Operation options
26
7.2.2 Information on the operational states
Operational states Function of status-LED and onsite display
Operation • Status LED is lit green
• LEDs of switch output 1 and switch output 2 signal the status of each switch output
• No activity of LED for switch output 2 if current output is active
• White background lighting
Problem • Status LED lit steady red
• Red display background
• LED of switch output 1 and switch output 2 off (switch output is deactivated)
Warning • Status LED flashing red
• White display background
• LEDs of switch output 1 and switch output 2 signal the status of each switch output
For Device Search • The green LED is lit (= operational) on the device and starts to flash with increased
luminosity. Flash frequency
• LEDs of switch output 1 and switch output 2 signal the status of each switch output
• Display background depending on the device status
IO-Link • Status LED flashes green as per IO-Link specification (regardless of measuring
communication operation, error or warning). Flash frequency
• Display background depending on the device status
• The state of switch output 1 is also indicated via the LED of switch output 1 at the same
time as the process data are displayed
7.3 General value adjustment and rejection of illegal
entries
Parameter (not numerical value) is flashing: parameter can be adjusted or selected.
When adjusting a numerical value: the numerical value does not flash. The first digit of the
numerical value starts to flash only when the  key is pressed by way of confirmation.
Enter the desired value with the  or  key and press the  key to confirm. Following
confirmation, the data are recorded directly and are active.
• Entry is OK: value is accepted and shown for one second on the display against a white
background.
• Entry is not OK: the message "FAIL" appears for one second on the display against a red
background. The value entered is rejected. In the event of an incorrect setting which
affects the TD, a diagnostic message is displayed.
7.4

Navigation and selection from list

The capacitive operating keys are used for navigation in the operating menu and to select
an option from a picklist.
Operating key(s) Meaning
• Navigate downwards in the picklist
• Edit the numerical values and characters within a function
A0017879
• Navigate upwards in the picklist
• Edit the numerical values and characters within a function
A0017880
• Confirm entry
• Jump to the next item
• Selection of a menu item and activation of edit mode
A0017881
• The key lock function (KYL) is accessed by pressing the key for longer than 2 seconds
