Conventions
Table 5
provides the conventions used for the ON and OFF settings in the present document.
Convention
Jumper OFF
Jumper [1-2]
Solder bridge ON
Solder bridge OFF
UM2538 - Rev 2
Table 5.
Jumper ON
ON/OFF conventions
Definition
Jumper fitted
Jumper not fitted
Jumper fitted between pin 1 and pin 2
Connections closed by 0 Ω resistor
Connections left open
UM2538
Conventions
page 6/25
