- Page 1 Asset Monitoring Gateway with SNAP ID Instruction Manual Original Instructions p/n: 234288 Rev. A July 17, 2023 © Banner Engineering Corp. All rights reserved.
-
Page 2: Table Of Contents
Contents Contents ..........................2 Chapter 1 Asset Monitoring Gateway (AMG) with SNAP ID Overview Asset Monitoring Gateway (AMG) Hardware ............................... 3 Dimensions ........................................4 Chapter 2 Configuration Instructions Wiring the AMG ......................................5 AMG HMI Home Screen....................................5 Commission and Assign Connected Sensors or Converters........................6 Chapter 3 Software Utilities Screens Sensor List Screens ..................................... -
Page 3: Chapter 1 Asset Monitoring Gateway (Amg) With Snap Id Overview
Asset Monitoring Gateway With SNAP ID Instruction Manual Chapter Contents Asset Monitoring Gateway (AMG) Hardware ..............................3 Dimensions.......................................... 4 Chapter 1 Asset Monitoring Gateway (AMG) with SNAP ID Overview The Asset Monitoring Gateway (AMG) with SNAP ID provides commissioning, monitoring, and alarms for up to 20 support ed Modbus® and SNAP SIGNAL® enabled sensors and converters. The gateway scans for individual sensors or converters and auto-detects model information, allowing users to change and assign Modbus server ID numbers to commission custom systems. -
Page 4: Dimensions
Asset Monitoring Gateway With SNAP ID Instruction Manual The items included with the Asset Monitoring Gateway with SNAP ID are: • 4" Banner Touch Screen HMI with Ethernet connection • M12 power and serial communications input connector • PSW-24-1 power supply •... -
Page 5: Chapter 2 Configuration Instructions
Rx - AMG HMI Home Screen Customize the gateway name, located on the top title bar, by tapping Enter title and typing in a custom name. For help information, click the help-information icon ( ) in the top right corner of the screen. Touch the globe icon to dis play a QR code that takes you to the product information from Banner Engineering. The four status icons represent groups of sensing assets (up to 20 devices). Each icon's color indicates warnings, alarms, or connection status within that group. Group icons are nameable from within the group icon window. Select an icon to view the asset’s status or additional sensor data. July 17, 2023 © Banner Engineering Corp. -
Page 6: Commission And Assign Connected Sensors Or Converters
In the Sensor Utilities column, touch Sensor Scan/ID Assign. The Sensor table will initially be unpopulated. Connect any supported Banner Modbus sensor or S15 converter using a splitter cable or hub with power connected to the homerun cable and a branch connected to the Gateway M12 connector on the bottom right of the enclosure. - Page 7 After a SID # has changed, the sensor table repopulates and displays the new SID # associated with the learned device. All previously learned sensors continue to appear in the table unless they are deleted from the system using this screen. July 17, 2023 © Banner Engineering Corp.
- Page 8 Blank page ...
-
Page 9: Chapter 3 Software Utilities Screens
Displays the current device Modbus Server ID Group If the sensor is grouped in the main display screen, Group displays that device's current group (numbered 14). To add a sensor to a group, pick a group icon from the main page and select Edit Group #. Highlight the device you'd like to add to the group and select Add To Group. To delete a device previously commissioned into a group, select the device and select Delete From Group. Sensor Name A customizable entry accessed using the Details button. Model Name The Banner part number nomenclature for the attached device. Sensor Type Displays the mode of sensing. July 17, 2023 © Banner Engineering Corp. - Page 10 The details screen also provides a notes area intended for any applicable user data specific to that sensor, such as the date of installation, location, or the name of the monitored asset. Sensor List Details screen Values Displays the current readings and thresholding settings for the selected sensor. Sensors List Values screen July 17, 2023 © Banner Engineering Corp.
- Page 11 Set thresholds for specific registers by touching the thresholds in the table and manually typing in an alarm value. This prompts the AMG to enable the Mode operator. Tap the mode operator to browse through the operands and select the in tended one. Select Save when you are satisfied with the alarm data, and then Yes for confirmation. Thresholds saved ap pears at the bottom of the screen after the settings are saved. Sensor List Thresholds screen Operations screen July 17, 2023 © Banner Engineering Corp.
