on the Uconnect Phone.
Page 217 MULTIMEDIA Phone Call Features CALL CONTROLS The following features can be accessed through the The touchscreen allows you to control the following call Uconnect Phone if the feature(s) are available and sup- features: ported by Bluetooth® on your mobile service plan. For example, if your mobile service plan provides three-way calling, this feature can be accessed through the Uconnect Phone.
Page 218 MULTIMEDIA RECENT CALLS — IF EQUIPPED ANSWER OR IGNORE AN INCOMING CALL — CALL CURRENTLY IN PROGRESS You may browse a list of the most recent of each of the following call types: If a call is currently in progress and you have another •...
Page 219 MULTIMEDIA NOTE: TOGGLING BETWEEN CALLS JOIN CALLS Only the first 25 characters can be seen on the When two calls are in progress (one active and one on touchscreen while typing a custom message. hold), press the Join/Merge Calls button on the Phone While in Do Not Disturb, “Conference Call”...
Page 220 MULTIMEDIA Advanced Phone Connectivity Echo at the far end can sometimes be reduced by low- WARNING! ering the in-vehicle audio volume. TRANSFER CALL TO AND FROM MOBILE Phone Voice Commands ALWAYS drive safely with your hands on the wheel. PHONE You have full responsibility and assume all risks Making and answering hands-free phone calls is easy related to the use of the Uconnect features and appli-...
Page 221: Android Auto™ & Apple Carplay
MULTIMEDIA Siri® Eyes Free — If Equipped ANDROID AUTO™ & APPLE CARPLAY® — PRE-DEFINED VOICE TEXT REPLY RESPONSES When used with your Apple® iPhone® connected to Yes. Stuck in traffic. See you later. IF EQUIPPED your vehicle via Bluetooth®, Siri lets you use your voice Start without to send text messages, select media, place phone calls I’ll be late.
Page 222 MULTIMEDIA NOTE: NOTE: • Google Maps™ for navigation • Be sure to use the factory-provided USB cable that To see the track details for the music playing through YouTube Music, Spotify, iHeart Radio, etc. for music came with your phone, as aftermarket cables may Android Auto™, select the Uconnect system’s media •...
Page 223: Apple Carplay
MULTIMEDIA Uconnect touchscreen. Connect your Android™ 6.0 or focused on the road. Use your Uconnect Touchscreen higher to one of the media USB ports, using the factory- display, the vehicle's knobs and controls, and your voice provided USB cable, and press the new Android Auto™ with Siri to get access to Apple Music®, Maps, Mes- icon that replaces your Phone icon on the main menu sages, and more.
Page 224: Android Auto™ And Apple Carplay® Tips And Tricks
MULTIMEDIA Phone Maps • Phone • Music With Apple CarPlay®, push and hold the VR Push and hold the VR button on the steering • button on the steering wheel to activate a wheel until the beep or tap the Microphone Messages Siri voice recognition session.
Page 225: Connected Vehicle Services - If Equipped
MULTIMEDIA What Is SiriusXM Guardian™? Multiple Devices Connecting To The Uconnect System INTRODUCTION TO CONNECTED — If Equipped VEHICLE SERVICES SiriusXM Guardian™ uses an embedded device in the It is possible to have multiple devices connected to the Uconnect system installed in your vehicle, which Uconnect system.
Page 226: Getting Started With Connected Vehicle Services
MULTIMEDIA 3. For customers in the United States, select “Cus- SiriusXM Guardian™ provides: tomer Care” to speak with a SiriusXM Guardian™ • The ability to remotely lock/unlock and remote start Customer Care agent who will activate services in your vehicle from virtually anywhere by using the your vehicle, or select “Enter Email”...
Page 227: Using Siriusxm Guardian
MULTIMEDIA Connected Services Status: • • Press the Location button on the bottom menu bar USING SIRIUSXM GUARDIAN™ of the app to bring up a map to locate your vehicle This statement will indicate your SiriusXM SOS Call — If Equipped or send a location to your Mobile Navigation, Guardian™-equipped vehicle.
Page 228 MULTIMEDIA NOTE: SOS Call System Limitations If your vehicle loses battery power for any reason (including during or after an accident), the SOS Call Certain SiriusXM Guardian™ connected services are Vehicles that have been purchased in the US and that system, among other vehicle systems, will not operate.
Page 229 MULTIMEDIA Automatic SOS — If Equipped • SiriusXM Guardian™ connected services are depen- WARNING! dent upon an operative telematics device, a cellular Automatic SOS is a hands-free safety service that can connection, navigation map data, and GPS satellite (INCLUDING DURING OR AFTER AN ACCIDENT), immediately connect you with help in the event that reception, which can limit the ability to reach the NEITHER THE MOBILE APPS NOR THE SIRIUSXM...
Page 230 MULTIMEDIA Remote Commands On the Remote Commands screen, you have access to several vehicle features that can be controlled remotely from your mobile device. These features include locking/unlocking, remote starting, and activating the horn and lights of the vehicle. Lock Press this button to lock your vehicle.
Page 231 MULTIMEDIA Remote Vehicle Start Working Vehicle Conditions • Your mobile device must have a cellular or Wi-Fi connection. • The vehicle must in PARK or at a standstill. Description • If the Panic button has been pressed, the vehicle • The vehicle must be in an open area with cell tower The Remote Vehicle Start feature provides you with the must be started at least once after alarming the...
Page 232 MULTIMEDIA Assist — If Equipped Requirements How It Works • This feature is available only on vehicles sold in the Description 1. There are multiple ways to find a destination. After US and Canada. selecting the Location tab at the bottom of the App, Vehicles equipped with the SiriusXM Guardian™...
Page 233 MULTIMEDIA How It Works NOTE: WARNING! A SiriusXM Guardian™ subscription is not required in Select the Vehicle Finder function within the Mobile App order to purchase and use the 4G Wi-Fi Hotspot. and select the Location tab at the bottom of the App. The driver should NEVER use the 4G Wi-Fi Hotspot Then, press the Vehicle icon to find your vehicle.
Page 234 MULTIMEDIA 3. SiriusXM Guardian™ Customer Care will authenti- In order to provide the Monthly Vehicle Health Report, receive a notification through your touchscreen, press cate that you are the owner of the vehicle and con- the Uconnect system in your vehicle may collect and OK to dismiss the message, or press Call Care to speak tact the law enforcement with whom you filed the transmit vehicle data to SiriusXM Guardian™...
