Chapter 5 Appendix; Specification - RGBlink mini-mx User Manual

Chapter 5 Appendix

5.1 Specification

Connectors Input
Output
Audio
Communication
Power
Performance Input Resolutions
Output Resolutions SMPTE
Video
Audio
Record/Storage
Supported Standards HDMI
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
HDMI 4K 4×HDMI-A
HDMI 2K 1×HDMI-A
USB (Stream) 1×USB-C
USB (Record) 1×USB-C
In 2×6.35mm XLR/6.35mm TRS Jack
1×6.35mm TRS Jack
Out 1×6.35mm TRS Jack
1×3.5mm mini-Jack
LAN 1×RJ45
1×USB-C
SMPTE 720p@50/60 |1080i@50 | 1080p@23.98/24.97/50/59.94/60
VESA 1024×768@60 | 1280×720@60 | 1280×768@60 | 1280×800@60 |
1280×1024@60 | 1360×768@60 |1366×768@60 | 1440×900@60 |
1600×1200@60 | 1680×1050@60 | 1920×1080@60 |
1920×1200@60 | 3840×2160@60 | 4096x2160@60
720p@50/60 | 1080p@24/25/30/50/60
VESA 1024×768@60 | 1280×720@60 | 1280×768@60 | 1280×1024@60 |
1360×768@60 | 1920×1080@60
Video Formats HDMI 2.0 | HDCP 2.2
Color Space RGB 8bit
Video Sampling 4:4:4 YUV
Video Latency <4 frames
Line In Delay up to 8 frames
Audio Format HDMI
USB
Record Formats MP4 | WAV
Disk Formats
FAT32( ≤ 32 GB) | exFAT(64GB~2T)
2.0
USB 3.0
H.265 ITU-T H.265/ ISO/IEC 23008-2
Linear PCM, 24 bits/48 kHz, 2 ch
Linear PCM, 16 bits/48 kHz, 2 ch
65
