Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Factory setting
1)
Output 1 (OU1)
1) Without Smart Sensor Profile
Navigation
Description
Selection
Factory setting
Teach Select
Navigation
Description
Selection
Factory setting
Teach SP1
Navigation
Description
Teach SP2
Endress+Hauser
0
Parameter → Application → Switch output 1 → Output 1 (OU1)
• Hysteresis normally open (HNO):
The switch output is specified as a NO contact with hysteresis properties.
• Hysteresis normally closed (HNC):
The switch output is specified as an NC contact with hysteresis properties.
• Window normally open (FNO):
The switch output is specified as a NO contact with window properties.
• Window normally closed (FNC):
The switch output is specified as an NC contact with window properties.
• Hysteresis normally open (HNO)
• Hysteresis normally closed (HNC)
• Window normally open (FNO)
• Window normally closed (FNC)
Hysteresis normally open (HNO) or as per order specifications
Only with Smart Sensor Profile
Teach Single Value
Parameter → Teach → Single Value → Teach Select
Selection of switching signal to be taught
• 0 = Default Channel = SSC1.1 Pressure
• 1 = SSC1.1 Pressure
• 2 = SSC1.2 success
• 255 = All SSC
1
Parameter → Teach → Single Value → Teach SP1
System command (value 65) "Teach switch point 1"
Description of device parameters
