Description of device parameters
Navigation
Description
Teach Result State
Navigation
Description
SSC1.1 Param. SP1
Navigation
Description
Selection

SSC1.1 Param. SP2

Navigation
Description
Selection

SSC1.1 Config. Logic

Navigation
Description
Selection
Factory setting

SSC1.1 Config. Mode

Navigation
76
Parameter → Teach → Single Value → Teach SP2
System command (value 66) "Teach switch point 2"
Parameter → Teach → Single Value → Teach Result State
Result of the activated system command
Switching Signal Channels
Switching Signal Channel 1.1
Parameter → Signal Switching Channels 1.1 → SSC1.1 Param. SP1
Switch point 1 of switching signal SSC1.1 for pressure
No selection. The user is free to edit the values.
Parameter → Signal Switching Channels 1.1 → SSC1.1 Param. SP2
Switch point 2 of switching signal SSC1.1 for pressure
No selection. The user is free to edit the values.
Parameter → Signal Switching Channels 1.1 → SSC1.1 Config. Logic
Logic for inverting the switching signal SSC1.1 for pressure
• 0 = High active
• 1 = Low active
0
Parameter → Signal Switching Channels 1.1 → SSC1.1 Config. Mode