Page 235: Manage My Siriusxm Guardian™ Account
MULTIMEDIA Speed Alert • Next, link the Uconnect system on your vehicle to Ama- MANAGE MY SIRIUSXM zon Alexa: Receive a notification whenever your car exceeds a GUARDIAN™ ACCOUNT speed limit you set. 1. Download the Amazon Alexa app on your mobile To manage your SiriusXM Guardian™...
Page 236: Connected Services Remote Door Lock/Unlock Faqs
MULTIMEDIA 2. What type of information is sent when I use the 5. Why is the Mobile App running slow? The Mobile 3. Can I select a different route than the most recent SOS Call button from my vehicle? Certain vehicle one I sent to my vehicle? Yes, once you enter the App relies on a mobile network connection from information, such as make and model, is transmit-...
Page 237: Connected Services Remote Vehicle Start Faqs
MULTIMEDIA 2. Which is faster, my key fob or the Mobile App? Your subject to a valid court order telling SiriusXM Guard- are leaving the stadium after the game, you can use ian™ to do so. We will also provide the service for the Mobile App to remote start your vehicle and key fob will sound the horn and flash the lights FCA entities to locate a vehicle that you have pur-...
Page 238 MULTIMEDIA 7. Can I try features or packages before I buy them? tions. Then, you will be directed to the SiriusXM You also can visit your Owner’s Site and choose a Guardian™ home page to complete your profile Your new vehicle purchase may have come with an subscription to view its expiration date.
Page 239: Data Collection & Privacy
MULTIMEDIA RADIO OPERATION AND MOBILE PHONES OFF-ROAD PAGES — IF EQUIPPED that required your smartphone only direct calls to Roadside Assistance Call may be functioning if you have an operable network. Under certain conditions, the mobile phone being on in If your vehicle is equipped with Off-Road Pages, it will your vehicle can cause erratic or noisy performance provide you vehicle status while operating on off-road...
Page 240: Off-Road Pages Status Bar
MULTIMEDIA OFF-ROAD PAGES STATUS BAR DRIVETRAIN ACCESSORY GAUGE The Off-Road Pages Status Bar is located along the bot- The Drivetrain page displays information concerning the The Accessory Gauge page displays the current status tom of Off-Road Pages and is present in each of the vehicle’s drivetrain.
Page 241: Pitch & Roll
MULTIMEDIA PITCH & ROLL The Pitch & Roll page displays the vehicle’s current pitch (angle up and down) and roll (angle side to side) in degrees. The Pitch & Roll gauges provide a visualiza- tion of the current vehicle angle. Pitch &...
Page 242: Safety
SAFETY Anti-Lock Brake System (ABS) Warning SAFETY FEATURES WARNING! Light • The ABS contains sophisticated electronic equip- ANTI-LOCK BRAKE SYSTEM (ABS) The yellow ABS Warning Light will turn on when the igni- ment that may be susceptible to interference tion is placed in the ON/RUN mode and may stay on for caused by improperly installed or high output radio The ABS provides increased vehicle stability and brake as long as four seconds.
Page 243 SAFETY Brake System Warning Light WARNING! WARNING! The red Brake System Warning Light will turn on when turns, driving on very slippery surfaces, or hydroplan- Many factors, such as vehicle loading, road condi- the ignition is placed in the ON/RUN mode, and may ing.
Page 244 SAFETY ESC Operating Modes Activation/Malfunction Indicator Light begins to flash WARNING! during acceleration, ease up on the accelerator and Depending upon model and mode of operation, the ESC apply as little throttle as possible. Be sure to adapt your • When in “Partial Off”...
Page 245 SAFETY Indicator Light also flashes when the Traction Control The following conditions must be met in order for HSA WARNING! System (TCS) is active. If the ESC Activation/ to activate: Malfunction Indicator Light begins to flash during accel- • • The feature must be enabled.
Page 246 SAFETY Disabling And Enabling HSA Ready Alert Braking (RAB) Activating SSC Once SSC is enabled it will activate automatically once This feature can be turned on or turned off. To change RAB may reduce the time required to reach full braking the following conditions are met: the current setting, see page 181 for further...
Page 247 SAFETY SSC Target Set Speeds — If Equipped With Off Road+ • The vehicle speed exceeds 20 mph (32 km/h) but WARNING! remains below 40 mph (64 km/h). • 1st = 0.6 mph (1 km/h) • The vehicle is shifted into PARK. •...
Page 248: Auxiliary Driving Systems
SAFETY When TSC is functioning, the ESC Activation/ When the vehicle is started, the BSM Warning Light will The BSM system can become blocked if snow, ice, mud, Malfunction Indicator Light will flash, the engine power momentarily illuminate in both outside rearview mirrors or other road contaminations accumulate on the rear may be reduced, and you may feel the brakes being to let the driver know that the system is operational.
Page 249 SAFETY Entering From The Rear Vehicles that come up from behind your vehicle on either side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h). Warning Light Location Overtaking/Approaching The BSM system monitors the detection zone from three different entry points (side, rear, front) while driv- ing to see if an alert is necessary.
Page 250 SAFETY WARNING! Rear Cross Path Detection (RCP) is not a backup aid system. It is intended to be used to help a driver detect an oncoming vehicle in a parking lot situation. Drivers must be careful when backing up, even when using RCP.
Page 251: Forward Collision Warning (Fcw) With Mitigation - If Equipped
SAFETY NOTE: FORWARD COLLISION WARNING Whenever an audible alert is requested by the BSM (FCW) WITH MITIGATION — system, the radio is also muted. IF EQUIPPED When the system is in RCP mode, the system shall respond with both visual and audible alerts when a FCW with Mitigation provides the driver with audible detected object is present.
Page 252 SAFETY • • When FCW status is set to “Warning and Braking”, Near WARNING! ○ this allows the system to warn the driver of a pos- When the sensitivity of FCW is set to the “Near” sible collision with the vehicle in front using audible/ setting and the system status is “Only Warning”, Forward Collision Warning (FCW) is not intended to visual warnings and it applies autonomous braking.
