Directed DS3+ Installation Manual page 12

Module
Conn./Pin Color Description
H4/2 Red/Black No Connection
H4/3 Pink/Black No Connection
H4/4 Pink/White No Connection
H4/5 Red No Connection
H4/6 Green No Connection
H4/7 Violet No Connection
H4/8 Orange No Connection
H4/9 Red/White No Connection
H4/10 Pink No Connection
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin Color Description
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
