Danfoss VLT FC 102 Operating Manual page 92

VLT HVAC Drive FC 102
Operating Guide
Type designation
Power losses and efficiency
Estimated power loss at rated maximum load [W]
Efficiency
(2)
The typical power loss is at normal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions).
1
Values are based on a typical motor efficiency. Lower efficiency motors also add to the power loss in the drive and conversely. If the switching fre-
quency is raised from nominal, the power losses may rise significantly. LCP and typical control card power consumptions are included. Further op-
tions and customer load may add up to 30 W to the losses. (Though typically only 4 W extra for a fully loaded control card or options for slot A or slot
B, each). Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be allowed for (±5%).
Measured using 5m (16.4 ft) shielded motor cables at rated load and rated frequency
2
Table 51: Mains Supply 3x525–600 V AC - Normal Overload 110% for 1 Minute, P37K–P90K
Type designation
Typical shaft output [kW]
IP20/UL Open Type
IP21/UL Type 1
IP55/UL Type 12
IP66/UL Type 4X
Output current
Continuous (3x525–550 V) [A]
Intermittent (3x525–550 V) [A]
Continuous (3x525–600 V) [A]
Intermittent (3x525–600 V) [A]
Continuous kVA (525 V AC) [kVA]
Continuous kVA (575 V AC) [kVA]
Maximum input current
Continuous (3x525–600 V) [A]
Intermittent (3x525–600 V) [A]
SCCR
With mains disconnect [kA
rms
Without mains disconnect [kA
92 | Danfoss A/S © 2023.09
(1)
]
]
rms
P11K P15K P18K
300 400 475
0.97 0.97 0.97
P37K P45K P55K
37 45 55
B4 C3 C3
C1 C1 C1
C1 C1 C1
C1 C1 C1
54 65 87
59 72 96
52 62 83
57 68 91
51.4 61.9 82.9
51.8 61.7 82.7
49 59 78.9
54 65 87
65 kA 65 kA 65 kA
100 kA 100 kA 100 kA
AQ267037536117en-000101 / 130R0083
Specifications
P22K P30K
525 700
0.97 0.97
P75K P90K
75 90
C4 C4
C2 C2
C2 C2
C2 C2
105 137
116 151
100 131
110 144
100 130.5
99.6 130.5
95.3 124.3
105 137
65 kA 65 kA
100 kA 100 kA