Page 253: Tire Pressure Monitoring System (Tpms)
SAFETY TIRE PRESSURE MONITORING Light) illuminates, you must increase the tire pressure CAUTION! to the recommended cold placard pressure in order for SYSTEM (TPMS) the TPMS Warning Light to turn off. same size, type, and/or style. The TPMS sensor is The Tire Pressure Monitoring System (TPMS) will warn not designed for use on aftermarket wheels, and The system will automatically update and the TPMS...
Page 254 SAFETY • The TPMS is not a substitute for proper tire mainte- The TPMS consists of the following components: receives the updated tire pressures, the system will nance, and it is the driver’s responsibility to main- automatically update, the pressure values in the •...
Page 255 SAFETY • • • Lots of snow or ice around the wheels or wheel The Tire Fill Alert feature cannot be entered if an The horn will chirp once again when enough air is let housings. existing TPMS system fault is set to “active” or if the out to reach proper inflation level.
Page 256: Occupant Restraint Systems
SAFETY You may also store pressure values chosen for each 1. The horn will chirp once when the selected pressure display pressure values in place of the dashes. On the axle in the Uconnect system application as preset pres- is reached to let you know when to stop inflating or next ignition cycle the "SERVICE TIRE PRESSURE SYS- sure values.
Page 257: Seat Belt Systems
SAFETY Initial Indication 3. If a child from 2 to 12 years old (not in a rear-facing WARNING! child restraint) must ride in the front passenger If the driver is unbuckled when the ignition switch is seat, move the seat as far back as possible and use •...
Page 258 SAFETY The outboard front passenger seat BeltAlert is not WARNING! WARNING! active when the outboard front passenger seat is unoc- cupied. BeltAlert may be triggered when an animal or • In a collision, you and your passengers can suffer • A lap belt worn too high can increase the risk of other items are placed on the outboard front passenger much greater injuries if you are not properly buck-...
Page 259 SAFETY WARNING! • A frayed or torn seat belt could rip apart in a colli- sion and leave you with no protection. Inspect the seat belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the seat belt system.
Page 260 SAFETY NOTE: 3. Slide the latch plate upward over the folded web- WARNING! bing. The folded webbing must enter the slot at the The adjustable upper shoulder belt anchorage is top of the latch plate. equipped with an Easy Up feature. This feature allows •...
Page 261 SAFETY Switchable Automatic Locking Retractor Position the lap belt snug and low below the abdomen installed in a seating position that has a seat belt with and across the strong bones of the hips. Place the (ALR) this feature. Children 12 years old and under should shoulder belt across the chest and away from the neck.
Page 262: Supplemental Restraint Systems (Srs)
SAFETY Air Bag System Components WARNING! • Occupant Restraint Controller (ORC) • The seat belt assembly must be replaced if the • Air Bag Warning Light switchable Automatic Locking Retractor (ALR) fea- • Steering Wheel and Column ture or any other seat belt function is not working •...
Page 263 SAFETY Redundant Air Bag Warning Light Bag Warning Light, either momentarily or continuously. A single chime will sound to alert you if the light comes If a fault with the Air Bag Warning Light is on again after initial startup. detected, which could affect the Supplemen- The ORC also includes diagnostics that will illuminate tal Restraint System (SRS), the Redundant...
Page 264 SAFETY Driver And Passenger Front Air Bag cator Light illuminates the words “PASSENGER AIR BAG deploy in all frontal collisions, including some that may Features OFF” to show that the Passenger Advanced Front Air produce substantial vehicle damage — for example, Bag will not deploy during a collision.
Page 265 SAFETY for occupants whose seated weight classifies them in a Bag. In order for the OCS to operate as designed, it is The OCS may deactivate the deployment of the Passen- category other than a properly seated adult. This could important for the front passenger to be seated properly ger Advanced Front Air Bag if the OCS estimates that: be a child, teenager, or even an adult.
Page 266 SAFETY Passenger Air Bag Disable (PAD) System Front Passenger Seat Occupant Status Front Passenger Advanced Air Bag Disabled Indica- Front Passenger Air Bag Status tor Light (“PAD”) Status Child, including a child in a forward-facing child restraint “PASSENGER AIR BAG OFF” DEACTIVATED or booster seat** Small adult...
Page 267 SAFETY Lighter Weight Passengers (Including Small Adults) 3. Place the seatback in the full upright position. front passenger seat may result in activation of the Pas- senger Advanced Front Air Bag. Examples of improper When a lighter weight passenger, including a small 4.
Page 268 SAFETY The OCS determines the front passenger’s most prob- WARNING! able classification. If an occupant in the front passen- ger seat is seated improperly, the occupant may provide • If a child restraint system, child, small teenager or an output signal to the OCS that is different from the adult in the front passenger seat is seated improp- occupant’s properly seated weight input, for example: erly, the occupant may provide an output signal to...
Page 269 SAFETY Knee Impact Bolsters The following requirements must be strictly followed: WARNING! • Do not modify the front passenger seat assembly or The Knee Impact Bolsters help protect the knees of the • components in any way. Ignoring the Air Bag Warning Light in your instru- driver and front passenger, and position the front occu- ment panel could mean you won’t have the air •...
Page 270 SAFETY sensors aid the ORC in determining the appropriate WARNING! response to impact events. The system is calibrated to deploy the Side Air Bags on the impact side of the against the seats. Children must be properly vehicle during impacts that require Side Air Bag occu- restrained in a child restraint or booster seat that pant protection.
Page 271 SAFETY • • Instrument Panel skin or eye irritation, rinse the area with cool water. Flash hazard lights as long as the battery has power For nose or throat irritation, move to fresh air. If the • • Knee Impact Bolsters Turn on the interior lights, which remain on as long irritation continues, see your doctor.
Page 272: Child Restraints
SAFETY Enhanced Accident Response System NOTE: WARNING! Reset Procedure EDR data are recorded by your vehicle only if a non- • Do not attempt to modify any part of your air bag trivial crash situation occurs; no data are recorded by In order to reset the Enhanced Accident Response Sys- system.
Page 273 SAFETY NOTE: There are different sizes and types of restraints for chil- WARNING! dren from newborn size to the child almost large • For additional information, refer to http:// enough for an adult safety belt. Always check the child In a collision, an unrestrained child can become a www.nhtsa.gov/parents-and-caregivers or call: seat Owner’s Manual to make sure you have the correct projectile inside the vehicle.
