8.10.4 UL Compliance (508C)

Table 62: Recommended Maximum Fuse, 200–240 V, Enclosure Sizes A, B, and C
Power [kW (hp)] Bussmann Type
RK1
1.1 (1.5) KTN-R-10
1.5 (2.0) KTN-R-15
2.2 (3.0) KTN-R-20
3.0 (4.0) KTN-R-25
3.7 (5.0) KTN-R-30
5.5–7.5 (7.5–10) KTN-R-50
11 (15) KTN-R-60
15 (20) KTN-R-80
18.5–22 (25–30) KTN-R-125
30 (40) KTN-R-150
37 (50) KTN-R-200
45 (60) KTN-R-250
KTS-fuses from Bussmann may substitute KTN for 240 V drives.
1
106 | Danfoss A/S © 2023.09
Class
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T
J/T
J/T
J/T
Bussmann
Type J
(1)
JKS-10
JKS-15
JKS-20
JKS-25
JKS-30
KS-50
JKS-60
JKS-80
JKS-125
JKS-150
JKS-200
JKS-250
Recommended
15 A
20 A
25 A
30 A
40 A
50 A
60 A
80 A
100 A
125 A
150 A
Bussmann Bussmann
Type T Type CC
JJN-10 FNQ-R-10
JJN-15 FNQ-R-15
JJN-20 FNQ-R-20
JJN-25 FNQ-R-25
JJN-30 FNQ-R-30
JJN-50 –
JJN-60 –
JJN-80 –
JJN-125 –
JJN-150 –
JJN-200 –
JJN-250 –
Specifications
Verified with
A5: class J, 30 A
A2: class J, 20 A
A5: class J, 30 A
A2: class J, 20 A
A5: class J, 30 A
A3: class J, 30 A
A5: class J, 30 A
A3: class J, 30 A
A5: class J, 30 A
B2: class J, 50 A
B1: class J, 50 A
B2: class J, 80 A
B2: class J, 80 A
C1: class J, 150 A
C1: class J, 150 A
C1: class J, 150 A
Bussmann Bussmann
Type CC Type CC
KTK-R-10 LP-CC-10
KTK-R-15 LP-CC-15
KTK-R-20 LP-CC-20
KTK-R-25 LP-CC-25
KTK-R-30 LP-CC-30
– –
– –
– –
– –
– –
– –
– –
AQ267037536117en-000101 / 130R0083
