Features

• X-NUCLEO-IHM16M1
– Three-phase driver board for BLDC/PMSM motors based on
– Nominal operating voltage range from 7 V dc to 45 V dc
– Output current up to 1.5 A rms
– Overcurrent, short-circuit, and interlocking protections
– Thermal shutdown and under-voltage lockout
– BEMF sensing circuitry
– Support of 3-shunt or 1-shunt motor current sensing
– Hall-effect-based sensors or encoder input connector
– Potentiometer available for speed regulation
– Equipped with ST morpho connectors
• NUCLEO-G431RB
– STM32G431RB
LQFP64 package with 128 Kbytes of flash memory and 32 Kbytes of SRAM
– Two types of extension resources:
◦
◦
– On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage,
Virtual COM port, and debug port
– 1 user and 1 reset push-buttons
• Three-phase motor:
– Gimbal motor: GBM2804H-100T
– Maximum DC voltage: 14.8 V
– Maximum rotational speed: 2180 rpm
– Maximum torque: 0.981 N·m
– Maximum DC current: 5 A
– Number of pole pairs: 7
• DC power supply:
– Nominal output voltage: 12 V dc
– Maximum output current: 2 A
– Input voltage range: from 100 V ac to 240 V ac
– Frequency range: from 50 Hz to 60 Hz