Page 274 SAFETY Infant And Child Restraints Older Children And Child Restraints WARNING! Safety experts recommend that children ride rear-facing Children who are two years old or who have outgrown • When your child restraint is not in use, secure it in in the vehicle until they are two years old or until they their rear-facing convertible child seat can ride forward- the vehicle with the seat belt or LATCH anchor-...
Page 275 SAFETY WARNING! Never allow a child to put the shoulder belt under an arm or behind their back. In a crash, the shoulder belt will not protect a child properly, which may result in serious injury or death. A child must always wear both the lap and shoulder portions of the seat belt correctly. Recommendations For Attaching Child Restraints Restraint Type Combined Weight of the...
Page 276 SAFETY Lower Anchors And Tethers For CHildren LATCH Positions For Installing Child (LATCH) Restraints In This Vehicle LATCH Label Your vehicle is equipped with the child restraint anchor- LATCH Positions age system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system Lower Anchorage Symbol (2 Anchorages Per Seat- has three vehicle anchor points for installing LATCH- ing Position)
Page 277 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined What is the weight limit (child’s weight + weight of the weight of the child and the child restraint is 65 lb (29.5 child restraint) for using the LATCH anchorage system to 65 lb (29.5 kg) kg).
Page 278 SAFETY Locating The LATCH Anchorages WARNING! The lower anchorages are round bars that Never use the same lower anchorage to attach more are found at the rear of the seat cushion than one child restraint. If you are installing LATCH- where it meets the seatback, adjacent to the compatible child restraints next to each other, you anchorage symbols on the seatback.
Page 279 SAFETY 3. Attach the lower hooks or connectors of the child bing retract back into the retractor. If it is locked, the WARNING! restraint to the lower anchorages in the selected ALR will make a clicking noise while the webbing is seating position.
Page 280 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + Always use the tether anchor when using weight of the child restraint) for using the the seat belt to install a forward-facing Weight limit of the Child Restraint Tether Anchor with the seat belt to attach child restraint, up to the recommended...
Page 281: Safety Tips
SAFETY 8. If the child restraint has a top tether strap and the 1. Place the child restraint on the seat and adjust the WARNING! seating position has a top tether anchorage, con- tether strap so that it will reach over the seat back, nect the tether strap to the anchorage and tighten under the head restraint and to the tether anchor •...
Page 282: Transporting Pets
SAFETY Defroster TRANSPORTING PETS WARNING! Check operation by selecting the defrost mode and Air Bags deploying in the front seat could harm your • ONLY install floor mats designed to fit your vehicle. place the blower control on high speed. You should be pet.
Page 283: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY Fluid Leaks The best protection against carbon monoxide entry into WARNING! the vehicle body is a properly maintained engine Check the area under vehicle after overnight parking for • exhaust system. It is recommended to only use mild soap and water fuel, coolant, oil, or other fluid leaks.
Page 284: Connected Vehicles
SAFETY Connected Vehicles Privacy of any wireless and wired communications can- not be assured. Third parties may unlawfully intercept information and private communications without your consent. For further information, refer to “Data Collec- tion & Privacy” in your Uconnect Radio Instruction Manual or “Onboard Diagnostic System (OBD II) Cyber- security”...
Page 285: In Case Of Emergency
IN CASE OF EMERGENCY NOTE: HAZARD WARNING FLASHERS WARNING! With extended use the Hazard Warning Flashers may wear down your battery. The Hazard Warning Flashers button is located on the ALWAYS obey traffic laws and pay attention to the instrument panel below the climate controls. road.
Page 286 IN CASE OF EMERGENCY • SiriusXM Guardian™ Customer Care – In-vehicle WARNING! WARNING! support for SiriusXM Guardian™. • Vehicle Customer Care – Total support for all other • ALWAYS obey traffic laws and pay attention to the If anyone in the vehicle could be in danger (e.g., vehicle issues.
Page 287: Jacking And Tire Changing
IN CASE OF EMERGENCY SOS Call System Limitations • The SOS Call system software and/or hardware are from placing an emergency call. An operable LTE Vehicles sold in Mexico DO NOT have SOS Call system damaged during a crash (voice/data) or 4G (data) network connection and a GPS signal is required for the SOS Call system to •...
Page 288: Preparations For Jacking
IN CASE OF EMERGENCY To remove, proceed as follows: WARNING! 1. Fold up the right rear seat. • Never start or run the engine while the vehicle is 2. Remove the jack and tools by turning the wing bolt on a jack. counterclockwise, remove the wing bolt and then lift •...
Page 289: Spare Tire Removal
IN CASE OF EMERGENCY NOTE: 4. Remove tool kit and assemble tools. WARNING! If the tailgate is lowered, the jack extension with hook can be added to this assembly to enable lowering of the After using the jack and tools, always reinstall them in spare tire without having to raise the tailgate.
Page 290: Jacking Instructions
IN CASE OF EMERGENCY 3. Rotate the lug wrench handle counterclockwise until the spare tire is on the ground with enough cable slack to allow you to pull it out from under the vehicle. CAUTION! The winch mechanism is designed for use with the jack wrench extension tool only.
Page 291 IN CASE OF EMERGENCY 1. Remove the spare tire, jack and tools from the WARNING! stored location. • Do not get under the vehicle when it is on a jack. If 2. Using the lug wrench, loosen the wheel nuts (but do you need to get under a raised vehicle, take it to a not remove) by turning them counterclockwise one service center where it can be raised on a lift.
Page 292: To Stow The Flat Or Spare
IN CASE OF EMERGENCY 5. Raise the vehicle by turning the jack screw clock- 11. After 25 miles (40 km), check the lug nut torque wise. Raise the vehicle only until the tire just clears with a torque wrench to ensure that all lug nuts are the ground surface and enough clearance is properly seated against the wheel.
Page 293: Reinstalling The Jack And Tools
IN CASE OF EMERGENCY 3. Attach the lug wrench to the extension tubes with the curved angle facing away from the vehicle. Insert the extension tubes through the access hole between the lower tailgate and the top of the fascia/ bumper and into the winch mechanism tube.
Page 294: Jump Starting
IN CASE OF EMERGENCY PREPARATIONS FOR JUMP START The battery in your vehicle is located in the right rear of WARNING! the engine compartment. After using the jack and tools, always reinstall them in the original carrier and location. While driving you may experience abrupt stopping, rapid acceleration or sharp turns.
