Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Operating Mode (FUNC)
Navigation
Description
Options
Value for 4 mA (STL)
Navigation
Description
Note
Options
Factory setting
Value for 20 mA (STU)
Navigation
Description
Note
Options
Factory setting
Endress+Hauser
9.6

Current output

Display: EF → Operating Mode (FUNC)
IO-Link: Parameter → Application → Sensor → Operating Mode (FUNC)
Enables the desired behavior of output 2 (not IO-Link output)
Options:
• OFF
• 4-20 mA (I) (can only be selected if the device has been ordered with 4-20mA)
• DC-PNP (PNP)
Display: STL → Value for 4 mA (STL)
IO-Link: Parameter → Application → Current output → Value for 4 mA (STL)
Assignment of the pressure value which should correspond to the 4 mA value.
It is possible to invert the current output. To do so, assign the pressure upper range value
to the lower measuring current.
Enter the value for 4 mA in the selected pressure unit anywhere within the measuring
range. The value can be entered in increments of 0.1 (increment depends on the
measuring range).
No selection. The user is free to edit the values.
0.0 or as per order specifications
Display: STU → Value for 20 mA (STU)
IO-Link: Parameter → Application → Current output → Value for 20 mA (STU)
Assignment of the pressure value which should correspond to the 20 mA value.
It is possible to invert the current output. To do so, assign the pressure lower range value
to the upper measuring current.
Enter the value for 20 mA in the selected pressure unit anywhere within the measuring
range. The value can be entered in increments of 0.1 (increment depends on the
measuring range).
No selection. The user is free to edit the values.
Upper measuring limit or as per order specifications.
Commissioning
