Insert a U disk to the other USB 3.0 port labeled number 1 by USB 3.0 cable to perform recording.
mini-mx supports recording streaming media content to an external USB storage device, such as
U disk or SSD. The SSD storage can reach up to 2T, and the USB storage can support up to 64G.
The supported format is exFAT.
Warning:
1. For U disk, please use one with USB 3.0 port.
2. For SSD, please check if it needs extra power supply.
3. OTG cable only for file transfer cannot be used for streaming.
4. For dual-channel streaming, or use UVC output/recording simultaneously, the touch screen may get sluggish.
5. USB-C ports adopts USB 3.1 data transmission protocol.

2.5 Connecting Router

Connect router and mini-mx with CAT6 cable. Click MENU > SETTING > NETWORK >Turn off
DHCP to set IP address of mini-mx. When connecting mini-mx and the router, the IP address of
mini-mx must be in the same LAN as the router.

2.6 Plugging in Power

RGBlink mini-mx is packaged with a PD power adapter (power cable included) , check the power
