If load is too great:
• failure current is output and "S803" displayed (output: MIN alarm current)
• Periodic checking to establish if it is possible to quit fault state
• In order to guarantee sufficient terminal voltage, a maximum load resistance RL
(including line resistance) must not be exceeded depending on the supply voltage UB of
the supply unit.
6.3

Post-connection check

 Are the device and cables undamaged (visual check)?
 Do the cables used comply with the requirements?
 Are the mounted cables relieved of tension?
 Are all cable glands installed, securely tightened and leak-tight?
 Does the supply voltage match the specifications on the nameplate?
 Is the terminal assignment correct?
 If required: has protective ground connection been established?
If supply voltage is present: is the device ready for operation and do values appear on the display module or

is the green status LED lit?
Electrical connection
23