Page 295: Jump Starting Procedure
IN CASE OF EMERGENCY See the following steps to prepare for jump starting: JUMP STARTING PROCEDURE 1. Apply the parking brake, shift the automatic trans- mission into PARK (P) (manual transmission in NEU- WARNING! TRAL) and place the ignition in OFF mode. Failure to follow this jump starting procedure could 2.
Page 296: Refueling In Emergency - If Equipped
IN CASE OF EMERGENCY Disconnecting The Jumper Cables REFUELING IN EMERGENCY – 1. Disconnect the negative (-) end of the jumper cable IF EQUIPPED from the engine ground of the vehicle with the dis- charged battery. The vehicle may be equipped with a refueling funnel. 2.
Page 297: If Your Engine Overheats
IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS 2. Insert funnel into same filler pipe opening as the WARNING! fuel nozzle. If the vehicle is overheating, it will need to be serviced You or others can be badly burned by hot engine cool- by an authorized dealer.
Page 298: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY Follow these steps to use the Manual Park Release: 4. Press and maintain firm pressure on the brake pedal. 1. Firmly apply the parking brake. 5. Pull the tether strap until the release lever locks into 2.
Page 299: Towing A Disabled Vehicle
IN CASE OF EMERGENCY NOTE: WARNING! CAUTION! • For vehicles with automatic transmission: Shifts • Fast spinning tires can be dangerous. Forces gener- Racing the engine or spinning the wheels may lead between DRIVE (D) and REVERSE (R) can only be ated by excessive wheel speeds may cause damage, to transmission overheating and failure.
Page 300: Four-Wheel Drive Models
IN CASE OF EMERGENCY transfer case is in NEUTRAL (N) and the transmission is Proper towing or lifting equipment is required to prevent CAUTION! in PARK (P) (for automatic transmissions) or in gear damage to your vehicle. Use only tow bars and other ( NOT in NEUTRAL, for manual transmissions) equipment designed for this purpose, following equip- Tow hooks are for emergency use only, to rescue a...
Page 301: Enhanced Accident Response System (Ears)
IN CASE OF EMERGENCY WARNING! • Do not use a chain for freeing a stuck vehicle. Chains may break, causing serious injury or death. • Stand clear of vehicles when pulling with tow hooks. Tow straps may become disengaged, caus- ing serious injury.
Page 302: Servicing And Maintenance
SERVICING AND MAINTENANCE NOTE: SCHEDULED SERVICING — GASOLINE On vehicles equipped with an instrument cluster dis- play, “Oil Change Required” will be displayed and a Under no circumstances should oil change intervals single chime will sound, indicating that an oil change is ENGINE exceed 10,000 miles (16,000 km), 12 months or necessary.
Page 303 SERVICING AND MAINTENANCE At Every Oil Change Interval As Indicated By Oil Change Indicator System: • Inspect engine air cleaner filter if using in dusty or off-road conditions, replace engine air cleaner filter if necessary. • Inspect all door latches for presence of grease, reapply if necessary. NOTE: Using white lithium grease, lubricate the door hinge joints twice a year to prevent premature wear.
Page 304 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Replace spark plugs – 3.6L Engine. ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km), whichever comes first. Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, police, delivery service (commercial...
Page 305: Scheduled Servicing - Diesel Engine
SERVICING AND MAINTENANCE such as frequent short-trips, trailer tow, extremely hot open the filter cap approximately six turns until the cap WARNING! or cold ambient temperatures will influence when the o-ring is visible and stop. Wait five minutes with the cap “Oil Change Required”...
Page 306 SERVICING AND MAINTENANCE At Every Oil Change Interval As Indicated By Oil Change Indicator System: • Inspect exhaust system. • Inspect engine air cleaner filter if using in dusty or off-road conditions, replace engine air cleaner filter if necessary. CAUTION! Failure to comply with Oil Change or Fuel Filter Drain and Replacement requirements (every oil change, not to exceed 10,000 miles) will result in premature engine wear.
Page 307 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Replace fuel filter and drain water from the fuel filter assembly. NOTE: In states that mandate fuel use of Biodiesel blends greater than 5% (B6-B20) [Example: Minnesota in summer months] oil changes and fuel filter replacements are required every 8,000 miles and should not exceed 6 months.
Page 308 SERVICING AND MAINTENANCE WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 309: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L GASOLINE ENGINE 1 — Power Distribution Center (Fuses) 6 — Engine Coolant Pressure Cap 2 — Battery 7 — Brake Fluid Reservoir 3 — Engine Oil Dipstick 8 — Engine Air Cleaner Filter 4 — Engine Oil Fill 9 —...
Page 310: 3.0L Diesel Engine
SERVICING AND MAINTENANCE 3.0L DIESEL ENGINE 1 — Battery 6 — Power Distribution Center (Fuses) 2 — Engine Oil Fill 7 — Power Steering Reservoir Cap 3 — Coolant Pressure Reservoir 8 — Engine Oil Dipstick 4 — Brake Fluid Reservoir Cap 9 —...
Page 311: Checking Oil Level
SERVICING AND MAINTENANCE CHECKING OIL LEVEL fluid reservoir, take some washer fluid and apply it to a WARNING! cloth or towel and wipe clean the wiper blades; this will To ensure proper engine lubrication, the engine oil must help blade performance. •...
Page 312: Pressure Washing
SERVICING AND MAINTENANCE Synthetic Engine Oils CAUTION! WARNING! Your engine was designed for synthetic engine oils, only • If the negative battery cables are not isolated prop- You can be badly injured working on or around a use synthetic API approved engine oils. erly it can cause a potential power spike or surge motor vehicle.
Page 313: Engine Air Cleaner Filter
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and ENGINE AIR CLEANER FILTER Replacement — Gasoline Engine For the proper maintenance intervals see page 300 for gas engines or page 303 for diesel engines. Follow the recommended maintenance intervals as shown in the Maintenance Schedule in this section.
Page 314: Draining Fuel/Water Separator Filter - Diesel Engine
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and DRAINING FUEL/WATER Replacement — Diesel Engine SEPARATOR FILTER — DIESEL Follow the recommended maintenance intervals as ENGINE shown in the Maintenance Schedule in this section. The fuel/water separator housing is located inside the Engine Air Cleaner Filter Removal left frame rail in front of the fuel tank.
