3.2 MENU

There is a 5.5" touch screen on operation board, through which most operations can be done.
Push MENU button in Main Interface and the LCD screen will quickly enter MENU.
As shown in the figure above the UI style on the touch screen is similar to current smart phone
operating interface.
The first-level menu is in icon. Users can quickly enter the corresponding function management
interface by tapping the corresponding icon.
8 functions are available in MENU, including EFFECTS, LAYOUT, PTZ, SCENE, CHROMA KEY,
AUDIO, OUTPUT and SETTING.

3.3 Editing Interface

Click PREVIEW Window on Main Interface
or tap icon to enter Editing Interface.
