Ceraphant PTC31B, PTP31B, PTP33B IO-Link
Endress+Hauser
9

Commissioning

If an existing configuration is changed, measuring operation continues! The new or
modified entries are only accepted once the setting has been made.
If block parameter configuration is used, a parameter change is only adopted after the
parameter download.
WARNING
L
Risk of injury from the uncontrolled activation of processes!
‣
Make sure that downstream processes are not started unintentionally.
WARNING
L
If a pressure smaller than the minimum permitted pressure or greater than the
maximum permitted pressure is present at the device, the following messages are
output in succession:
‣
S140
‣
F270
NOTICE
An IODD with corresponding default values is used for all pressure measuring ranges.
This IODD applies to all measuring ranges! The default values of this IODD may not be
valid for this device. IO-Link messages (e.g. "Parameter value above limit") may be
displayed when the device is updated with these default values. Existing values are
not accepted in this case. The default values apply exclusively to the 10 bar (150 psi)
sensor.
‣
Before default values are written from the IODD to the device, the data must first be
read from the device.
9.1

Function check

Before commissioning your measuring point, ensure that the post-installation and post-
connection checks have been performed:
• Checklist for "Post-mounting check" →  19
• Checklist for "Post-connection check"
9.2

Commissioning with an operating menu

Commissioning comprises the following steps:
• Configure pressure measurement →  40
• Where necessary, perform position adjustment →  42
• Where necessary, configure process monitoring →  44
