Danfoss VLT FC 102 Operating Manual page 114

VLT HVAC Drive FC 102
Operating Guide
Enclosure size
Protection rating –
Height [mm (in)]
Height of mounting plate
Height with ground termination
plate for fieldbus cables
Distance between mounting holes
Width [mm (in)]
Width of mounting plate
Width of mounting plate with 1 C
option
Width of mounting plate with 2 C
options
Distance between mounting holes
Depth [mm (in)]
Depth without option A/B
With option A/B
Screw holes [mm (in)]
Maximum weight [kg (lb)]
Front cover tightening torque [Nm (in-lb)]
Plastic cover (low IP)
Metal cover (IP55/66)
See Illustration 34 and Illustration
1
114 | Danfoss A/S © 2023.09
C1
IP21/55/66(UL Type
1/12/4X)
A 680 (26.8)
(1)
A –
a 648 (25.5)
B 308 (12.1)
B 308 (12.1)
B 308 (12.1)
b 272 (10.7)
C 310 (12.2)
C 310 (12.2)
c 12.5 (0.49)
d ø19 (ø0.75)
e ø9 (ø0.35)
f 9.8 (0.39)
45 (99)
Click
2.2 (19.5)
35.
C2 C3
IP21/55/66(UL Type IP20(UL Open
1/12/4X) Type)
770 (30.3) 550 (21.7)
– 630 (24.8)
739 (29.1) 521 (20.5)
370 (14.6) 308 (12.1)
370 (14.6) 308 (12.1)
370 (14.6) 308 (12.1)
334 (13.1) 270 (10.6)
335 (13.2) 333 (13.1)
335 (13.2) 333 (13.1)
12.5 (0.49) –
ø19 (ø0.75) –
ø9 (ø0.35) 8.5 (0.33)
9.8 (0.39) 17 (0.67)
65 (143) 35 (77)
Click 2 (17.7)
2.2 (19.5) 2 (17.7)
AQ267037536117en-000101 / 130R0083
Specifications
C4
IP20(UL Open
Type)
660 (26)
800 (31.5)
631 (24.8)
370 (14.6)
370 (14.6)
370 (14.6)
330 (13)
333 (13.1)
333 (13.1)
–
–
8.5 (0.33)
17 (0.67)
50 (110)
2 (17.7)
2 (17.7)
