DEMO MANUAL DC2228A
Dc2228a control tool
2. Send the hardware ID and request for free license
renewal to TEConcept GmbH
subject line:
To: info@teconcept.de
Subject: DC2228A license renewal request
3. Receive the new license key by email.
A
D
B
10
using this address and
C
F
G
(A) Control Tool connection controls
(B) Control Tool connection status
(C) Port selector
(D) Port status
(E) Device selector and device parameters
(F) Device configuration controls
Figure 6. Control Tool Main Window
4. Again using Tools → License key manager, enter the
new key. For Period, enter "10000". Then click the
"Send" button and close the window.
5. Re-open the license manager and check that the "Re-
maining time" has been reset.
E J
H
K
(G) Connected device state and speed
(H) Light bulb controls and status
(I) Process data
(J) Device parameters
(K) Firmware version
I
DC2228A F06
