UM2248
Pin RGB mode
No. description
47
49
6.30.1

Limitations

The TFT LCD module connector supports RGB mode or FMC mode only at the same time.
The signal INT is used both for TFT LCD and DSI display connectors. When RGB mode
TFT LCD is used, STM32L4R9AII6 cannot access the on-board SRAM and NOR flash
memory.
6.31 Pmod™ connector
The Pmod™-standard connector (P1) is available on the STM32L4R9I-EVAL main board to
support flexibility in small form factor applications. The Pmod™ connector implements the
Pmod™ type 2A and 4A on the STM32L4R9I-EVAL main board.
Pin number
1
2
3
4
5
6
6.32

MB1314 DSI display daughterboard

MB1314 is the DSI display daughterboard that is available to mount on the STM32L4R9I-
EVAL main board via the CN1 connector. GVO IEG1120TB103GF-001 is selected for round
LCD with one data lane, 390x390 resolution, 24 bpp with capacitive touch panel (FocalTech
FT3x67 driver).
CN1 connector.

Table 24. Pin function description of the MB1314 daughterboard connector (CN1)

Pin number
1
3
5
7
Table 22. TFT LCD module connector (CN20) (continued)
FMC mode
description
BLGND BLGND
BLGND BLGND
Table 23. Pmod™ connector (P1)
Description
SS/CTS (PI0/PB13)
MOSI/TXD (PI3/PG7)
MISO/RXD (PI2/PG8)
SCK/RTS (PI1/PB12)
GND
3.3 V
Table 24 shows the pin function description of the MB1314 daughterboard
Description
GND
DSI_CK_P
DSI_CK_N
GND
Pin Pin
connection No. description
- 48
- 50
Pin number
7
8
9
10
11
12
Pin number
2
4
6
8
UM2248 Rev 5
Hardware layout and configuration
RGB mode FMC mode
description
VDD VDD
+3.3 V +3.3 V
Description
INT (PG13)
RESET (PB14)
GND
3.3 V
Description
DSI_INT
GND
RFU
Pin
connection
-
-
-
-
-
47/77
