DESCRIPTION
The LTC 5562 is a versatile low power mixer optimized
®
for applications requiring very wide input bandwidth, low
distortion, and low LO leakage. This mixer can be used
for either upconverting or downconverting applications,
and provides a nominal conversion gain of 1dB. Demon-
stration circuit 2483A-A showcases the LTC5562 mixer
for upconverting applications while demonstration circuit
2483A-B is tuned for downconverting applications. The
differential inputs are optimized for use with 1:1 trans-
mission-line baluns, allowing very wideband impedance
matching. The LTC5562 uses a 3.3V supply for low power
consumption and an enable pin allows the part to be shut
ABSOLUTE MAXIMUM INPUT RATINGS
Supply Voltage (V , OUT
CC
Enable Input Voltage (EN) ................–0.3V to V
+ –
LO , LO Input Power (1GHz to 7GHz) .................10dBm
+ –
IN , IN Power (10MHz to 7GHz)..........................15dBm
LGND Voltage............................................... –0.3V to 1V
Operating Temperature Range (T

BOARD PHOTO

Figure 1. DC2483A-A
+ –
, OUT ) ..............................4V
+ 0.3V
CC
) ........ –40°C to 105°C
C
DEMO MANUAL
DC2483A-A/DC2483A-B
Wideband Low Power
down for further power savings. The total mixer current
is adjustable, allowing for even further power savings.
The standard match frequency ranges for each board are
outlined in the table below.
DEMO BOARD INPUT RANGE
DC2483A-A 30MHz to 3GHz 2.8GHz to 3.4GHz 3.3GHz to 3.7GHz
DC2483A-B 30MHz to 3GHz 0.4GHz to 1.4GHz 10MHz to 550MHz
Design files for this circuit board are available at
http://www.linear.com/demo/DC2483A-A
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Analog
Devices, Inc. All other trademarks are the property of their respective owners.
Junction Temperature (T
Storage Temperature Range .................. –65°C to 150°C
CAUTION: THIS PART IS SENSITIVE TO ELECTROSTATIC
DISCHARGE (ESD). OBSERVE PROPER ESD PRECAU-
TIONS WHEN HANDLING THE LTC5562.
Figure 2. DC2483A-B
LTC5562
Active Mixer
LO RANGE OUTPUT RANGE
) .................................... 150°C
J
