3) Connect camera and computer to the switch.
4) Connect mini-mx and camera to the switch via Ethernet cables (It is recommended to use
RGBlink CAT6 cable with order code as 940-0001-00-11-0). Then use mini-mx for PTZ control.
Warning:
1. The computer IP, mini-mx IP and the tested IP must be in the same LAN.
2. It is suggested to use ping command to check IP addresses of four cameras one by one to ensure
normal communication.
3. ONLY VISCA via IP protocol is supported. Protocols including NDI PTZ/CGI/HTTP/Pelco-D/Pelco-P are
not supported.
5)
Tap HDMI 1/HDMI 2/HDMI 3/HDMI 4 to switch camera control interface.
Use Adjuster on the front panel or tap
adjustment can be achieved by clicking AUTO.
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
icon to adjust zoom and focus. Automatic
