Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Description
Selection
Factory setting

SSC1.1 Config. Hyst.

Navigation
Description
Selection
Switching delay time, output 1 (dS1)
Navigation
Description
Selection
Factory setting
Switchback delay time, output 1 (dR1)
Navigation
Description
Selection
Factory setting

SSC1.2 Param. SP1

Endress+Hauser
Module of switching signal SSC1.1 for pressure
• 0 = Deactivated
• 1 = Single point
• 2 = Window
• 3 = Two-point
0
Parameter → Signal Switching Channels 1.1 → SSC1.1 Config. Hyst.
Hysteresis of switching signal SSC1.1 for pressure
No selection. The user is free to edit the values.
Parameter → Signal Switching Channels 1.1 → Switching delay time, output 1 (dS1)
To prevent switching on and switching off at values around the switch point, you can
configure a delay for the specific points within a range of 0 to 50 s with a resolution of 2
decimal places.
If the measured value leaves the switching range during the configured delay time, the
delay time starts again.
0.00 to 50.00 s
0 s
Parameter → Signal Switching Channels 1.1 → Switchback delay time, output 1 (dR1)
To prevent switching on and switching off at values around the switch-back point, you can
configure a delay for the specific points within a range of 0 to 50 s with a resolution of 2
decimal places.
If the measured value leaves the switching range during the configured delay time, the
delay time starts again.
0.00 to 50.00 s
0 s
Switching Signal Channel 1.2
Description of device parameters
77
