Connector
JPWR1
JPV1
JRK1
JSD1
JSFPLED1
JSLIM1, JSLIM2
JSTBY1
JTGLED2
JTPM1
LAN1/2, LAN3/4
LAN5/6
LAN7/8
P1_NVME0
SLOT6
UID
USB0/1, USB2/3
USB4/5
VGA
Description
24-pin ATX Power Connector (Required)
8-pin CPU Power Connector (Required)
Intel RAID Key Header
SATA DOM Power Connectors
LAN7/8 Activity LED Header
PCIe 4.0 x8 SlimSAS Connector
Standby Power Header
LAN5/6 Activity LED Header
Trusted Platform Module/Port 80 Connector
1 GbE RJ45 LAN Ports
10 G Base-T RJ45 LAN Ports
25 G SFP28 LAN Ports
OCuLink Connector (to 4x SATA 3.0 or PCIe 3.0 x4)
CPU1 PCIe 4.0 x16 Slot
Unit Identifier Switch
Front Accessible USB 2.0 Headers
Back Panel USB 3.0 Ports
VGA Port
