Features

• Ultra-low-power STM32U5x9NJH6Q microcontroller based on the Arm
TrustZone
for STM32U5A9NJH6Q, and SMPS in a TFBGA216 package
• 2.47" RGB 480 × 480 pixels TFT round LCD module with 16.7M color depth, with MIPI DSI
interface and capacitive touch panel
• USB Type-C
• Low‑power system designed for VDD at 1.8 V only
• MEMS sensors from STMicroelectronics
– Time‑of‑Flight and gesture-detection sensor
– Temperature sensor
• 512‑Mbit Octo‑SPI NOR flash memory
• 512‑Mbit Hexadeca‑SPI PSRAM
• 4‑Gbyte eMMC flash memory
• Two user LEDs
• User and reset push-buttons
• Board connectors:
– USB ST-LINK Micro-B
– USB Type-C
– Two double-row 2.54 mm pitch expansion connectors for additional peripherals prototyping
– Audio MEMS daughterboard expansion (for STM32U5G9J-DK1)
– MIPI10
– Tag‑Connect
• Flexible power-supply options: ST-LINK USB V
• On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded
Workbench
Note: Arm and TrustZone are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2967 - Rev 4
®
, featuring 4 Mbytes of flash memory, 3 Mbytes of SRAM for STM32U5G9NJH6Q or 2.5 Mbytes
®
with USB 2.0 HS interface, sink only
®
™
10‑pin footprint
®
, MDK-ARM, and STM32CubeIDE
®
Cortex
, USB connector, or external sources
BUS
STM32CubeU5
UM2967
Features
‑M33 core with Arm
® ®
®
2‑data lane
MCU Package
