DEMO MANUAL DC2958A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 1 C4
4 1 C6
5 1 C7
6 1 C8
7 1 L1
8 1 R2
9 1 R3
DC2958A-A Version Specific Components
1 1 U1
2 1 C5
3 1 R4
4 1 R5
DC2958A-B Version Specific Components
1 1 U1
2 0 C5 (OPT.)
3 1 R4
4 0 R5 (OPT.)
DC2958A-C Version Specific Components
1 1 U1
2 0 C5 (OPT.)
3 1 R4
4 0 R5 (OPT.)
Additional Demo Board Circuit Components
1 1 C1
2 2 C3,C10
3 1 C9
4 1 C11
5 2 C12, C13
6 1 FB1
7 1 L2
8 1 R1
9 0 R6 (OPT.)
Hardware for Demo Board Only
1 9 E1 – E9
2 1 E10(OPT.)
3 1 JP1
4 1 XJP1
5 4 MH1 – MH4
6
PART DESCRIPTION
CAP ., X7R, 4.7μF, 50V, 10% 1206
CAP ., X7R, 0.1μF, 16V, 10%, 0603
CAP ., X7R, 47μF, 10V, 10%, 1210
CAP ., X7R, 1.0μF, 25V, 10%, 0603
CAP ., X7R, 0.01μF, 16V, 10%, 0603
IND., 2.2µH
RES., CHIP , 18.2k, 1/10W, 1%, 0603
RES., CHIP , 49.9k, 1/10W, 1%, 0603
IC, REGULATOR, DDM-10
CAP ., C0G, 10pF, 25V, 5%, 0603
RES., CHIP , 1MΩ, 1/10W, 1%, 0603
RES., CHIP , 187k, 1/10W, 1%, 0603
IC, REGULATOR, DDM-10
CAP ., 0603
RES., 0Ω, 1/10W, 0603
RES., 0603
IC, REGULATOR, DDM-10
CAP ., 0603
RES., 0Ω, 1/10W, 0603
RES., 0603
CAP ., ALUM 22μF 63V
CAP ., X7R, 4.7μF, 50V, 10% 1206
CAP ., X7R, 4.7μF, 16V, 10%, 0805
CAP ., X7R, 1μF, 50V, 10%, 0805
CAP ., X7R, 0.1μF, 50V, 10%, 0603
FERRITE BEAD 0805
RES., CHIP , 0Ω, 3/4W, 2010
RES., CHIP , 1MΩ, 1/10W, 1%, 0603
RES., 0603
TESTPOINT, TURRET, 0.094"
TESTPOINT, TURRET, 0.094"
DOUBLE ROW HEADER 2 × 4 0.079"
SHUNT, 0.079" CENTER
STAND-OFF , NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM31CR71H475K
MURATA, GRM188R71C104KA01D
MURATA, GRM32ER71A476KE20L
MURATA, GRM188R71E105KA12D
AVX, 0603YC103KAT2A
COILCRAFT, XFL4020-222MEC
VISHAY, CRCW060318K2FKEA
VISHAY, CRCW060349K9FKEA
ANALOG DEVICES, LT8609AEDDM#PBF
AVX, 06033A100JAT2A
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW0603187KFKEA
ANALOG DEVICES, LT8609AEDDM-5#PBF
VISHAY, CRCW06030000Z0EA
ANALOG DEVICES, LT8609AEDDM-3.3#PBF
VISHAY, CRCW06030000Z0EA
SUN ELECT, 63CE22BS
MURATA, GRM31CR71H475K
MURATA, GRM21BR71C475K73L
TDK, C2012X7R1H105K
MURATA, GRM188R71H104KA93D
TDK, MPZ2012S221A
VISHAY, CRCW20100000Z0EF
VISHAY, CRCW06031M00FKEA
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS NRPN042PAEN-RC
SAMTEC 2SN-BK-G
KEYSTONE, 8833 (SNAP ON)
Rev. 0