Page 315: Fuel Filter Replacement - Diesel Engine
SERVICING AND MAINTENANCE NOTE: If water is detected in the water separator while the engine is running, or while the ignition switch is in the Care should be taken in disposing of used fluids from ON position, the Water In Fuel Indicator Light will illumi- your vehicle.
Page 316: Priming If The Engine Has Run Out Of Fuel - Diesel Engine
SERVICING AND MAINTENANCE NOTE: 6. Wipe clean the underside of the filter housing to 10. Lubricate o-ring on the cap with clean engine oil. prevent contamination from entering fuel system The engine may run rough until the air is forced from all 11.
Page 317: Intervention Regeneration Strategy - Message Process Flow
SERVICING AND MAINTENANCE INTERVENTION REGENERATION ACCESSORY DRIVE BELT STRATEGY — MESSAGE PROCESS INSPECTION FLOW WARNING! This engine meets all required diesel engine emissions standards. To achieve these emissions standards, your • Do not attempt to inspect an accessory drive belt vehicle is equipped with a state-of-the-art engine and with vehicle running.
Page 318: Air Conditioner Maintenance
SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling AIR CONDITIONER MAINTENANCE R-1234yf For best possible performance, your air conditioner should be checked and serviced by an authorized R-1234yf Air Conditioning Refrigerant is a Hydrofluo- dealer at the start of each warm season. This service roolefin (HFO) that is endorsed by the Environmental should include cleaning of the condenser fins and a Protection Agency and is an ozone-friendly substance...
Page 319: Body Lubrication
SERVICING AND MAINTENANCE The external lock cylinders should be lubricated twice a year, preferably in the Autumn and Spring. Apply a small amount of a high quality lubricant, such as Mopar® Lock Cylinder Lubricant, directly into the lock cylinder. WINDSHIELD WIPER BLADES Clean the rubber edges of the wiper blades and the windshield periodically with a sponge or soft cloth and a mild nonabrasive cleaner.
Page 320: Exhaust System
SERVICING AND MAINTENANCE Wiper Blade Removal/Installation EXHAUST SYSTEM The best protection against carbon monoxide entry into CAUTION! the vehicle body is a properly maintained engine exhaust system. Do not allow the wiper arm to spring back against the If you notice a change in the sound of the exhaust sys- glass without the wiper blade in place or the glass tem, or if the exhaust fumes can be detected inside the may be damaged.
Page 321: Cooling System
SERVICING AND MAINTENANCE Coolant Checks To minimize the possibility of catalytic converter CAUTION! damage: Check the engine coolant (antifreeze) protection every • • Do not interrupt the ignition when the transmission The catalytic converter requires the use of 12 months (before the onset of freezing weather, where is in gear and the vehicle is in motion.
Page 322 SERVICING AND MAINTENANCE Selection Of Coolant • coolant (antifreeze) can be used up to 10 years or Some vehicles require special tools to add coolant 150,000 miles (240,000 km) before replacement. To properly. Failure to fill these systems properly could For further information page 361.
Page 323: Charge Air Cooler - Inter-Cooler (Diesel Engine)
SERVICING AND MAINTENANCE Disposal Of Used Coolant Cooling System Notes CHARGE AIR COOLER — INTER-COOLER (DIESEL ENGINE) Used ethylene glycol-based coolant (antifreeze) OAT or NOTE: HOAT, is a regulated substance requiring proper dis- When the vehicle is stopped after a few miles/ The charge air cooler is positioned in front of the radia- posal.
Page 324: Front/Rear Axle Fluid
SERVICING AND MAINTENANCE Fluid Level Check — Brake Master TRANSFER CASE WARNING! Cylinder Fluid Level Check • Overfilling the brake fluid reservoir can result in The fluid level of the master cylinder should be checked spilling brake fluid on hot engine parts, causing The fluid level should be to the bottom edge of the fill whenever the vehicle is serviced, or immediately if the the brake fluid to catch fire.
Page 325: Manual Transmission - If Equipped
SERVICING AND MAINTENANCE Fluid And Filter Changes MANUAL TRANSMISSION — CAUTION! IF EQUIPPED Under normal operating conditions, the fluid installed at Do not use chemical flushes in your transmission as the factory will provide satisfactory lubrication for the the chemicals can damage your transmission compo- Fluid Level Check life of the vehicle.
Page 326: Fuses
SERVICING AND MAINTENANCE FUSES General Information WARNING! • When replacing a blown fuse, always use an appro- priate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload.
Page 327 SERVICING AND MAINTENANCE Power Distribution Center Location — Gas Engine...
Page 328 SERVICING AND MAINTENANCE Power Distribution Center Location — Diesel Engine Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare* 40 Amp Green – Starter – 5 Amp Tan Intelligent Battery Sensor (IBS)
Page 329 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 20 Amp Yellow Fuel Pump MTR/FPCM – 5 Amp Tan Security Gateway – – Spare* – – Spare* – 15 Amp Blue Trans Control Module TCM-8HP CYGNUS –...
Page 330 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 40 Amp Green – Central Body Controller (CBC) 3-POWER LOCKS 40 Amp Green – Central Body Controller (CBC) 4-EXTERIOR LIGHTS #2 – – Spare* – 10 Amp Red DIAGNOSTIC PORT Heating Ventilation Air Conditioning Mod (HVAC CTRL MOD)/Steering –...
Page 331 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 10 Amp Red HD ACC* Humidity Light Rain Sensor (HLRS)/Inverter 400W Wake Up/USB/ – 10 Amp Red InSide RearView Mirror (ISRVM)/Compass Module (CSGM)/DTV – 20 Amp Yellow Cigar Lighter –...
Page 332 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare* – 20 Amp Yellow ECM (GAS)/PCM (DSL) – 10 Amp Red Heated Mirrors – – Spare* – 20 Amp Yellow SMART BAR CTRL MOD – 15 Amp Blue Powertrain Control Module (PCM)/Solenoid 1 2 Block Shift 30 Amp Pink...
Page 333: Bulb Replacement
SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped F100 30 Amp Pink – ESC-ECU & VALVES F101 30 Amp Pink – Drivetrain Control Module (DTCM) F102 – 15 Amp Blue DUAL USB PORT F103 – 15 Amp Blue HD ACCY #3* F104 –...
