MultiLab 4010-1

Settings

Menu item
Calibration / Calibra-
tion record
Calibration / Calibra-
tion data storage / Dis-
play
Calibration /
Calibration data stor-
age / Output to
RS232/USB
Calibration / Buffer
Calibration / Single-
point calibration
Calibration / Calibra-
tion interval
Calibration / Unit for
slope
QSC / First calibration
QSC / Record of first
calibration
QSC / Control calibra-
tion
Man. temperature
ba76141e03 03/2014
9 Settings
9.1

pH measurement settings

9.1.1 Settings for pH measurements

The settings are made in the menu for calibration and measurement settings of
the pH/ORP measurement. To open the settings, display the required mea-
sured parameter in the measured value display and press the <MENU/
ENTER> key. After completing the settings, switch to the measured value dis-
play with <M>.
Default settings are printed in bold.
Possible Description
setting
- Displays the calibration record of the last calibration.
- Displays the last calibration records (max. 10)
- Outputs the calibration data storage to the interface
YSI Buffer sets to be used for pH calibration.
ConCal More buffers and details: see section 9.1.2 B
NIST/DIN
CALIBRATION
... 30.
yes Quick calibration with 1 buffer
no
1 ... 7 ... Calibration interval for the IDS pH sensor (in days).
999 d The meter reminds you to calibrate regularly by the flashing
sensor symbol in the measuring screen.
mV/pH Unit of the slope.
% The % display refers to the Nernst slope of
-59.2 mV/pH (100 x determined slope/Nernst slope).
- Starts the initial calibration with QSC buffers.
This menu item is only available as long as no initial calibra-
tion was carried out with the connected IDS sensor.
- Displays the calibration record of the QSC initial calibration.
- Starts the control calibration with QSC buffers.
This menu item is only available if an initial calibration was
carried out with the connected IDS sensor.
-25 ... +25 Entry of the manually determined temperature.
... +130 °C This menu item is only available if an IDS adapter is con-
nected.
, page 60 and section 5.2
Settings
UFFER SETS FOR
H , page
P CALIBRATION
59
