VLT HVAC Drive FC 102
Operating Guide
Table 63: Recommended Maximum Fuse, 200–240 V, Enclosure Sizes A, B, and C
Power SIBA Type RK1
[kW (hp)]
1.1 (1.5) 5017906-010
1.5 (2.0) 5017906-016
2.2 (3.0) 5017906-020
3.0 (4.0) 5017906-025
3.7 (5.0) 5012406-032
5.5–7.5 5014006-050
(7.5–10)
11 (15) 5014006-063
15 (20) 5014006-080
18.5–22 2028220-125
(25–30)
30 (40) 2028220-150
37 (50) 2028220-200
45 (60) 2028220-250
A6KR-fuses from Ferraz Shawmut may substitute A2KR for 240 V drives.
1
2 FWH-fuses from Bussmann may substitute FWX for 240 V drives.
A50X-fuses from Ferraz Shawmut may substitute A25X for 240 V drives.
3
Table 64: Recommended Maximum Fuse, 380–480 V, Enclosure Sizes A, B, and C
Power [kW (hp)] Bussmann Type
RK1
1.1 (1.5) KTS-R-6
1.5–2.2 (2.0–3.0) KTS-R-10
3.0 (4.0) KTS-R-15
4.0 (5.0) KTS-R-20
5.5 (7.5) KTS-R-25
7.5 (10) KTS-R-30
11–15 (15–20) KTS-R-40
18.5 (25) KTS-R-50
22 (30) KTS-R-60
30 (40) KTS-R-80
37 (50) KTS-R-100
45 (60) KTS-R-125
Danfoss A/S © 2023.09
Littelfuse Ferraz Ferraz Shaw-
Type RK1 Shawmut mut Type
Type CC
KLN-R-10 ATM-R-10
KLN-R-15 ATM-R-15
KLN-R-20 ATM-R-20
KLN-R-25 ATM-R-25
KLN-R-30 ATM-R-30
KLN-R-50 –
KLN-R-60 –
KLN-R-80 –
KLN-R-125 – A2K-125-R
KLN-R-150 – A2K-150-R
KLN-R-200 – A2K-200-R
KLN-R-250 – A2K-250-R
Bussmann
Type J
JKS-6
JKS-10
JKS-15
JKS-20
JKS-25
JKS-30
JKS-40
JKS-50
JKS-60
JKS-80
JKS-100
JKS-125
Bussmann
Type
RK1 JFHR2
(1) (2)
A2K-10-R FWX-10
A2K-15-R FWX-15
A2K-20-R FWX-20
A2K-25-R FWX-25
A2K-30-R FWX-30
A2K-50-R FWX-50
A2K-60-R FWX-60
A2K-80-R FWX-80
FWX-125
FWX-150
FWX-200
FWX-250
Bussmann Bussmann
Type T Type CC
JJS-6 FNQ-R-6
JJS-10 FNQ-R-10
JJS-15 FNQ-R-15
JJS-20 FNQ-R-20
JJS-25 FNQ-R-25
JJS-30 FNQ-R-30
JJS-40 –
JJS-50 –
JJS-60 –
JJS-80 –
JJS-100 –
JJS-125 –
Specifications
Littelfuse Ferraz
JFHR2 Shawmut
JFHR2
(3)
– –
– –
– –
– –
– –
– –
– –
– –
– –
L25S-150 A25X-150
L25S-200 A25X-200
L25S-250 A25X-250
Bussmann Bussmann
Type CC Type CC
KTK-R-6 LP-CC-6
KTK-R-10 LP-CC-10
KTK-R-15 LP-CC-15
KTK-R-20 LP-CC-20
KTK-R-25 LP-CC-25
KTK-R-30 LP-CC-30
–
–
–
–
–
–
AQ267037536117en-000101 / 130R0083 | 107
Ferraz
Shawmut
J
HSJ-10
HSJ-15
HSJ-20
HSJ-25
HSJ-30
HSJ-50
HSJ-60
HSJ-80
HSJ-125
HSJ-150
HSJ-200
HSJ-250
–
–
–
–
–
–
