PARTS LIST
ITEM
QTY
REFERENCE
10
1
C34
11
1
R3
12
1
R4
13
1
R6
14
1
R14
15
1
R15
16
1
R24
17
2
R8, R16
18
2
R9, R10
19
1
R17
20
1
R7
21
1
Q1
22
1
RS2
23
1
U1
Additional Demo Board Circuit Components
24
0
C4, C9, C15, C36, C19, C43, C44
25
0
C13, C16, C22-C24, C37
26
0
C21, C20, C17
27
0
C25-C28
28
0
C39
29
0
C40
30
0
C41
31
0
C42
32
0
R18
33
0
C35
34
0
R21-R23
35
0
R1, R2, R5, R11-R13, R19, R20
36
0
L1
37
0
L2
Hardware: For Demo Board Only
38
10
E1, E3, E5, E6, E8-E12, E14
39
4
E2, E4, E7, E13
40
2
J1, J2
41
5
JP1, JP2-JP6
42
1
JP7
43
1
JP8
44
4
MP1-MP4
45
3
XJP1, XJP7, XJP8
DEMO MANUAL DC2665B-C
PART DESCRIPTION
CAP ., 1μF, X7R, 6.3V, 10%, 0402
RES., 10k, 1%, 1/10W, 0603
RES., 60.4k, 1%, 1/10W, 0603
RES., 30.1k, 1%, 1/10W, 0603
RES., 10.7k, 1%, 1/10W, 0603
RES., 15k, 1%, 1/10W, 0603
RES., 6.65k, 1% 1/10W 0603
RES., 100k, 1%, 1/10W, 0603
RES., 0Ω, 5%, 1/16W, 0402
RES., 0Ω, 1/10W, JUMPER, 0603
RES., 150k, 5%, 1/10W, 0603
XSTR, MOSFET, N-CH, 40V, TO-252 (DPAK) VISHAY, SUD50N04-8M8P-4GE3
RES., SENSE, 0.005Ω, 1%, 1W, 2512
IC, 20V, 8A STEP-DOWN μModule REG.
CAP ., OPTION, 0603
CAP ., OPTION, 0805
CAP ., OPTION, 1206
CAP ., OPTION, 1210
CAP ., OPTION, 0805, 3 PC Pad
CAP ., OPTION, 1206, 3 PC Pad
CAP ., OPTION, 0603, 3 PC Pad
CAP ., OPTION, 1206, 3 PC Pad
RES., OPTION, 0805
CAP ., OPTION, 0805
RES., OPTION, 0402
RES., OPTION, 0603
IND., OPTION, 1812
IND., OPTION, 4mm × 4mm, AEX-Q200
TESTPOINT, TURRET 0.064"
JACK, BANANA
CONN, BNC, 5 PINS
HEADER, 1×2, 2mm
HEADER, 2×3, 2mm
HEADER, 1×3, 2mm
STAND-OFF , NYLON 0.5"
SHUNT, 2mm
MANUFACTURER/PART NUMBER
MURATA, GRM155R70J105KA12D
VISHAY, CRCW060310K0FKEAC
VISHAY, CRCW060360K4FKEA
VISHAY, CRCW060330K1FKEA
YAGEO, RC0603FR-0710K7L
VISHAY, CRCW060315K0FKEA
YAGEO, RC0603FR-076K65L
STACKPOLE ELECTRONICS, RMCF0603FG100K
ROHM, SFR01MZPJ000
YAGEO, RC0603FR-070RL
YAGEO, RC0603JR-07150KL
VISHAY, WSL25125L000FEA
ANALOG DEVICES, INC. LTM4657EY#PBF
OPTION
OPTION
OPTION
OPTION
MURATA, NFM21PC104R1E3D
TDK, YFF31HC2A104MT000N
MURATA, NFM18CC223R1C3D
MURATA, NFM31PC276B0J3L
OPTION
OPTION
OPTION
OPTION
OPTION
COILCRAFT, XEL4020-800MEC
MILL-MAX, 2308-2-00-80-00-00-07-0
KEYSTONE, 575-4
AMPHENOL RF , 112404
SULLINS, NRPN021PAEN-RC
SULLINS, NRPN032PAEN-RC
SAMTEC, TMM-103-02-L-S
KEYSTONE, 8833(SNAP ON)
SAMTEC, 2SN-BK-G
Rev. 0
7
