VLT HVAC Drive FC 102
Operating Guide
Type designation
Power losses and efficiency
Estimated power loss at rated maximum load [W]
Efficiency
(2)
For type of fuse see 8.10.2 CE Compliance
1
2 The typical power loss is at normal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions).
Values are based on a typical motor efficiency. Lower efficiency motors also add to the power loss in the drive and conversely. If the switching fre-
quency is raised from nominal, the power losses may rise significantly. LCP and typical control card power consumptions are included. Further op-
tions and customer load may add up to 30 W to the losses. (Though typically only 4 W extra for a fully loaded control card or options for slot A or slot
B, each). Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be allowed for (±5%).

8.5 Mains Supply

Supply terminals
Supply voltage
(1)(2)(3)
Supply voltage
(1)(2)(4)
Supply voltage
(1)(2)
Supply frequency
Maximum imbalance temporary between mains phases
True power factor (λ)
Displacement power factor (cos Φ)
Switching on the input supply L1, L2, L3 (power-ups) ≤7.5 kW
Switching on input supply L1, L2, L3 (power-ups) 11–90 kW
Environment according to EN60664-1
Mains voltage low/mains dropout: During low mains voltage or a mains dropout, the drive continues until the DC-link voltage drops below the
1
minimum stop level, which corresponds typically to 15% below the drive's lowest rated supply voltage. Power-up and full torque cannot be expec-
ted at mains voltage lower than 10% below the drive's lowest rated supply voltage.
The unit is suitable for use on a circuit capable of delivering not more than 100000 RMS symmetrical Amperes, 240/500/600/690 V maximum,
2
depending upon drive power and voltage rating.
If type code position 23 = 6: UL 61800-5-1, the supply voltage is 3x115Y/200–139Y/240 V.
3
If type code position 23 = 6: UL 61800-5-1, the supply voltage is 3x220Y/380–277Y/480 V.
4

8.6 Motor Output and Motor Data

8.6.1 Motor Output (U, V, W)

Output voltage
Output frequency (1.1–90 kW)
Switching on output
Ramp times
From software version 3.92 the output frequency of the frequency converter is limited to 590 Hz. Contact local Danfoss partner for further informa-
1
tion.

8.6.2 Torque Characteristics

Starting torque (constant torque)
Starting torque
Overload torque (constant torque)
Starting torque (variable torque)
Overload torque (variable torque)
96 | Danfoss A/S © 2023.09
(2)
and the Fuses and Circuit Breakers section.
P37K P45K P55K
740 900 1100
0.98 0.98 0.98
Overvoltage category III/pollution degree 2
AQ267037536117en-000101 / 130R0083
Specifications
P75K P90K
1500 1800
0.98 0.98
L1, L2, L3
200–240 V ±10%
380–480 V/500–600 V ±10%
525–600 V ±10%
47.5–63 Hz
3.0% of rated supply voltage
≥0.9 nominal at rated load
Near unity (>0.98)
Maximum 2 times per minute
Maximum 1 time per minute
0–100% of supply voltage
0–590 Hz
(1)
Unlimited
1–3600 s
Maximum 110% for 60 s
(1)
Maximum 135% up to 0.5 s
(1)
Maximum 110% for 60 s
(1)
Maximum 110% for 60 s
(1)
Maximum 110% for 60 s
