Rear View
Figure 1-3. SYS-110D-4C/8C/14C/16C/20C-FRAN8TP: Rear View
Figure 1-4. SYS-110D-4C/8C/14C/16C/20C-FRDN8TP: Rear View
Feature
Description
Power Supplies
Two redundant power supply modules, PWS1 on the right, PWS2 on the left
Fans
Five system fans
Fans
Fans
System Features: Rear
13
Chapter 1: Introduction
Power Supply 2
Power Supply 1
Power Supply 2
Power Supply 1
