Multi 3630/3620 IDS Overview Overview Meters of the series MultiLine Multi 3630/3620 IDS can be wirelessly con- ® nected to the OxiTop -IDS measuring heads. ® The OxiTop -IDS measuring heads in conjunction with a Multi 3630/3620 IDS ® meter add the following functions to the OxiTop measuring system: ®... -
Page 6: Safety
Safety Multi 3630/3620 IDS Safety Safety information 2.1.1 Safety information in the operating manual This operating manual provides important information on the safe operation of the meter. Read this operating manual thoroughly and make yourself familiar with the meter before putting it into operation or working with it. The operating manual must be kept in the vicinity of the meter so you can always find the infor- mation you need. -
Page 7: Safe Operation
Multi 3630/3620 IDS Safety Safe operation 2.2.1 Authorized use ® Authorized use of the meter in operation with OxiTop -IDS measuring heads is ® exclusively the pressure measurement with OxiTop -IDS measuring heads in a laboratory. Only the operation and running of the meter according to the instructions and technical specifications given in this operating manual is authorized (see chapter 16 T ECHNICAL DATA... -
Page 8: Commissioning
Commissioning Multi 3630/3620 IDS Commissioning Information on how to put the Multi 3630/3620 IDS into operation is given in the operating manual of your meter. Information on how to put the WLM-M adapter into operation is given in the operating manual of the WLM system. ®... -
Page 9: Operation
Multi 3630/3620 IDS Operation Operation The basic information and general operating principles are given in the operating manual of your meter, e.g. operation, navigation in the menu, setting the date, time and language. ® The meter can either be operated with IDS sensors or OxiTop -IDS measuring ®... -
Page 10: Measuring Modes While Operating The Oxitop ® -Ids Measuring Heads
Operation Multi 3630/3620 IDS Color Explanation Measurement is running. The measuring head is in a critical condition: The battery is nearly discharged The pressure in the sample bottles is too high. Suitable actions, see operating manual of your measuring head. -
Page 11: Oxitop ® Set Management
Multi 3630/3620 IDS Operation ® OxiTop set management 4.2.1 Overview ® After switching to operation with the OxiTop -IDS measuring heads with <M_>, the display of the meter shows the OxiTop set management (overview of all set/ samples started). A set can include several (max. 12) samples, for which the following joint set- tings are specified: ... -
Page 12: Overview Of The Sets (Oxitop Set Management)
Operation Multi 3630/3620 IDS 4.2.2 Overview of the sets (OxiTop set management) In the OxiTop set management, you can create new sets (<F1>/[New]), and within a set, new samples – max. 12 sets – per set up to 12 samples ®... -
Page 13: Overview Of The Samples Of The Set
Multi 3630/3620 IDS Operation 4.2.3 Overview of the samples of the set The current measured values of all samples are automatically called up when the details of a set are queried (with <MENU/ENTER> in the OxiTop set man- agement). Set 190216-1 ... -
Page 14: Overview Of The Oxitop ® -Ids Measuring Heads In A
Operation Multi 3630/3620 IDS ® 4.2.4 Overview of the OxiTop -IDS measuring heads in a sample ® The details of the OxiTop -IDS measuring heads registered for a sample are listed in the overview of samples in the set and can be viewed by selecting a sample with <><>... -
Page 15: Settings
Multi 3630/3620 IDS Operation Settings 4.3.1 Measurement settings of the set The measurement settings for a set are defined while the set is being estab- lished. Default settings are printed in bold. Menu item Possible setting Explanation Measuring mode BOD standard Depending on the selected measuring BOD special mode, some of the following settings are... -
Page 16: Measurement Settings Of The Sample
Operation Multi 3630/3620 IDS Menu item Possible setting Explanation Number of measured Standard 1 measured value per day values Max. 360 measured values for the specified mea- suring duration Switching on/off the LED indication of the ® operating statuses (at the OxiTop -IDS measuring head). -
Page 17: Measuring Head
Multi 3630/3620 IDS Operation Menu item Possible setting Explanation Settings The maximum setting ranges quoted here can be restricted by other set- (for BOD special) tings. The setting selected in the Calculation menu is not available here. Measuring range 0 ... 400000 mg/l Measuring range Sample volume 10 ... - Page 18 Operation Multi 3630/3620 IDS Meas. head 12345678 Accept date/time Cancel 15.03.2020 08:00 ® 1 ID of the OxiTop -IDS measuring head ® (entered at the OxiTop -IDS measuring head) ® 2 Series number of the OxiTop -IDS measuring head Using Accept date/time, confirm the date and time for the measuring head.
-
Page 19: Operation With Oxitop ® -Ids Measuring Heads
® Multi 3630/3620 IDS Operation with OxiTop -IDS measuring heads ® Operation with OxiTop -IDS measuring heads Measuring 5.1.1 Preparing the measurement Municipal wastewater does not normally contain any toxic or inhibiting sub- stances. There are enough nutrient salts and suitable microorganisms present. Under these conditions, BOD determination in the undiluted sample using the ®... - Page 20 ® Operation with OxiTop -IDS measuring heads Multi 3630/3620 IDS Risks during determination of Caution ® During the anaerobic degradation of organic material in sealed biogas (OxiTop -IDS equipment, high pressure can develop due to biogas (main compo- /B measuring head) nents: methane and carbon dioxide).
