Danfoss VLT FC 102 Operating Manual page 103

VLT HVAC Drive FC 102
Operating Guide
Enclosure Power [kW (hp)]
C2 37 (50)
45 (60)
C3 22 (30)
30 (40)
C4 37 (50)
45 (60)
Table 57: 380–480 V, Enclosure Sizes A, B, and C
Enclosure Power [kW (hp)]
A2 1.1–3.0 (1.5–4.0)
4.0 (5.0)
A3 5.5–7.5 (7.5–10.0)
A4 1.1–3.0 (1.5–4.0)
4.0 (5.0)
A5 1.1–3.0 (1.5–4.0)
4.0–7.5 (5.0–10.0)
B1 11–18 (15–24)
B2 22 (30)
30 (40)
B3 11–18 (15–24)
B4 22 (30)
30 (40)
37 (50)
C1 37 (50)
45 (60)
55 (75)
C2 75 (100)
90 (125)
C3 45 (60)
55 (75)
C4 75 (100)
90 (125)
Danfoss A/S © 2023.09
Recommended Recommended
fuse size maximum fuse
aR-160 aR-200
aR-200 aR-250
gG-80 gG-150
aR-125 aR-160
aR-160 aR-200
aR-200 aR-250
Recommended Recommended
fuse size maximum fuse
gG-10 gG-25
gG-16
gG-16 gG-32
gG-10 gG-32
gG-16
gG-10 gG-32
gG-16
gG-40 gG-80
gG-50 gG-100
gG-63
gG-40 gG-63
gG-50 gG-125
gG-63
gG-80
gG-80 gG-160
gG-100
gG-160
aR-200 aR-250
aR-250
gG-100 gG-150
gG-160 gG-160
aR-200 aR-250
aR-250
Recommended circuit break-
er Moeller
NZMB2-A250
NZMB2-A200
NZMB2-A250
Recommended circuit break-
er Moeller
PKZM0-25
PKZM0-25
PKZM0-25
PKZM0-25
PKZM4-63
NZMB1-A100
PKZM4-50
NZMB1-A100
NZMB2-A200
NZMB2-A250
NZMB2-A200
NZMB2-A250
AQ267037536117en-000101 / 130R0083 | 103
Specifications
Maximum trip
level [A]
250
150
250
Maximum trip
level [A]
25
25
25
25
63
100
50
100
160
250
150
250
