Cond measurement settings

9.4.1 Settings for IDS conductivity sensors

The settings are made in the menu for the measured parameter, conductivity.
To open the settings, display the required measured parameter in the mea-
sured value display and press the <MENU/ENTER> key. After completing the
settings, switch to the measured value display with <M>.
The possible settings are individually displayed for each sensor. Below the set-
ting menu is displayed for two IDS sensors (4310, 4320).
Default settings are printed in bold.
Menu item
Calibration /Cali-
bration record
Calibration / Cali-
bration data stor-
age / Display
Calibration /
Calibration data
storage / Output to
RS232/USB
Calibration /Cali-
bration interval
Type
Cell const. man
Temp. comp. (TC) /
Method
Possible Description
setting
- Displays the calibration record of the
last calibration.
- Displays the last calibration records
(max. 10)
- Outputs the calibration data storage to
the interface
1 ... 150 ... Calibration interval for the IDS con-
999 d ductivity sensor (in days).
The meter reminds you to calibrate
regularly by the flashing sensor sym-
bol in the measuring screen.
Measuring cell used
cal Measuring cells whose cell constant is
determined by calibration in the KCL
control standard solution.
Calibration range:
0.450 to 0.500 cm
The currently valid cell constant is dis-
played in the status line.
man Manually adjustable cell constant in
the range 0.450 ... 0.500 cm
0.450 ... Display and setting options for the
0.475 ... manually adjustable cell constant.
-1
0.500 cm
nLF Procedure for temperature compen-
Lin sation (see section 8.2 T
off
COMPENSATION
This setting is only available for the
measured parameters, conductivity
ϰ
( ) and resistivity (
MultiLab 4010-1
-1
-1
.
EMPERATURE
, page 55).
ρ)
.
