Overview of the IO-Link operating menu
IO-Link Level 1
Teach - Single Value
Switching Signal Channels
System
Observation Pressure
Condensed Status
Switch State Output (OU1)
Switch State Output (OU2)
62
Level 2 Level 3
Current output Value for 4 mA (STL)
Value for 20 mA (STU)
Pressure applied for 4mA (GTL)
Pressure applied for 20mA (GTU)
Alarm current (FCU)
Teach Select
System Command
Teach SP1
Teach SP2
Teach Result State
Switching Signal Channel SSC1.1 Param. SP1
1.1
SSC1.1 Param. SP2
SSC1.1 Config. Logic
SSC1.1 Config. Mode
SSC1.1 Config. Hyst.
Switching delay time, output 1
(dS1)
Switchback delay time, output 1
(dR1)
Switching Signal Channel SSC1.2 Param. SP1
1.2
SSC1.2 Param. SP2
SSC1.2 Config. Logic
SSC1.2 Config. Mode
SSC1.2 Config. Hyst.
Switching delay time, output 2
(dS2)
Switchback delay time, output
2(dR2)
Device Management HI Max value
(maximum indicator)
LO Min value
(minimum indicator)
Revisioncounter (RVC)
Reset to factory settings (RES)
Back-to-box
Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Details
→  69
→  69
→  69
→  70
→  70
→  75
→  75
→  75
→  75
→  76
→  76
→  76
→  76
→  76
→  77
→  77
→  77
→  77
→  78
→  78
→  78
→  78
→  79
→  79
→  81
→  81
→  81
→  81
→  82
→  83
→  83
→  83
→  83
