Description of device parameters
Teach Select
Navigation
Description
Selection
Factory setting
Teach SP1
Navigation
Description
Teach SP2
Navigation
Description
Teach Result State
Navigation
Description
80
Teach Single Value
Parameter → Teach → Single Value → Teach Select
Selection of switching signal to be taught
• 0 = Default Channel = SSC1.1 Pressure
• 1 = SSC1.1 Pressure
• 2 = SSC1.2 success
• 255 = All SSC
1
Parameter → Teach → Single Value → Teach SP1
System command (value 65) "Teach switch point 1"
Parameter → Teach → Single Value → Teach SP2
System command (value 66) "Teach switch point 2"
Parameter → Teach → Single Value → Teach Result State
Result of the activated system command
