max megatron specifications

UL 325 Class of Operation
Gate Type - Vehicular Swing Gate
Max Gate Weight / Length:
- MAX Megatron 1400/1400HP - 1400lbs @ 15 ft or 1200 lbs @ 20 ft
- MAX Megatron 2200 - 2200lbs @ 15 ft or 1500 lbs @ 20 ft
- MAX Megatron FAST - 1600lbs @ 12 ft gate per operator
NOTE: The MAX Megatron FAST is ONLY available for installation on bi-parting gates (dual operators).
A single gate operator CANNOT be used.
90° Opening Time:
- MAX Megatron 1400/1400HP/2200 - 16 selectable speeds from approximately
11.5 sec to 20 sec depending on the weight and length of the gate.
- MAX Megatron FAST - 16 selectable speeds from approximately
6 sec to 14 sec depending on the weight and length of the dual gates.
Cycles per Hour AC Input Power
Battery Back-Up Cycles
- Approximately 450 cycles
NOTE: The number of gate cycles using ONLY battery back-up power will vary depending on the
weight of the gate, the gate length, the operating condition of the gate hardware, temperature and
the amount of charge the batteries have at the beginning of the battery power only operation.
Input AC Power - Switchable: 115VAC or 230VAC single phase
Motor - 24VDC Brushless (equivalent to 1 HP AC motor)
Operating Temperature:
Entrapment Protection:
- UL 325 Type A Inherent (ERD sensor)
- Inputs for NORMALLY CLOSED (N.C.)
UL 325 Type B1 (photo cell)
and Type B2 (sensing edge)

important safety information

WARNING – To reduce the risk of injury or death:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Never let children operate or play with gate controls. Keep the remote control away from children.
3. Always keep people and objects away from the gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE.
4. Test the gate operator monthly. The gate MUST reverse on contact with a rigid object or stop when an object activates the
non-contact sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to adjust and retest the
gate operator properly can increase the risk of injury or death.
5. Use the emergency release only when the gate is not moving.
6. KEEP GATES PROPERLY MAINTAINED. Read the owner's manual. Have a qualified service person make repairs to gate
hardware.
7. The entrance is for vehicles only. Pedestrians must use separate entrance.
8. SAVE THESE INSTRUCTIONS
2
- Class I, II, III, IV
- Continuous
(BC-7 Battery Module-7 Amp/Hr Batteries fully charged):
-4°F to 158°F (-20°C to 70°C)
25.2"
1400HP
(High Profile)
17"
26.6"
1400HP
1400HP
16.8"
18.3"
18.5"
29.9"
24.5"
24.5"
21.3"
