MB1315 TFT LCD daughterboard

MB1315 is the TFT LCD daughterboard supporting RGB mode, available to mount on the
STM32L4R9I-EVAL main board via the CN1 connector.
The 4.3" TFT LCD uses LCD RK043FN48H-CT672B with a capacitive touch panel, which only
supports 3.3 V power and interface. So, a level shifter SN74LVC16T245DGGR is requested
on the TFT RGB LCD daughterboard to support a wide power supply range.
the pin function description of the MB1315 daughterboard connector (CN1).

Table 25. Pin function description of the MB1315 daughterboard connector (CN1)

Pin number
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
Description
GND
R0
R1
R2
R3
R4
R5
R6
R7
GND
B0
B1
B2
B3
B4
B5
B6
B7
GND
INT
-
BL_CTRL
BL+5 V
BLGND
BLGND
UM2248 Rev 5
Hardware layout and configuration
Pin number
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
Table 25 shows
Description
GND
G0
G1
G2
G3
G4
G5
G6
G7
GND
DE
LCD_DSIP
HSYNC
VSYNC
GND
PCLK
GND
RST#
SDA
SCL
-
-
-
VDD
+3.3 V
