Hardware Setup and Configuration

For detailed visual presentation of the hardware setup and configuration, refer to the
Getting started tutorial - use the link isystem.com/start.
1. Connect the power supply cable. BlueBox should be switched off.
2. First connect via USB. Later you can configure TCP/IP connection to work remotely.
3. Connect the Grounding wire to the BlueBox and the Target.
If the Grounding wire is not connected, the ground potential difference between the
BlueBox and the Target can exceed well over 1000V even before any of the devices are
powered up. This voltage difference is discharged over the BlueBox and the Target,
leading to the possible destruction of electronic components.
4. Connect the ribbon cable to the iC5 Debug Adapter.
5. Connect the ribbon cable to the BlueBox connector(s).
6. Connect the Debug Adapter to the Target. To disconnect squeeze the two metal latches on
the ribbon cables.
7. Power on procedure:
·
BlueBox
·
Target
8. Install winIDEA and create a new workspace.
