Wiring Diagram - Directed DS3+ Installation Manual

Wiring diagram

- Important! In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without notice. Please ensure you disconnect the (-) terminal - Important! In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without notice. Ensure you disconnect the (-) terminal of the
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
of the battery prior to disconnecting and reconnecting the connectors at the start-stop module below the steering wheel to avoid damage to the keyless entry module. battery prior to disconnecting and reconnecting the connectors at the start-stop module below the steering wheel to avoid damage to the keyless entry module.
- Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( - Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Start/Stop Unit
(white conn. at steering column)
16 15 14 13 12 11
32 31 30 29 28 27 26
Keyless Data:
Green/Orange or Green,
pin 9
(+)12V
(-) Parking Lights:
Yellow, pin 3
7 933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Lt. Green/Red or Pink, pin 10
(+) Starter:
Brown/Black or Brown,
pin 23
10 9 8 7 6 5 4 3 2 1
25 24 23 22 21 20 19 18 17
(-) PTS: pin 20
1A diode
Ign. 2 Interr.:
[1N4002+]
Violet, pin 17
Cut
86 87 85
87a
30
Optional
Cut
Parking Lights Interrupt:
Green, pin 4
1 2 3 4 5 6
Parking Light
Switch Assembly
Refer to the Optional starter
disable connection section for
relay and connection details.
Start/Stop Unit
(white conn. at
(+) Ignition:
steering column)
12 11 10 9 8 7 6 5 4 3 2 1
24 23 22 21 20 19 18 17 16 15 14 13
HS CAN High: (+) Accessory 2: Brown/Red
White/Black or Pink, pin 14
or White, pin 7
HS CAN Low:
Red/Yellow
or Red, pin 8
(-) Parking Lights Output: Lt. Green/Black: 1
(-) Ignition Interrupt Output: Dk. Blue/Black: 9
Hood Pin
Siren
Parking Light Interrupt (vehicle side): Blue/White: 1
Parking Light Interrupt (conn. side): Blue: 3
(+) 12V:
White, pin 1
1
Fuse Box
(white conn.
at driver's kick)
HS CAN Low: Tan: 1
A
HS CAN High: Tan/Black: 2
this installation.
Keyless Data Output: Orange/Black: 7
(-) GWA Output: Dk. Green/Black: 3
(+) Accessory 2 Output: Violet/Black: 8
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
(+) Starter Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
(+) 12V Input: Lt. Green/Red: 7
(+) Ignition Output: Lt. Green: 8
(-) Ground: Black: 10
Legend:
DS4+
).
). ).
module can also be used for
IMPORTANT:
Position the
fuses correctly!
Slide to open
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