Page 334 SERVICING AND MAINTENANCE Interior Bulbs Bulb Name Bulb Number Rocker Switch Indicator Lamp (Rear Window Defogger) Soundbar Dome Lamp ** Bulbs only available from an authorized dealer. Exterior Bulbs Bulb Name Bulb Number Headlamps Premium Head Lamps LED – (Serviced at an authorized dealer) Sport Front Park/Turn Signal Lamps 7442NALL Premium Front Park/Turn Signal Lamps...
Page 335 SERVICING AND MAINTENANCE Bulb Replacement NOTE: CAUTION! See an authorized dealer for service. NOTE: Do not touch the new bulb with your fingers. Oil con- LED FRONT SIDE MARKER — IF EQUIPPED Lens fogging can occur under certain atmospheric con- tamination will severely shorten bulb life.
Page 336: Tires
SERVICING AND MAINTENANCE CENTER HIGH MOUNTED STOP LAMP 2. Pull the outboard side of the lamp rearward, far CAUTION! enough to unsnap the two receptacles on the out- (CHMSL) board side of the lamp housing, from the two plastic Do not touch the new bulb with your fingers. Oil con- The stop lamp is mounted on the tailgate.
Page 337 SERVICING AND MAINTENANCE Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on US design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European — Metric tire sizing is based on European design standards.
Page 338 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire, or 31 = Overall diameter in inches (in)
Page 339 SERVICING AND MAINTENANCE Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
Page 340 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure NOTE: Tire And Loading Information Placard Under a maximum loaded vehicle condition, gross axle NOTE: weight ratings (GAWRs) for the front and rear axles must not be exceeded. The proper cold tire inflation pressure is listed on the driver’s side B-pillar or the rear edge of the driver's side For further information on GAWRs, vehicle loading, and door.
Page 341: Tires - General Information
SERVICING AND MAINTENANCE NOTE: Safety (4) The resulting figure equals the available amount of cargo and luggage • If your vehicle will be towing a trailer, load from your WARNING! trailer will be transferred to your vehicle. The follow- load capacity. For example, if “XXX” ing table shows examples on how to calculate total •...
Page 342 SERVICING AND MAINTENANCE Radial Ply Tires Tread Wear Check tire pressures more often if subject to a wide range of outdoor temperatures, as tire pressures vary Improper cold tire inflation pressures can cause abnor- with temperature changes. mal wear patterns and reduced tread life, resulting in WARNING! the need for earlier tire replacement.
Page 343 SERVICING AND MAINTENANCE • replaced immediately. A Run Flat tire is not repairable. Performance tires, tires with a speed rating of V or When a Run Flat tire is changed after being driven higher, and Summer tires typically have a reduced under a Run Flat mode 14 psi (96 kPa) condition, tread life.
Page 344: Tire Types
SERVICING AND MAINTENANCE It is recommended to replace the two front tires or two CAUTION! WARNING! rear tires as a pair. Replacing just one tire can seriously affect your vehicle’s handling. If you ever replace a Replacing original tires with tires of a different size Do not use Summer tires in snow/ice conditions.
Page 345: Spare Tires - If Equipped
SERVICING AND MAINTENANCE Limited Use Spare — If Equipped SPARE TIRES — IF EQUIPPED Since this tire has limited tread life, the original equip- ment tire should be repaired (or replaced) and rein- The limited use spare tire is for temporary emergency NOTE: stalled on your vehicle at the first opportunity.
Page 346: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE WHEEL AND WHEEL TRIM CARE CAUTION! All wheels and wheel trim, especially aluminum and Do not use scouring pads, steel wool, a bristle brush, chrome plated wheels, should be cleaned regularly metal polishes, or oven cleaner. These products may using mild (neutral Ph) soap and water to maintain their damage the wheel's protective finish.
Page 347: Snow Traction Devices
SERVICING AND MAINTENANCE SNOW TRACTION DEVICES Use of traction devices require sufficient tire-to-body clearance. Due to limited clearance, the following snow traction devices are recommended. Follow these recommendations to guard against damage: • Snow traction device must be of proper size for the tire, as recommended by the snow traction device manufacturer. •...
Page 348: Tire Rotation Recommendations
SERVICING AND MAINTENANCE TIRE ROTATION course. For example, a tire graded CAUTION! 150 would wear one and one-half RECOMMENDATIONS Proper operation of four-wheel drive vehicles depends times as well on the government The tires on the front and rear of your vehicle operate on tires of equal size, type, and circumference on course as a tire graded 100.
Page 349: Temperature Grades
SERVICING AND MAINTENANCE 109. Grades B and A represent higher WARNING! WARNING! levels of performance on the labora- • Vehicles with the Stop/Start system will be The traction grade assigned to this tory test wheel, than the minimum equipped with two batteries. Both the main and tire is based on straight-ahead brak- required by law.
Page 350: Bodywork
SERVICING AND MAINTENANCE BODYWORK BODY AND UNDERBODY MAINTENANCE PROTECTION FROM ATMOSPHERIC Cleaning Headlights AGENTS Your vehicle is equipped with plastic headlights and fog Vehicle body care requirements vary according to geo- lights that are lighter and less susceptible to stone graphic locations and usage.
Page 351 SERVICING AND MAINTENANCE Appearance Care For Fabric Top Models • Avoid using abrasive compounds and power buffing CAUTION! that may diminish the gloss or thin out the paint To maintain the appearance of your vehicle's interior finish. Failure to follow these cautions may cause interior trim and top, follow these precautions: water damage, stains, or mildew of the top material: •...
Page 352: Interiors
Only operate the vehicle when the year of your vehicle. carpet is securely attached by the grommets so it can- dow, not up and down. Mopar® Jeep® Soft Glass • If the vehicle carpet has been removed and...
Page 353 SERVICING AND MAINTENANCE Rear Carpet 2. Pull the carpet out from the front to the rear. 4. Under the back of the front seat, open the carpet split and then pull out the rear edge and slide the 1. Remove the grommets under the front seat (one left carpet to the front (do not remove the harness).
Page 354: Seats And Fabric Parts
SERVICING AND MAINTENANCE Seat Belt Maintenance 6. Lift carpet off of the rear retainers (one left and one PLASTIC AND COATED PARTS right). Use Mopar® Total Clean to clean vinyl upholstery. CAUTION! CAUTION! Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners.
