RGBlink mini-mx User Manual page 15

❶
UVC
❷
USB-C
❸
Ethernet Port
❹
PROGRAM
❺
MUlTI-VIEW
❻
1~4 HDMI in
❼
Locking Hole
❽
USB-C Power Port
❾
Power Switch
❿
Headphone Output
⓫
6.35mm TRS Jack
⓬
Line-in
⓭
MIC in 2
⓮
MIC in 1
⓯
+48V DIP Switch
Warning：
Except condenser microphones that require phantom power, please Turn Off phantom power switch
when connecting other devices.
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
Recognized as USB webcam to connect computer or mobile phone for streaming or
video conference.
● Insert SSD or U disk for recording.
● Insert a U disk to import audio, video and graphic files.
● Use with USB-C cable provided to share network with mobile phone. (Refer to
Smartphone Tethering)
Achieve network connection and camera control connection for streaming, remote
control, upgrade and camera signal transmission.
PROGRAM output port. Default to output real-time scene, can set as Multi-view
Preview or Test Pattern.
MULTI-VIEW output port. Default as multi-view preview output, can set as Program
or HDMI 1~4.
Four HDMI input ports support 4K resolution and downward compatible with all
resolution.
Use with T-lock to fix the device.
PD protocol, 12V, 3A.
Rocker switch to power on or off device.
3.5mm mini-jack for listening each analog input and HDMI input.
Balanced XLR audio output jack.
Balanced 6.35mm XLR Jack to connect to mobile phone, computer or audio
console.
XLR/TRS NEUTRIK MIC in port.
XLR/TRS NEUTRIK MIC in port with 48V Phantom Power supported.
● 48V Phantom Power supported.
● Defaults to OFF.
