Initial Set-Up

Installing the
Battery
DSAM Product Family Quick-Start Guide Rev. 001
sources for additional technical assistance, the product
warranty, equipment return instructions, and specifications
for the meter and its power components.
Typically your DSAM meter is shipped with the following
accessories:
– One (1) Hi-Capacity Li-Ion rechargeable battery
– One (1) 12 volt DC universal power supply module
– One (1) power cord
– One (1) 12-volt DC in-vehicle power cable
– One (1) protective soft case
– One (1) shoulder strap
– One (1) installed replaceable lens
– One (1) quick-start guide
Many optional accessories are available to extend your
DSAM meter's functionality, versatility, and ease of use.
Learn more about optional DSAM accessories at this
Internet address:
index.html.
To install the battery
1 Hold the meter securely with the display screen facing
away from you and the keypad in the palm of your
hand.
2 Holding the battery in your other hand with its label
facing away from you, rest the lower (contact) edge of
the battery against the raised edge at the bottom of
the meter.
3 Gently lower the battery into the cavity of the meter
until the top edge of the battery latches into place.
