Table 8 Product Specifications (Continued)
Item
DSAM Sweep Specifications (optional)
Forward Sweep
Reverse Sweep and Reverse
Alignment
Sweep Modes
Frequency Range
Display Span
Display Scale/Range
Sweep Pulse Occupied
Bandwidth
Stability
Sweep Rate
Channel Plan Templates (user
editable on SDA Head-end
gear)
Return Loopback
Frequency Range
Transmit Level
DSAM Product Family Quick-Start Guide Rev. 001
DSAM Product Family Specifications
Description
Requires SDA-5500
(SDA compatible mode)
Requires SDA-5500 (Single Reverse)
or SDA-5510 (Multiple Reverse)
(SDA compatible mode)
5 to 1000 MHz Forward
5 to 65 MHz Reverse
User definable
6 vertical divisions
1, 2, 5, or 10 dB/division
30 kHz
± 0.5 dB, normalized (dependent on
stability of referenced carriers)
~1 second (78 channels, including
scrambled and digital signal types)
China-1; China-2; France; HDTP-NL;
Ireland; Japan; Jerold; Jerold-HRC;
Jerold-IRC; NCTA; NCTA-HRC;
NCTA-SUB; NCTA-IRC; NTSC-
Broadcast; OIRT-D/K; PL-B/G; PAL-
UK
5-55 MHz (Annex B),
5-65 MHz (Annex A)
8-58 dBmV
Appendix A Specifications
