DEMO MANUAL
DC981A/DC981B
PARTS LIST
ITEM
QTY
REFERENCE
DC981B Required Circuit Components
1
2
C2, C1
2
2
C3, C4
3
1
C5
4
1
D1
5
1
D2
6
1
J1
7
1
R1
8
1
R2
9
1
U1
12
PART DESCRIPTION
CAP, X7R, 0.1µF 16V, 10%, 0603
CAP, X7R 0.1µF 100V, 10%, 0603
CAP, X7R, 0.47µF 100V, 10%, 0805
DIODE, 58V TVS, SMA-DIODE
DIODE, SCHOTTKY, PICO MINI, SOT563
HEADER, 1X6, 0.079", SMT, HORIZONTAL
RES, CHIP 510kΩ 1/16W 5%, 0603
RES, CHIP 1kΩ 1/16W 5%, 0603
I.C., LTC4263CDE, DFN14DE
MANUFACTURER/PART NUMBER
MURATA, GRM188R71C104KA01D
MURATA, GRM188R72A104KA35D
MURATA, GRM21BR72A474KA73L
DIODES INC, SMAJ58A
CENTRAL SEMI, CMLSH05-4
SAMTEC, MMT-106-02-S-SH-004
AAC, CR16-514JM
AAC, CR16-102JM
ANALOG DEVICES, LTC4263CDE