Page 355: Leather Surfaces
SERVICING AND MAINTENANCE LEATHER SURFACES GLASS SURFACES Mopar® Total Clean is specifically recommended for All glass surfaces should be cleaned on a regular basis leather upholstery. with Mopar® Glass Cleaner, or any commercial household-type glass cleaner. Never use an abrasive Your leather upholstery can be best preserved by regu- type cleaner.
Page 356: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) In the event power assist is lost for any reason (i.e., repeated brake applications with the engine off) the brakes will still function. However, the effort required to The VIN is found on the left front corner of the A-pillar, brake the vehicle will be much greater than that visible from outside of the vehicle through the required with the power system operating.
Page 357: Fuel Requirements - Gasoline Engine
TECHNICAL SPECIFICATIONS After 25 miles (40 km), check the lug nut/bolt torque to octane rating of 87 as specified by the (R+M)/ GASOLINE/OXYGENATE BLENDS be sure that all the lug nuts/bolts are properly seated 2 method. The use of higher octane premium gasoline Some fuel suppliers blend unleaded gasoline with oxy- against the wheel.
Page 358: Cng And Lp Fuel System Modifications
TECHNICAL SPECIFICATIONS CNG AND LP FUEL SYSTEM FUEL SYSTEM CAUTIONS FUEL REQUIREMENTS – DIESEL ENGINE MODIFICATIONS CAUTION! Modifications that allow the engine to run on Com- CAUTION! pressed Natural Gas (CNG) or Liquid Propane (LP) may Follow these guidelines to maintain your vehicle’s •...
Page 359: Diesel Fuel Specifications
TECHNICAL SPECIFICATIONS NOTE: WARNING! • If you accidentally fill the fuel tank with gasoline or Do not use alcohol or gasoline as a fuel blending DEF on your diesel vehicle, do not start the engine. agent. They can be unstable under certain conditions Damage to the engine and fuel system could occur.
Page 360 TECHNICAL SPECIFICATIONS % Biodiesel Customer View Pump Required Label 0–5% (B5) No Label Required Acceptable For Use 6–20% (B6–B20) DO NOT USE except in states requiring B20 sale (e.g. Minnesota in Summer months) NOTE: Refer to Fuel Requirements - Die- sel Engine for further informa- tion.
Page 361 TECHNICAL SPECIFICATIONS % Biodiesel Customer View Pump Required Label >21% (B21) DO NOT USE Biodiesel Fuel Properties — Low Fuel In Oil Dilution — Must Adhere To • Petrodiesel fuel meeting ASTM specification D-975 and biodiesel fuel (B100) meeting ASTM Ambient Temperatures Required Oil Change Interval specification D-6751...
Page 362: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 22.0 Gallons 83.0 Liters Engine Oil with Filter 3.6L Gasoline Engine 5.0 Quarts 4.7 Liters Cooling System * 3.6L Gasoline Engine 13.0 Quarts 12.3 Liters *Includes coolant recovery bottle filled to MAX level. Metric Fuel (Approximate) 3.0L Diesel Engine...
Page 363: Engine Fluids And Lubricants
TECHNICAL SPECIFICATIONS ENGINE FLUIDS AND LUBRICANTS GASOLINE ENGINE Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile Engine Coolant (240,000 km) Formula OAT (Organic Additive Technology) or equivalent meeting the requirements of the manufacturer Material Standard MS.90032. We recommend using Mopar®...
Page 364 TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® Fuel Filter. Must meet 3 micron rating. Using a fuel fil- ter that does not meet the manufacturer filtration and water separating require- Fuel Filters — 3.0L Diesel Engine ments can severely impact fuel system life and reliability.
Page 365: Chassis Fluids And Lubricants
TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid or equivalent. Fail- Automatic Transmission — If Equipped ure to use the correct fluid may affect the function or performance of your transmission.
Page 366: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FCA CANADA INC. CUSTOMER Warranty service must be done by an authorized dealer. We strongly recommend that you take the vehicle to an CENTER authorized dealer. They know your vehicle the best, and FOR YOUR VEHICLE are most concerned that you get prompt and high qual- P.O.
Page 367: Warranty Information
CUSTOMER ASSISTANCE MOPAR® PARTS Any hearing or speech impaired customer, who has Mopar Vehicle Protection Plans offer valuable protec- access to a TDD or a conventional teletypewriter (TTY) tion against repair costs after your vehicle warranties in the United States, can communicate with FCA US LLC have expired.
Page 368: In Canada
CUSTOMER ASSISTANCE To contact NHTSA, you may call the Ordering and Accessing Owner’s GENERAL INFORMATION Vehicle Safety Hotline toll free at Information The following regulatory statement applies to all Radio 1-888-327-4236 (TTY: Frequency (RF) devices equipped in this vehicle: To order the following manuals, you may use either the 1-800-424-9153);...
Page 369 INDEX Security Alarm ....21 Alterations/Modifications About Your Brakes....354 Battery .
Page 370 INDEX Carbon Monoxide Warning ... . .281 Console ..... .59 Oil (Engine) .
Page 371 INDEX In Case Of ....283 Freedom Panels ....83 SOS Emergency Call .
Page 372 Hood Prop .....92 Jeep Wireless Speaker ... . .62, 65 AdBlue UREA Injection System Failure .
Page 373 INDEX Engine Check Malfunction Indicator ..115 Loading Vehicle ....165 Vanity .....45 Engine Coolant Temperature .
Page 374 INDEX Owner's Manual ....366 Radio Remote Starting System ... .19, 20 Outside Rearview Mirrors ....45 Presets .
Page 375 INDEX Extender ....258 Transfer Case, Shifting Out Of Transfer Power ....113, 142 Front Seat .
Page 376 INDEX High Speed ....340 Traction Control ....245 Bluetooth Communication Link .
Page 377 INDEX Windshield Wiper Blades ... . .317 Windshield Wipers ....52 Vanity Mirrors....45 Wipers Blade Replacement .
Page 379 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Jeep brand vehicle and to provide a convenient ®...
Page 380 ©2023 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une Fourth Edition marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep GLADIATOR 2022 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jeep GLADIATOR 2022

Summary of Contents for Jeep GLADIATOR 2022
