VLT HVAC Drive FC 102
Operating Guide
Enclosure Power [kW (hp)]
B2/B4 11 (15)
15 (20)
18 (24)
22 (30)
B4/C2 30 (40)
C2/C3 37 (50)
45 (60)
C2 55 (75)
75 (100)

8.10.3 UL Compliance (61800-5-1)

Table 60: Recommended Fuse, 200–240 V and 115Y/200–139Y/240, Enclosure Sizes A2, A3, A5, B1, B2, and C1
Power [kW (hp)]
1.1 (1.5)
1.5 (2.0)
2.2 (3.0)
3.0 (4.0)
3.7 (5.0)
5.5–7.5 (7.5–10)
11 (15)
15 (20)
18.5–22 (25–30)
30 (40)
Table 61: Recommended Fuse, 380–480 V and 220Y/380–277Y/480, Enclosure Sizes A2, A3, A5, B1, B2, and C1
Power [kW (hp)]
1.1 (1.5)
1.5–2.2 (2.0–3.0)
Danfoss A/S © 2023.09
Recommended fuse Recommended maxi-
size mum fuse
gG-25 gG-63
gG-32
gG-32
gG-40
gG-63 gG-80
gG-63 gG-100
gG-80 gG-125
gG-100 gG-160
gG-125
Class
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T/CC
J/T
J/T
J/T
Class
J/T/CC
J/T/CC
Recommended circuit
breaker Moeller
–
–
–
–
Recommended
10 A
15 A
20 A
25 A
30 A
50 A
60 A
80 A
125 A
150 A
Recommended
6 A
10 A
AQ267037536117en-000101 / 130R0083 | 105
Specifications
Maximum trip lev-
el [A]
–
–
–
–
Verified with
A2: class J, 20 A
A5: class J, 30 A
A2: class J, 20 A
A5: class J, 30 A
A2: class J, 20 A
A5: class J, 30 A
A3: class J, 30 A
A5: class J, 30 A
A3: class J, 30 A
A5: class J, 30 A
B1: class J, 60 A
B1: class J, 60 A
B2: class J, 80 A
C1: class J, 150 A
C1: class J, 150 A
Verified with
A2: class J, 10 A
A5: class J, 30 A
A2: class J, 20 A
