input ac power

Wire input AC power wire to the MAX Megatron Toroid box as shown.
Choose either 115V or 230V setting on input AC power selector switch.
NOTE: AC power wire is required for EACH gate operator
when using dual gate operators.
CAUTION: Make sure circuit
breaker is OFF from incoming
AC input wire BEFORE wiring!
Input AC Power Options
Single Phase 115VAC Only
115VAC
Set to 115V
115V
115 OR 230VAC
Power Wire
Single Phase 230VAC Only
230VAC
230V
Set to 230V
Operator MUST be Properly GROUNDED
Any of the Chassis Grounds can be used. They are located next to
the gear reducer. DO NOT remove any existing green ground wires.
Proper grounding of this gate operator is a
WARNING WARNING
requirement for LIGHTNING PROTECTION
connect chassis
in lightning prone areas. To be effective,
to ground rod for
ground connections should be made with a
lightning protection
minimum 12 AWG, 600 volt insulated wire
to a ground point within 10 feet of the gate operator. The ground
point must be at an electrical panel, a metallic cold water pipe that
runs in the earth, or a grounding rod.
NOTE: Consult city codes for AC line wiring.
Beware of existing underground services.
Wiring operator
7 Amp Fuse
DANGER
HIGH VOLTAGE!
Power Terminal
Line (Black)
Neutral (White)
Chassis (Green)
IMPORTANT NOTE: Make sure there are NO exposed
bare wires at the power terminal connection.
AC IN Power LED
A C
2 3 0
V
Input AC Power I N
Selector Switch
e d
n u
n ti ly w
c o
o r o n fu s
: F c e o f
p la
IN G n g
, re ra ti r n
R N