-
Page 21: The Course Of The Measurement
® Multi 3630/3620 IDS Operation with OxiTop -IDS measuring heads 5.1.2 The course of the measurement Carry out the preparatory activities (see section 5.1.1 P REPARING THE MEASUREMENT Keep ready the instruments and accessories required Determine the sample volume ... - Page 22 ® Operation with OxiTop -IDS measuring heads Multi 3630/3620 IDS Measuring mode BOD special Set name 190228-1 Duration 17 d Settings BOD5 End date 23.02.2019 AutoTemp, GLP V_P 432 ml 79 Free meas. heads 15.03.2020 08:00 Sample Check and, if necessary, change the settings in the Set menu. ...
- Page 23 ® Multi 3630/3620 IDS Operation with OxiTop -IDS measuring heads Quit the Settings menu with <ESC>. Using <F1>/[Sample], open the settings for the individual samples in the current set. Sample Sample name Calculation Meas. range Settings continue Type BOD5, End date 23.02.2019 Mb 395 mg/l, V_P 432 ml V_F 510 mg, 1+1, T 22 °C p = 800 mbar.
- Page 24 ® Operation with OxiTop -IDS measuring heads Multi 3630/3620 IDS Check and, if necessary, change the settings in the Settings menu. Measuring range Bottle volume Sample volume Dilution 1 + Quit the Settings menu with <ESC>. ®...
- Page 25 ® Multi 3630/3620 IDS Operation with OxiTop -IDS measuring heads Assign further measuring heads of the current Sample in the Set (repeat steps 14-16). If necessary, create another sample in the set with <F2>/[New]. As the name for the Sample, a new number is automatically selected. The name can be changed freely (max.
-
Page 26: Displaying And Saving The Momentary Value
® Operation with OxiTop -IDS measuring heads Multi 3630/3620 IDS If there is a radio link with the measuring head (LED magenta), you can transfer and display the available measured values while a measurement is running. Completing the When the measurement is finished, the status LED flashes green for approx. measurement ®... -
Page 27: Evaluating The Samples
® Multi 3630/3620 IDS Operation with OxiTop -IDS measuring heads Display the momentary value with <STO>. – Save the momentary value with <MENU/ENTER>. – Exit the display without saving with <ESC>. Display any momentary values that were already saved with <RCL>. - Page 28 ® Operation with OxiTop -IDS measuring heads Multi 3630/3620 IDS Carry out one of the following actions: Using <MENU/ENTER>, display the individual measuring heads of the selected sample. There you can – View the data of the individual measuring heads that were last stored –...
-
Page 29: Transmitting Data (Usb Interfaces)
® Multi 3630/3620 IDS Operation with OxiTop -IDS measuring heads Carry out one of the following actions: Using <><>, highlight a graph. Using <MENU/ENTER>, load the graph as a single graph. There you can – view the individual measured values of the measuring head with <><>... -
Page 30: Calibration
® Operation with OxiTop -IDS measuring heads Multi 3630/3620 IDS Connect the output device to a USB interface. USB-A: USB printer, USB memory device USB-B: PC Using <M>, open the OxiTop set management. Using <><>, highlight a Set. Open the details of the selected set with <MENU/ENTER>. -
Page 31: Oxitop ® Pm-Test (Cal Test)
® Multi 3630/3620 IDS Operation with OxiTop -IDS measuring heads trum depending on their composition and food supply. With the aid of testing tools and suitable tests, errors due to defective pressure sensors or untight Oxi- ® -IDS measuring head threads can be identified. ®... - Page 32 ® Operation with OxiTop -IDS measuring heads Multi 3630/3620 IDS ® If necessary, assign further OxiTop -IDS measuring heads to the sam- ple (details: see section 5.1.2 T ) is HE COURSE OF THE MEASUREMENT displayed. If necessary, create more samples with measuring heads in the set (details: see section 5.1.2 T HE COURSE OF THE MEASUREMENT Start the calibration.
-
Page 33: Technical Data
Multi 3630/3620 IDS Technical data Technical data The present operating manual only describes operating with a MultiLine Multi 3630/3620 IDS. ® The technical data of the individual devices of the OxiTop measuring system are given in the following documents: Meter (Multi 3630/3620 IDS), ... -
Page 34: What To Do If
What to do if... Multi 3630/3620 IDS What to do if... Cause Remedy ® ® ® An OxiTop -IDS mea- – The selected OxiTop -IDS mea- – Register a free OxiTop -IDS mea- suring head cannot be suring head is already registered suring head registered for a sam- for a sample... - Page 35 Multi 3630/3620 IDS What to do if... Cause Remedy The Multi 3630/ – The batteries of the meter are – Insert new batteries or connect the 3620 IDS meter does empty power pack not react – Operating condition undefined or –...
-
Page 36: Firmware Update
Firmware update Multi 3630/3620 IDS Firmware update Firmware update for the meter Multi 3630/3620 IDS You can find available firmware update files for your meter on the Internet. With the "Firmware Update " program and a PC you can update the firmware of the Multi 3630/3620 IDS to the newest version. -
Page 37: Firmware Update For The Ids Wlm-M Adapter
Multi 3630/3620 IDS Firmware update Firmware update for the IDS WLM-M adapter You can find available firmware update files for the IDS WLM-M adapter on the Internet. With the Firmware Update program and a PC you can update the firm- ware of an IDS WLM-M adapter to the newest version. -
Page 38: Firmware Update For Oxitop
Firmware update Multi 3630/3620 IDS ® Firmware update for OxiTop -IDS measuring heads ® Available firmware updates for OxiTop -IDS measuring heads are provided on the Internet. With the "Firmware Update " program and a PC you can update ® the firmware of a OxiTop -IDS measuring head to the newest version. - Page 40 For more information on how Xylem can help you, go to xyleminc.com. ® Service address: Xylem Analytics Germany Sales GmbH &...
