1.1 Overview

This chapter provides a brief outline of the functions and features of the
SuperServer SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP. It is based on the
X12SDV-4C/8C/14C/16C/20C-SPT8F motherboard and the CSE-515M-R000NP2 chassis.
The following provides an overview of the specifications and capabilities.
Motherboard
X12SDV-4C/8C/14C/16C/20C-SPT8F
Chassis
CSE-515M-R000NP2
Processor
Intel® Xeon D Ice Lake 4/8/14/16/20 Cores Processor from 65 W to 120 W
Support
Four DIMM slots, up to 256 GB ECC RDIMM or 512 GB LRDIMM DDR4 memory with
Memory
speeds of up to 2933 MT/s
Note: 128 GB RDIMM is not compatible with the system.
Drive Support
Two internal 2.5" SATA3 drive bays
One PCIe 4.0 x16 slots (FHFL slots)
Expansion Slots
One M.2 PCIe 3.0 x4/SATA3 slot (supports M-Key 2280 and 2242)
Four GbE LAN ports, two 10 G BASE-T LAN ports, two 25 G SFP28 ports
One dedicated RJ45 BMC LAN port
I/O Ports
One VGA port
Two USB 3.0 Type A
System Cooling
Five counter-rotating, hot-swappable fans
SYS-110D-4C/8C/14C/16C/20C-FRAN8TP: Two 800W AC redundant power supplies
Power
SYS-110D-4C/8C/14C/16C/20C-FRDN8TP: Two 600W DC redundant power supplies
Form Factor
1U; (WxHxD) 17.2 x 1.7 x 15.7 in (437 x 43 x 398.78 mm)
Note: The Quick Reference Guide can be found on the product page for
SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP. The following safety agency or regulatory
models associated with the SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP have been
certified as compliant with UL or CSA: 515M-R8X12, 515M-8, 515M-R6DX12, and 515M-6D.