-
Page 12: Special Sensor Settings Screen
Asset Monitoring Gateway With SNAP ID Instruction Manual Statistics Displays how many times a selected sensor has breached a threshold along with how many communications errors were detected (if applicable). Sensor List Statistics screen Special Sensor Settings Screen The Special Sensor Settings screen contains the menus for specific sensor configurations, including global Vibration algo rithm base settings (applicable when using QM30VT2 vibration sensors with VIBE-IQ® turned on) and a scaling option direct ed towards generic analog converters (S15C-U-MQ and S15C-I-MQ). Special Sensor Settings screen July 17, 2023 © Banner Engineering Corp. - Page 13 An asset with more extensive variability often requires a longer sampling period to characterize its behavior. Global VIBE-IQ screen July 17, 2023 © Banner Engineering Corp.
-
Page 14: Initialize The Vibe-Iq Machine Learning Algorithm
Sensor Custom Scaling IMPORTANT: If you need to push sensor-specific data to Banner Cloud Data Services, you must also configure the custom scaling in the cloud because the AMG only stores this data locally. Initialize the VIBE-IQ Machine Learning Algorithm After global settings have been confirmed in the special settings window, previously commissioned vibration sensors can acti... - Page 15 The number of samples the gateway has available (preferably up to 300) and the average value of the parameters is shown. Press Undo if more samples are required. The suggested banked samples needed to accurately characterize a rotating asset is 300. Running the baseline pro cedure with all 300 samples is recommended, but a sensor can be re-baselined at any time. Press Close then Save to store the learned threshold information for each register within the register details. July 17, 2023 © Banner Engineering Corp.
-
Page 16: Dxm Utilities Screens
Contains options for pushing data to the Banner Cloud Data Services website. The Cloud Push Enable toggle field de faults to No. To change this to Yes, press the field entry toggle. DXM Configuration screen IMPORTANT: You must configure your Banner CDS portal and set up a gateway destination on the Banner CDS website before you turn Cloud Push Enable on. ... -
Page 17: Hmi Utilities Screen
DXM HTTP Status Contains cellular signal strength (if applicable) along with cloud push statistics. By default, the AMG is configured with Push disabled (shown at the bottom of the screen). When cloud push is turned on (via the DXM Configuration Screen) the status changes in this window to Push Enabled. - Page 18 Asset Monitoring Gateway With SNAP ID Instruction Manual Reset Options Reset HMI resets the screen to the splash page and main window. HMI Reset screen Run Panel Setup accesses the internal HMI startup menu to update the screen with new firmware. Reset DXM resets the internal gateway but the HMI screen remains active. Full System Reset triggers an entire reset of the AMG. Security/Passwords Logout secures the device to the current configuration; no settings can be changed without the administration password. The default administration password, if prompted, is 8888. HMI Security/Passwords screen Passwords displays the custom password table. There can be up to seven user passwords, configurable by entering and saving new values within this screen. By default, Require Login at Startup is turned off to allow for initial set up and con figuration. July 17, 2023...
- Page 19 Asset Monitoring Gateway With SNAP ID Instruction Manual System Messages Contains communication messages, critical error messages, global settings, and sensor scan data. HMI System Messages screen July 17, 2023 © Banner Engineering Corp.
- Page 20 Blank page ...
-
Page 21: Chapter 4 Additional Information
Dashboard. Email alerts can be configured using the Alarms screen. For more information on creating accounts on and using the Banner Cloud Data Services (CDS) system, please refer to the Banner CDS Quick Start Guide (p/n 201126) or the Instruction Manual (p/n 178337). Create a New Gateway (on BannerCDS) The web server captures data from the AMG using either a cellular connection or an Ethernet connection. Users collect and ... -
Page 22: Configure The Hmi To Push Information To The Cloud
Cloud Push Enable to Yes. Failure to do so can result in long wait times for the web site to autodetect. On the HMI: Go to DXM Utilities › DXM Configuration to enable cloud pushing. Change the Threshold Filter to a number greater than 0 (3 is recommended). Verify your device's Push Communication Mode is accurate to your model. Toggle Cloud Push Enable to Yes. HMI Utilities screen Change the Cloud Push Interval to a desired time. The default push interval is 600 seconds (10 minutes). Press Save and confirm. The AMG pushes immediately upon confirmation. The user can track the HTTP data within the DXM Utilities › DXM HTTP Status screen. July 17, 2023 © Banner Engineering Corp. -
Page 23: Chapter 5 Product Support
Banner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at July 17, 2023... - Page 24 WHETHER ARISING IN CONTRACT OR WARRANTY, STATUTE, TORT, STRICT LIABILITY, NEGLIGENCE, OR OTHER WISE. Banner Engineering Corp. reserves the right to change, modify or improve the design of the product without assuming any obligations or liabilities relating to any product previously manufactured by Banner Engineering Corp. Any misuse, abuse, or improper application or installation of this product or use of the product for personal protection applications when the product is identified as not intended for such purposes will void the product warranty.
