Illustration 2: Exploded View Enclosure Types B and C, IP55 and IP66
1 Local control panel (LCP)
2 Cover
3 RS485 serial bus connector
4 Digital I/O and 24 V power supply
5 Analog I/O connector
6 Cable shield connector
7 USB connector
8 Serial bus terminal switch
9 Analog switches (A53), (A54)
10 Relay 1 (01, 02, 03)
Danfoss A/S © 2023.09
10
9
8
3
4
5
17
19
18
11
12
13
14
15
16
17
18
19
11
7
6
FAN MOUNTING
16
Relay 2 (04, 05, 06)
Lifting ring
Mounting slot
Grounding clamp (PE)
Cable shield connector
Brake terminal (-81, +82)
Load sharing terminal (DC bus) (-88, +89)
Motor output terminals 96 (U), 97 (V), 98 (W)
Mains input terminals 91 (L1), 92 (L2), (L3)
