Tips:
The recognized device is generally named as mini-mx-XXXX.

3.14.4 Pattern

Click Pattern to select T-Bar PVW Mode or CUT Mode.
mini-mx defaults to T-Bar Mode. Users can also switch to CUT Mode and then use Button 1~4 on
the operation board to switch 4 HDMI inputs. The Button 1~4 corresponds to 4 HDMI inputs.
For some important occasions, users might need to preview and preset the next scene to ensure
the accuracy and stability of the screen. mini-mx provides T-Bar PVW mode to allow switch after
editing and confirmation.
When PVW Mode is enabled, all operation could be checked on PVW window. Slide T-Bar to
switch between PVW and PGM. Switch time can be customized by sliding the time bar.
Warning:
Only PVW mode supports time setting. Switch time of CUT mode defaults to 0.5s.

3.14.5 Reset

Tap Reset to check current version of mini-mx and perform factory reset.
