The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB ground connection is not galvanically isolated from protective earth. Use only an isolated laptop as PC connection to the
USB connector on the drive.

8.9.11 Relay Outputs

Programmable relay outputs
Relay 01 terminal number
Maximum terminal load (AC-1)
load)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
load)
Maximum terminal load (DC-13)
Relay 02 terminal number
Maximum terminal load (AC-1)
Maximum terminal load (AC-15) on 4–5 (NO) (inductive load @
cosφ 0.4)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
cosφ 0.4)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Minimum terminal load on 1–3 (NC), 1–2 (NO), 4–6 (NC), 4–5 (NO)
Environment according to EN 60664-1
IEC 60947 parts 4 and 5. The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV)
1
2 Overvoltage Category II
UL applications 300 V AC 2 A.
3

8.9.12 Control Card Performance

Scan interval

8.9.13 Control Characteristics

Resolution of output frequency at 0–590 Hz
Repeat accuracy of precise start/stop (terminals 18, 19)
System response time (terminals 18, 19, 27, 29, 32, 33)
Speed control range (open loop)
Speed control range (closed loop)
Speed accuracy (open loop)
Speed accuracy (closed loop), depending on resolution of feed-
back device
Torque control accuracy (speed feedback)
All control characteristics are based on a 4-pole asynchronous motor.
Danfoss A/S © 2023.09
on 1–3 (NC), 1–2 (NO) (resistive
(1)
(inductive load @ cosφ 0.4)
(1)
on 1–2 (NO), 1–3 (NC) (resistive
(1)
(inductive load)
(1)
on 4–5 (NO) (resistive load)
(1)
on 4–5 (NO) (resistive load)
(1)
on 4–5 (NO) (inductive load)
(1)
on 4–6 (NC) (resistive load)
(1)
on 4–6 (NC) (inductive load @
(1)
on 4–6 (NC) (resistive load)
(1)
on 4–6 (NC) (inductive load)
(1)
(2)(3)
Specifications
1–3 (break), 1–2 (make)
4–6 (break), 4–5 (make)
24 V DC 1 mA, 24 V AC 20 mA
Overvoltage category III/pollution degree 2
1:100 of synchronous speed
1:1000 of synchronous speed
30–4000 RPM: Error ±8 RPM
0–6000 RPM: Error ±0.15 RPM
Maximum error ±5% of rated torque
AQ267037536117en-000101 / 130R0083 | 101
2
240 V AC, 2 A
240 V AC, 0.2 A
60 V DC, 1 A
24 V DC, 0.1 A
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
1 ms
±0.003 Hz
≤±0.1 ms
≤2 ms
